Goldtouch SK-9071 Product Manual

Getting Started
Thank you for choosing this Bluetooth Keyboard . SK-9071 is to develop a BT3.0 Keyboard for mobile device, such as Media Tablet or Smart
phone. It was designed to be fully compatible with i-OS, Android, Win XP, Vista and win7 system. This specification defines mechanical,
reliability, dynamic, electric requirements.
Set up the keyboard.
1. Turn on the keyboard
2. Press the Blue connect button. The battery light flashes green.
3. Complete Bluetooth pairing on your device.
Insert the battery.
● Remove the battery compartment cover at the bottom of the keyboard
by pushing it in the direction of the arrow.
● Insert two AAA batteries.
● Place back the battery compartment cover.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to instructions. Refer
to "Important Battery Information" for disposal instructions.
● Low battery warning
Red-colored LED on upper-right edge of keyboard will keep flashing when it operates in low power.
The following description of keys applies for the operating systems that support these functions:
●
Mute (Fn+F10)
Volume Down (Fn+F11)
Volume Up(Fn+F12)
Previous Track (Fn+F7)
Play/Pause (Fn+F8)
Next Track(Fn+F9)
Technical data
Designation
Wireless
Operating Frequency
Storage temperature
Operating temperature
Battery type
Supply voltage
Current consumption
SK-9071 Bluetooth Keyboard Product Guide
Press this key to mute/unmute the audio.
Press this key to decrease the volume.
Press this key to increase the volume.
Multimedia key to skip to the previous track in the active player.
Multimedia key to play or pause the track or video in the active player.
Multimedia key to skip to the next track in the active player.
Value
Bluetooth EDR 2.0
2402MHz~2480MHz
–20 °C ... +60 °C
0 °C ... +40 °C
two alkaline batteries, type AAA
3V(2.2~3.3V)
max. 50 mA
User's Manual
