Open Motor Direct Drive Drum Fan
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item# 5025661
READ & SAVE THESE INSTRUCTIONS
Advertisement
Related Manuals for Strongway 5025661
Summary of Contents for Strongway 5025661
- Page 1 Open Motor Direct Drive Drum Fan Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 5025661 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a Strongway product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code (if applicable): _____________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
- Page 3 Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Grounding .............................. 7 Extension Cords ............................ 8 Main Parts of Product ........................... 9 Assembly Instructions .......................... 9 Before Each Use ..........................
- Page 4 Intended Use This 2-speed 42in. Open Motor Direct-Drive Drum Fan is designed to provide high velocity cooling, ventilation, and circulation of commercial environments. Packaging Contents Drum Fan Body (1) Wheels Shaft (1) Wheels (2) Wheel Shaft Bushing (2) Cotter Pin (2) Owner’s Manual (1)
- Page 5 ⚠WARNING PROP 65 This product can expose you to chemicals including Di(2-ethylhexyl)phthalate (DEHP), which is [are] known to the State of California to cause cancer and birth defects or other reproductive harm.. For more information, go to www.p65warnings.ca.gov. Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm.
- Page 6 Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Air vents on the tool often cover moving parts and should be avoided. ...
- Page 7 Discard fan or return to an authorized service facility for examination and/or repair. Do not run under carpeting. Do not cover with throw rugs,runners, or similar coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic area where it will not be tripped over.
- Page 8 Extension Cords ⚠WARNING USE A PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage, resulting in loss of power and cause overheating.
- Page 9 Main Parts of Product Subassembly Fan Guard Fan Body Fan Blade Motor Wheel Assembly Instructions ⚠WARNING Be sure the fan does not have any damage. 1. Slide wheel axle through wheel support frame. 2. Install wheel axle bushing at both ends of the wheel axle. 3.
- Page 10 Before Each Use ⚠WARNING Before using, be sure the fan does not have any damaged parts. Locate fan in safe, desired position on level ground, and connect to approved power source. Operating Instructions ⚠WARNING Do not operate any fan with a damaged cord or plug, do not expose to water or rain. 1.
- Page 11 Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control. Keep handles dry, clean, and free from oil and grease. Also refer to the engine manufacturer’s instruction manual for additional information about engine maintenance. The following chart is based on a normal operation schedule.
- Page 12 Parts Diagram Parts List Part Number Quantity Part Description Fan Blade Assembly Power Cord Cord Buckle Rocker Switch Electric box Handle Motor fixed press plate Motor Fan guard Wheel Motor fixed bushing Wheel bushing Foot plate Wheel shaft Cotter pin Barrel body Upright support Motor fixed plate...
- Page 13 Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ...
- Page 14 Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Strongway product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase.
- Page 15 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 15 of 15...
