LC "Light Condenser"
Vocals
Recording
Live Sound
Sound/AV company
Slender and elegant silhouette
PB 1000 Presence boost adapter for increased intelligibility
Condenser vocal microphone for onstage use
XLR connector module with 24-carat gold plated pins for optimized connectivity
24-carat gold plated transducer case for optimum conductivity and resistance to
corrosion and humidity
Spring steel wire-mesh grill for extreme ruggedness incl. reliable control of pops and wind noise
Internal elastic suspension
L C
This professional condenser vocal microphone will make your voice cut through the loudest mix - on any
stage. Its cardioid polar pattern ensures maximum gain before feedback and has been optimized for use
with in-ear monitor systems. LC is custom-designed with piano black painting to address the aesthetic
preferences of special performances: a slim line premium condenser microphone.
Delivering an extremely accurate, detailed and natural sound, the AKG LC features an XLR connector
module with 24-carat gold plated pins for optimized connectivity, as well as resistance to corrosion and
humidity. Additionally, the LC features a spring steel wire-mesh grill for extreme ruggedness offering
reliable control of pops and wind noise while an artist is on stage.
The resulting LC microphone features a frequency range of 60 to 20,000 Hz and premium 24-carat gold
plated transducer case for optimum conductivity. Offering a slender and elegant silhouette, the
lightweight unit has a subtle piano black finish to visually complement any performance.
Handheld Microphone

Advertisement

loading

Summary of Contents for AKG LC

  • Page 1 The resulting LC microphone features a frequency range of 60 to 20,000 Hz and premium 24-carat gold plated transducer case for optimum conductivity. Offering a slender and elegant silhouette, the lightweight unit has a subtle piano black finish to visually complement any performance.
  • Page 2 Specifications Polar pattern cardioid Frequency range 60 to 20,000 Hz Sensitivity 4 mV/Pa (-52 dBV) Max. SPL for 1%/3% THD 140/145 dB SPL Equivalent noise level 25 dB-A Signal/noise ratio (A-weighted) 69 dB Impedance/load Impedance ≤200 ohms Recommended load impedance: >2000 ohms Powering: 9 to 52 V phantom power to DIN 45596 Current consumption:...
