FASTMOUNT METAL MC Series Installation Manual

METAL MC RANGE
MC-M5/F5/F10 INSTALLATION GUIDE
MC-M5/F5/F10
MC-M5
INSTALLATION STEPS
Drill hole through support frame
1
Min. 13mm deep for self tapping
into plywood or similiar
20Ø
3
Drill panel on centre mark
9
Ø10
MORE INFO: SETOUT GUIDE TD-02, 09, 12. PRODUCT SHEET MC-05
PROUDLY DESIGNED IN NEW ZEALAND
75 | FASTMOUNT TECHNICAL GUIDE 2024
INSTALLATION GUIDE (SELF TAPPING)
MC-F5 MC-F10
Self tapping method
see next page
MC-IT5
in battery drill
4
into panel
Subject to change without notice.
FM Install MC-M5/F5/F10 - 07/24. Copyright © Fastmount Ltd.
INSTALL WITH:
MC-CP5
Note: Installation of wall panels only.
2
Mark panel with MC-CP5
MC-IT5 in battery drill
fastmount.com
20Ø drill CT-09 MC-IT5
Panel
Exploded cutaway view
5
of installed clip set
