Goldtouch

Getting Started

Thank you for choosing this Bluetooth Keyboard . SK-2770 is to develop a BT3.0 Keyboard for mobile device, such as Media Tablet or Smart
phone. It was designed to be fully compatible with i-OS, Android, Win XP, Vista and win7 system.

Set up the keyboard.

1.
Turn on the keyboard
2.
Press the Blue connect button. The battery light flashes green.
3.
Complete Bluetooth pairing on your device.

Insert the battery.

● Remove the battery compartment cover at the bottom of the keyboard
by pushing it in the direction of the arrow.
● Insert two AAA batteries.
● Place back the battery compartment cover.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to instructions. Refer
to "Important Battery Information" for disposal instructions.
● Low battery warning
Red-colored LED on upper-right edge of keyboard will keep flashing when it operates in low power.
The following description of keys applies for the operating systems that support these functions:
Mute (Fn+F6)
Volume Down (Fn+F4)
Volume Up(Fn+F5)
Previous Track (Fn+F1)
Play/Pause (Fn+F2)
Next Track(Fn+F3)

Technical data

Designation
Wireless
Operating Frequency
Storage temperature
Operating temperature
Battery type
Supply voltage
Current consumption
SK-2770 Bluetooth Keyboard Product Guide
Press this key to mute/unmute the audio.
Press this key to decrease the volume.
Press this key to increase the volume.
Multimedia key to skip to the previous track in the active player.
Multimedia key to play or pause the track or video in the active player.
Multimedia key to skip to the next track in the active player.
Value
Bluetooth 3.0 without EDR
2402MHz~2480MHz
–20 °C ... +60 °C
0 °C ... +40 °C
two alkaline batteries, type AAA
3V(2.2~3.3V)
max. 50 mA
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SK-2770 and is the answer not in the manual?

Questions and answers

taylor
March 6, 2025

cannot connect bluetooth , due to no have PIN

1 comments:
Mr. Anderson
March 6, 2025

The Goldtouch SK-2770 Bluetooth keyboard does not mention requiring a PIN for pairing. To connect it, follow these steps:

1. Turn on the keyboard.
2. Press the blue "Connect" button until the battery light flashes green.
3. Complete the Bluetooth pairing process on your device.

If a PIN is requested, try entering "0000" or "1234" on the device and pressing "Enter" on the keyboard. If the device allows pairing without a PIN, simply accept the connection request.

This answer is automatically generated

Summary of Contents for Goldtouch SK-2770

  • Page 1 Getting Started Thank you for choosing this Bluetooth Keyboard . SK-2770 is to develop a BT3.0 Keyboard for mobile device, such as Media Tablet or Smart phone. It was designed to be fully compatible with i-OS, Android, Win XP, Vista and win7 system.
  • Page 2 User’s Manual FCC/Canada Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
