pardo TechnoPlus i10 ICU Quick Reference Sheet

TechnoPlus i10 ICU Bed
Q
uick reference sheet
A E
O C N D
B ' c
ed s oMponents
Removable headboard
A
Backrest side rails
B
Backrest tilting indicator
C
Trendelenburg / Reverse Trendelenburg tilting indicator
D
E HPL mattress platform
F Legrest side rails
Removable curved footboard
G
Wheels Ø15 cm
H
Headboard and footboard unlocking
I
www.pardo.es
TECHNICAL SERVICE CENTRE
(+34) 976 300 033
B Q F G
K P H M J I L
Braking pedal
J
Fifth wheel
K
Bed extension lever
L
Lifting column
M
N Emergency CPR
O Protection discs
Protection cover frame
P
Railing weighing system
Q
o
ther functions
Side rails:
ƒ Raising the rail: Pull the rail upwards until it is immo-
bilised in the highest position (1).
ƒ Lowering the rail: Pull the handle placed under-
neath the rail outwards (2). The rail will automatically
lower (3).
Emergency CPR:
ƒ Activate either of the two levers located in the middle
of bed base, accompanying it in turn as it lowers (4).
1
Raising the rails
4
Emergency CPR
c
leaning
Daily cleaning and disinfection with up to a 1000ppm
concentration of chlorine solutions:
ƒ Rails. Headboard. Footboard.
Cleaning and disinfection after a patient leaves or
before a transfer:
ƒ Mattress platform area, chassis of the bed.
Thorough cleaning and disinfection every two
months:
ƒ The entire bed.
Braking pedal:
ƒ Braking the bed: Pedal in low position (5).
ƒ Moving the bed: Pedal in intermediate position (6).
ƒ Activating 5th or steering wheel: Pedal in raised
position (7).
2
Lowering the rails
5 6
Brake Free movement Steering or 5
M
aintenance
Always check the correct state of:
ƒ Electrical wiring.
ƒ Wheels.
ƒ Braking mechanisms.
For more information, please consult the
use and maintenance manual.
3
7
