ASSEMBLY ASSISTANCE
IMPORTANT: Retain for future reference and read
carefully.
Foundations strives for the highest quality in our
products but occasionally a missing part or problem
can occur during assembly.
If any parts are missing or broken or you need
assistance with assembly, DO NOT return the
product to your dealer. Go to our website at
www.foundations.com or call Foundations
for assistance at 1-877-716-2757 (U.S. Only) or
1-330-722-5033 (Monday through Friday,
9:00 a.m.– 4:00 p.m. Eastern Time). Please have
the model number and manufacture date available
when you call or write us at:
Foundations, 5216 Portside Dr., Medina, OH 44256
ASSEMBLY INSTRUCTIONS
• Adult assembly required.
• Read all instructions BEFORE assembly and USE
of product.
• Unpack carton, remove packing materials,
including polybag. Identify and check all parts.
STEP X
.
(outside of U.S. 330-722-5033). DO NOT CALL
FOR WARRANTY AND FEDERAL SAFETY STANDARD
COMPLIANCE CERTIFICATES, PLEASE VISIT OUR
Record the information for your product here:
Model number:
Manufacture date:
PO number:
Harmony Night Stand
Foundations Worldwide, Inc.
Medina, OH 44256 USA
www.forever-eclectic.com
AB20394_G1
FOR CUSTOMER SERVICE CALL
1-877-716-2757
RETAILER OR RESELLER FOR SERVICE
AS THEY ARE NOT AUTHORIZED TO
RESOLVE ANY SERVICE ISSUES.
WEBSITE AT
www.forever-eclectic.com
Model Covered: F09028
5216 Portside Dr.
PH: 1 330.722.5033
FAX: 1 330.722.5037
AB20394A
Advertisement
Table of Contents
Related Manuals for FOREVER Eclectic Harmony F09028
Summary of Contents for FOREVER Eclectic Harmony F09028
- Page 1 STEP X Harmony Night Stand Model Covered: F09028 Foundations Worldwide, Inc. 5216 Portside Dr. Medina, OH 44256 USA PH: 1 330.722.5033 FAX: 1 330.722.5037 www.forever-eclectic.com AB20394_G1 FOR CUSTOMER SERVICE CALL KEEP INSTRUCTIONS 1-877-716-2757 FOR FUTURE USE (outside of U.S. 330-722-5033). DO NOT CALL RETAILER OR RESELLER FOR SERVICE AS THEY ARE NOT AUTHORIZED TO ASSEMBLY ASSISTANCE...
-
Page 2: Parts List
PARTS LIST Description Quantity A. Top B. Left Side C. Right Side D. Back Panel E. Shelf F. Front Top Rail G. Front Middle Rail H. Front Bottom Rail . Back Top Rail J. Drawer Front K. Drawer Left Side L. - Page 3 STEP 1 C x 1 H x 1 I x 1 AA x 4 DD x 1 EEx 1 AA x 2 AA x 2 AB20394_G4 STEP 2 E x 1 D x 1 CC x 3 AA x 3 CC x 3 AA x 3 AB20394_G5...
- Page 4 STEP 3 B x 1 AA x 7 DD x 1 EE x 1 AA x 7 AB20394_G6 STEP 4 F x 1 BB x 2 CC x 2 BB x 2 CC x 2 AB20394_G7...
- Page 5 STEP 5 JJ x 4 CC x 5 JJ x 4 CC x 5 AB20394_G8 STEP 6 A x 1 EE x 6 EE x 6 AB20394_G9...
- Page 6 STEP 7 AA x 4 DD x 6 DD x 6 AA x 4 AB20394_G10 STEP 8 CC x 2 II x 8 CC x 2 HH/II x 8 AB20394_G11...
- Page 7 STEP 9 G x 1 BB x 2 CC x 4 CC x 2 BB x 2 CC x 2 AB20394_G12 STEP 10 J x 1 L x 1 K x 1 N x 1 CC x 4 CC x 4 AB20394_G13...
- Page 8 STEP 11 M x 1 CC x 4 CC x 4 AB20394_G14 STEP 12 FF x 1 GG x 1 AB20394_G15...
-
Page 9: Drawer Removal
STEP 13 These slide sections mounted on cabinet must be fully extended for installation This slide section mounted to drawer Drawers may need to be pushed in and out to properly set slides AB20394_G16 DRAWER REMOVAL AB20394_G17... -
Page 10: Maintenance And Cleaning
MAINTENANCE AND CLEANING MAINTENANCE: Upon completion of the assembly, check to make sure all screws, bolts and connectors are tightened and secure. Periodically check furniture for damaged hardware, loose joints, missing parts or sharp edges before and after assembly and frequently during use. DO NOT use furniture if any parts are missing or broken. -
Page 11: Guide D'assemblage
Table De Nuit Harmony Modèle Couvert: F09028 Foundations Worldwide, Inc. 5216 Portside Dr. Medina, OH 44256 USA PH: 1 330.722.5033 FAX: 1 330.722.5037 www.forever-eclectic.com AB20394_G1 POUR LE SERVICE À LA CLIENTÈLE, APPELEZ LE CONSERVEZ CES INSTRUCTIONS À 1-877-716-2757 (à l’extérieur des É-U, appelez le 1-330- TITRE DE RÉFÉRENCE. -
Page 12: Liste Des Pièces
LISTE DES PIÈCES Description des pièces Quantité A. Haut B. Côté Gauche C. Côté Droit D. Panneau Arrière E. Étagère F. Rail Supérieur Avant G. Rail Central Avant H. Rail Inférieur Avant . Rail Supérieur Arrière J. Face de Tiroir K. - Page 13 ÉTAPE 1 C x 1 H x 1 I x 1 AA x 4 DD x 1 EEx 1 AA x 2 AA x 2 AB20394_G4 ÉTAPE 2 E x 1 D x 1 CC x 3 AA x 3 CC x 3 AA x 3 AB20394_G5...
- Page 14 ÉTAPE 3 B x 1 AA x 7 DD x 1 EE x 1 AA x 7 AB20394_G6 ÉTAPE 4 F x 1 BB x 2 CC x 2 BB x 2 CC x 2 AB20394_G7...
- Page 15 ÉTAPE 5 JJ x 4 CC x 5 JJ x 4 CC x 5 AB20394_G8 ÉTAPE 6 A x 1 EE x 6 EE x 6 AB20394_G9...
- Page 16 ÉTAPE 7 AA x 4 DD x 6 DD x 6 AA x 4 AB20394_G10 ÉTAPE 8 CC x 2 II x 8 CC x 2 HH/II x 8 AB20394_G11...
- Page 17 ÉTAPE 9 G x 1 BB x 2 CC x 4 CC x 2 BB x 2 CC x 2 AB20394_G12 ÉTAPE 10 J x 1 L x 1 K x 1 N x 1 CC x 4 CC x 4 AB20394_G13...
- Page 18 ÉTAPE 11 M x 1 CC x 4 CC x 4 AB20394_G14 ÉTAPE 12 FF x 1 GG x 1 AB20394_G15...
- Page 19 ÉTAPE 13 Ces diapositives les sections montées sur l’armoire doivent être entièrement Cette section Slide monté sur tiroir Les tiroirs peuvent avoir besoin être poussé dedans et dehors AB20394_G16 RETRAIT DU TIROIR AB20394_G17...
- Page 20 ENTRETIEN NETTOYAGE ET STOCKAGE ENTRETIEN: À la fin de l’assemblage, assurez-vous que toutes les vis, boulons et connecteurs sont serrés et sécurisé. Vérifiez périodiquement meubles pour le matériel endommagé, les joints lâches, des pièces manquantes ou des bords tranchants avant et après l’assemblage et fréquemment pendant l’utilisation. NE PAS utiliser meubles si des pièces sont manquantes ou brisées.
