Hubbell GAI-TRONICS 12504-004 Series Manual

Door Handle Replacement Kits
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics. GAI-
Tronics retains all intellectual property and other rights in or to the information contained herein, and
such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.
General Information
The Model 12504-004 Series Door Handle Replacement Kits include the following models:
 
12504-004
They are provided for the repair of the following GAI-Tronics weatherproof enclosures:
 
473-001 7335-002
 
733-002 473-002
This kit includes the following components:
Qty Description
1 Handle
1 Handle shaft, stainless steel
Flat washer, stainless steel, 0.281 I.D.  0.500 O.D.  0.063 thick (inches)
1
1 Torsion spring, stainless steel
Roll pin, stainless steel (0.125-inch dia.  1.00-inch long)
1
1 O-ring
Installation
Removing the Old Handle
1. Knock the existing roll pin entirely out of the handle and the handle shaft.
2. Remove the handle from the shaft. Unhook the torsion spring from the retaining boss on the inside of
the door. Remove the shaft, the spring, and the flat washer from the door, and discard all the pieces
removed from the door.
GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA
V
ISIT WWW
G A I - T R O N I C S ®
A H U B B E L L C O M P A N Y
M 12504-004 S
ODEL

12504-004OR 12504-004RD

733-001

7335-001
610-777-1374  800-492-1212  Fax: 610-796-5954
. - .
GAI TRONICS COM FOR PRODUCT LITERATURE AND MANUALS
ERIES

12504-004YL
 
10444-003 7335-004
 
733-006 7335-006
Pub. 42003-011C

255-003xx

354-001xx
Item Number
1
2
3
4
5
6
