STS/Mutoh 628D/628DC Printer Guidelines
• Best Environmental Conditions
• No direct sunlight.
• Dust free with minimal static.
• Temperatures between 20 and 24 degrees Celsius/68-75F 24hrs a day 7 days a week.
• Humidity 35% - 45%.
Note: When using 220ml and 500ml cartridges, do not wet cap the print head.
The STS/Mutoh 628DC Printer is designed to stay on, the built-in internal circulation cycles throughout the
• Daily Maintenance/Before Daily Printing
1. Remove and rotate the 2 white ink cartridges to a flat position and shake them from
side to side with the cartridge slot guide in both up and down positions (40x) each day
before wakeup from sleep mode.
2. Also shake the cartridge upside down to make sure the cartridge contents is mixed in
appropriately
Allow your printer to automatically enter sleep mode.
night. Keep this printer on & attached to a surge protector.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MUTOH 628D
Summary of Contents for MUTOH 628D
- Page 1 Note: When using 220ml and 500ml cartridges, do not wet cap the print head. Allow your printer to automatically enter sleep mode. The STS/Mutoh 628DC Printer is designed to stay on, the built-in internal circulation cycles throughout the night. Keep this printer on & attached to a surge protector.
- Page 2 STS/Mutoh 628D/628DC Printer Guide- www.stsinks.com 3. Before installing, remove any free ink from the end of each 500mL white cartridge with a paper towel. 4. Make sure the Heat Platen is free from residue or ink (the metal surface that the substrate prints on, and that the media guards are also clean, as well as underneath them) 5.
- Page 3 STS/Mutoh 628D/628DC Printer Guide- The PET Film used for DTF printing is covered with a layer of a specialized emulsion that sets the inks to a gel-like state when the ink lands on the film. Therefore, if the print head touches the PET film any ink...
- Page 4 STS/Mutoh 628D/628DC Printer Guide- www.stsinks.com • Cleaning of Cleaning Wiper Cleaning period: • Weekly. • When print blurring and dot missing remain after head cleaning is done. Preparation: • Cleaning Stick. Steps: 1. Display the Printer Preferences screen of printer driver.
- Page 5 STS/Mutoh 628D/628DC Printer Guide- 5. Short press the operation key on the operation panel. * The carriage moves to the maintenance position inside the front cover. 6. Open the front cover. IMPORTANT - When cleaning the cleaning wiper, please note the followings.
- Page 6 STS/Mutoh 628D/628DC Printer Guide- www.stsinks.com • Inside Cleaning Cleaning period: • Monthly. Steps: 1. Check the power is OFF. 2. Open the front cover. IMPORTANT Inmediately after turning OFF the power, the temperature of the heater on this product is very high.
- Page 7 STS/Mutoh 628D/628DC Printer Guide- • Quarterly Maintenance 1. Lubricate the carriage guide rails and the bearings on the carriage. 2. Lightly clean the encoder strip with DI water only using a lint-free cloth once every two or three weeks, and more often after heavy production.
