Twin Stim® Plus
3rd Edition
QUICK REFERENCE GUIDE
The purpose of this guide is to assist you in correctly operating your Twin Stim® Plus 3rd Edition unit. This
device should only be used under the continued supervision of a healthcare professional. This guide is not
intended to replace or substitute the Twin Stim® Plus 3rd Edition Instruction Manual. PLEASE READ THE
INSTRUCTION MANUAL COMPLETELY BEFORE USING THIS DEVICE. Read, understand and practice the
contraindications, warnings, cautions and operating instructions found on page
manual. Always follow the operating instructions prescribed by your healthcare provider.
Top
11
10
9
8
7
6
Front
15
ELECTRODES
(SET OF 4)
LEAD WIRES
(4 INCLUDED,
ONE FOR EACH
CHANNEL)
For more information about your Twin Stim® Plus 3
1
2
3
4
5
INDICATION FOR USE
DEFINITIONS
TENS
The TENS and IF modes are often prescribed for:
Transcutaneous Electrical
Nerve Stimulator
EMS
Electrical Muscle
Stimulation
The EMS and RUSSIAN modes are often prescribed for:
IF
Interferential
RUSSIAN
Specific Form
of Electro-stimulation
Consult a physician before using for undiagnosed pain.
rd
Back
14
12
13
Back
• Symptomatic relief of chronic intractable pain
• Reduction of inflammation
• Post-traumatic acute pain and edema
• Post-surgical acute pain and edema
• Relaxation of muscle spasms and edema reduction
• Prevention or retardation of disuse atrophy
• Increasing local blood circulation
• Muscle re-education
• Maintaining or increasing range of motion
• Immediate post-surgical stimulation of lower leg muscles to
prevent venous thrombosis
Edition unit, please visit richmarweb.com or call 1-800-871-7858.
PAGE 1
25
of your instruction
TWIN STIM® PLUS
3
EDITION UNIT
RD
1
Lead Connector Sockets - 4 Channels
2
Liquid Crystal Display (LCD)
3
Panel Cover
4
Mode Control
5
Power On/Off Control
6
Set Control
Increment Control for Pulse Rate,
7
Pulse Width and Time Indicators
Decrement Control for Pulse Rate,
8
Pulse Width and Time Indicators
Intensity Decrease Control for
9
Respective Channels
Intensity Increase Control for
10
Respective Channels
11
Channels 1-4 LEDs
12
Belt Clip
13
Battery Case
14
Batter Cover
15
AC Adapter
3264.19.06.A
