pardo NewCare Bariatrica Bed Quick Reference Sheet

NewCare Bariátrica Bed
Q
uick reference sheet
A
L M C D
B '
ed s coMponents
Removable stainless steal headboard
A
Backrest side rails
B
Backrest tilting indicator
C
Trend / Reverse Trend tilting indicator
D
HPL mattress platform
E
F Legrest side rails
www.pardo.es
TECHNICAL SERVICE CENTRE
(+34) 976 300 033
B E F G
I H J
Removable stainless steal footboard
G
Braking pedal
H
Double wheels Ø15 cm
I
Headboard and footboard unlocking
J
Protection discs
L
M Emergency CPR
o
ther functions
Side rails (1):
ƒ Raising the rail: Pull the rail upwards until it is im-
mobilised in the highest position.
ƒ Lowering the rail: Pull the handle found under-
neath the rail outwards. The rail will automatically
lower.
Emergency CPR (2):
ƒ Activate either of the two levers located under the
headrest module, accompanying it in turn as it
lowers.
Raising the rails
Emergency CPR
c
leaning
Daily cleaning and disinfection with up to a 1000ppm
concentration of chlorine solutions:
ƒ Rails. Headboard. Footboard.
Cleaning and disinfection after a patient leaves or
before a transfer:
ƒ Mattress platform area. Chassis of the bed.
Thorough cleaning and disinfection every two
months:
ƒ Support and lifting area of the bed.
Centralised braking system (3):
ƒ Braking the bed: Pedal in low position.
ƒ Moving the bed: Pedal in intermediate position.
ƒ Activating steering wheel: Pedal in raised position.
Lowering the rails
Brake Free movement Steering wheel
M
aintenance
Always check the correct state of:
ƒ Electrical wiring.
ƒ Wheels.
ƒ Braking mechanisms.
For more information, please consult the
use and maintenance manual.
