Bond Y97016 Assembly Instruction

Read these instructions carefully and keep the fountain power off until the following
Notes:
Choose an appropriate location for the fountain.
Excessive weight or pressure on any of the fountain sections may cause it to fall. Keep pets,
children, or anyone from sitting, leaning, or climbing on any of the fountain components.
While fountain is designed to operate as splash free as possible, some water splashing out of
the fountain is inevitable. Place the fountain in a location where any splashing will not cause
damage.
The National Electric Code requires that a ground fault circuit interrupter (GFCI) be used in
the branch circuit supplying fountain pump and other pond equipment. Seek your electrical
supplies dealer for this device.
Always keep the fountain working with sufficient water and clean of debris and dirt to ensure
proper functioning of the pump.
If necessary, clean the fountain with a soft cloth and change the water frequently. Due to
water evaporation, you may see a buildup of white residue on the fountain surface from
mineral content in the water supply. To prevent such buildup, regularly clean the fountain
with soap and water, do not use any abrasive, which may damage the applied finish.
See the pump instructions for pump safety, maintenance, and warranty information.
Keep this manual for future reference.
Installation & Assembly
Place the fountain on a level surface, away from areas where it is likely to get clogged with
leaves and make sure that the cable will reach the socket.
Follow steps to assemble as illustrated below.
Figure'1-5'
Step (1) Connect the big plate and pedestal tightly as arrowheads indicates.
Figure'2-5'
Step (2) Get the wire of pump through plastic pipe of big plate centre. Make sure the wire is put
into the pedestal's cavity.
Step (3) Connect the pillar and big plate tightly as arrowheads indicate.
Figure'3-5'
Step (4) Connect medium plate and pillar tightly as arrowheads indicate.
Figure'4-5'
Step (5) Put plastic hose into the plastic pipe of medium plate centre then connect top part and
medium plate tightly as arrowheads indicate.
Figure'5-5'
Step (6) Connect plastic hose to pump outlet.
Step (7) Please close the small door to the pillar of big plate centre.
Step (8) and (9) Fill the big plate with enough clean water to assure the pump to work properly.
Plug the pump, water will start to flow in minutes.
Assembly Instruction
Y97016
* * WARNING * *
assembly process is strictly completed.
