Read these instructions carefully and keep the fountain power off until the following
Notes:
Choose an appropriate location for the fountain.
Excessive weight or pressure on any of the fountain sections may cause it to fall. Keep pets,
children, or anyone from sitting, leaning, or climbing on any of the fountain components.
While fountain is designed to operate as splash free as possible, some water splashing out of
the fountain is inevitable. Place the fountain in a location where any splashing will not cause
damage.
The National Electric Code requires that a ground fault circuit interrupter (GFCI) be used in
the branch circuit supplying fountain pump and other pond equipment. Seek your electrical
supplies dealer for this device.
Always keep the fountain working with sufficient water and clean of debris and dirt to ensure
proper functioning of the pump.
If necessary, clean the fountain with a soft cloth and change the water frequently. Due to
water evaporation, you may see a buildup of white residue on the fountain surface from
mineral content in the water supply. To prevent such buildup, regularly clean the fountain
with soap and water, do not use any abrasive, which may damage the applied finish.
See the pump instructions for pump safety, maintenance, and warranty information.
Keep this manual for future reference.
Installation & Assembly
Place the fountain on a level surface, away from areas where it is likely to get clogged with
leaves and make sure that the cable will reach the socket.
Follow steps to assemble as illustrated below
Figure'1-2'
Step (1). Connect the top to the fountain tightly as arrowheads indicate.
Step (2). Connect the flexible hose to pump outlet
Step (3).Connect three lines of LED light to connector.
Step (4).Closed up the back door.
Figure'2-2'
Step (5).Connect the connector of LED lihgt to adaptor.
Step (6).Fill the reservoir with clean water carefully or pipe water into fountain from the back
door. Always make sure the water can submerge the pump completely to work properly and
prevent the pump damage.
Step(7)&(8).Plug the pump and adaptor then switch on,the water will start to flow in
minutes,and lights will be shining instantly.
Adjust the pump flow rate to achieve the desired effect and to minimize any splashing.
Splashing can occur if the flow rate is too high or the reservoir is too full. The flow rate can
be increased or decreased by moving the flow rate control slider on the pump body. Moving
the switch towards '+/ Max.' will increase the flow rate and moving it towards '-/Min' will
decrease it.
On some type of pumps, flow regulator may be turned clockwise or counterclockwise to
adjust.
Assembly Instruction
Y98563
* * WARNING * *
assembly process is strictly completed.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Y98563 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bond Y98563

  • Page 1 Assembly Instruction Y98563 * * WARNING * * Read these instructions carefully and keep the fountain power off until the following assembly process is strictly completed. Notes: Choose an appropriate location for the fountain. Excessive weight or pressure on any of the fountain sections may cause it to fall. Keep pets, children, or anyone from sitting, leaning, or climbing on any of the fountain components.
  • Page 2 (6) the pump might be “air locked”. Plug and unplug the pump several times to release the air inside the pump. (7) check and reconnect all the cords and try again. IF YOU HAVE QUESTIONS OR CONCERNS PLEASE CALL BOND TOLL FREE # 1-866-771-BOND(2663) OR TO BETTER EXPEDITE YOUR REQUEST FEEL FREE TO EMAIL US customerservice@bondmfg.com OR LOG IN TO OUR WEBSITE UNDER CUSTOMER SERVICE SUPPORT www.bondmfg.com...
