- Page 1 INFORMATION BOOKLET PERMANENT Bottle Refill & Drinking Fountain MP-TO-01-M MP-TO-01-T MP-TO-01 MP-TO-01-ML MP-TO-01-TL 1300mm 1500mm 1900mm 20191016_MP_IBTO_V06 23301...
-
Page 2: Table Of Contents
CONTENTS Disclaimer And Safety ������������������������������������������������������������������������������ 3 Troubleshooting ���������������������������������������������������������������������������������������� 4 Overview | Installation & Plumbing ����������������������������������������������������������� 5 Installation & Plumbing Bolt Down | Option 1 ���������������������������������������������������������������������������� 6 New Mounting Plate | Option 2 ������������������������������������������������������������ 7 Sub Surface Pit | Option 3 �������������������������������������������������������������������� 8 Accessibility Guidelines ����������������������������������������������������������������������������... -
Page 3: Disclaimer And Safety
DISCLAIMER AND SAFETY Here at Meet PAT™ we are very safety conscious. We design and manufacture water related products with the safety of you, the user, foremost in mind. In addition, we ask that you exercise a degree of care when using any Meet PAT™ product. -
Page 4: Troubleshooting
Step by step instructions on how to perform these tasks are located within the product Information Booklet. If the above troubleshooting does not work, please submit your problem at meetpat.com.au/faults/ or contact the office. All spare parts are available through Meet PAT. -
Page 5: Overview | Installation & Plumbing
OVERVIEW | INSTALLATION & PLUMBING EXTERNAL FEATURES Bottle refill outlet Bottle refill press button/sensor Drinking fountain outlet Drinking fountain press button/sensor INTERNAL COMPONENTS (supplied standard to all water stations) Dual Back Flow Valve Carbon Filter Waterless Trap 40mm PVC Connection Shut off tap with 1/2”... -
Page 6: Installation & Plumbing
INSTALLATION & PLUMBING Meet PAT permanent water stations have multiple installation options. We advise you review the following 3 options and follow the guidelines applicable to your location; 1)BOLT DOWN 2)NEW MOUNTING PLATE 3)SUB SURFACE PIT (optional dog bowl) BOLT DOWN | OPTION 1 Bolt water station down to any appropriate hard surface using concrete fixings or other suitable fasteners. -
Page 7: New Mounting Plate | Option 2
NEW MOUNTING PLATE | OPTION 2 Create a new concrete pad and embed the Meet PAT mounting plate. Plumbing is brought through the base of unit and connected internally. NOTE: All Meet PAT permanent water stations are provided with a mounting plate and screw fixings as part of the purchase price. -
Page 8: Sub Surface Pit | Option 3
SUB SURFACE PIT | OPTION 3 with optional Dog Bowl Create a new concrete pad and embed the sub surface pit. Plumbing is installed internally through the pit. This configuration is needed for the Meet PAT dog bowl. Excavate a hole in Suspend the pit the ground. -
Page 9: Accessibility Guidelines
Clear access path Minimum is 1000mm (with 1200mm preferred) • Circulation area surface can include; a footpath, paving or similar if installing against a path The above guidelines and sizing is applicable to all water stations in the Meet PAT permanent product range... -
Page 10: Panel Replacement |The One
If Solar Top is installed, go Completely to Lighting Instructions remove bottle located in this booklet refill frame & set aside Anti Clockwise Clockwise 4mm Allen Key 8mm Allen Key to loosen Screws Screws to loosen *Additional screws on models MP-TO-01-T & MP-TO-01-TL only... - Page 11 PANEL REPLACEMENT | THE ONE Anti Clockwise 8mm Allen Key Screws to loosen Putting it back together Are you all finished and need to put the unit back together? Follow the steps in reverse 7, 6, * Remember to reattach any water pipes disconnected during disassembly.
-
Page 12: Drinking Fountain
This information will guide you on adjusting the * Amazing flow of the Meet PAT drinking fountain, so it can be everything it’s wanted to be The unit needs to be installed and working for you to adjust the drinking fountain tap flow. - Page 13 TAP FLOW ADJUSTMENT DRINKING FOUNTAIN | FOR PRESS BUTTON Test the flow and operation once the Clockwise button has been 3mm Allen Key to tighten Screws installed * Using a 3mm Allen Key turn the grub screw clockwise 2-3 turns. Has the flow changed? •...
-
Page 14: Tap Flow Adjustment For Sensor Button
FOR SENSOR BUTTON This information will guide you on adjusting the * Amazing flow of the Meet PAT drinking fountain, so it can be everything it’s wanted to be The unit needs to be installed and working for you to adjust the drinking fountain tap flow. -
Page 15: Sensor Tap | Battery Replacement
SENSOR TAP | BATTERY REPLACEMENT ENSURE PANEL IS REMOVED (See panel replacement instruction) A) Disconnect battery pack Locate the battery pack cable from unit inside the water station B) Pull to detach battery pack from water station (velcro adhesive) Detach and retain 4x screws Install 4x new AA batteries and and cover. -
Page 16: Filter Installation & Replacement
FILTER INSTALLATION & REPLACEMENT ALWAYS! DISCONNECT/TURN OFF WATER SUPPLY | De-pressure the unit push all buttons. Press down To Disconnect To Connect All connections on locking Pull up on the Push pipe are Press-fit ring pipe into ring ENSURE PANEL IS REMOVED (See panel replacement instruction) INSTALLING FILTER (if supplied) REPLACING/REFILLING FILTER Locate the Bridge Fitting installed in... -
Page 17: Cleaning Instructions
CLEANING INSTRUCTIONS QUICK CLEAN - Meet PAT recommends every 2-4 weeks (depending on the location). DETAILED CLEAN - Meet PAT recommends every 6-12 months or 6000LT (whichever is first). Clean and wipe down all external surfaces. Use a scrubbing brush to clean the Use a non-acidic, non-abrasive cleaner and drain mesh. -
Page 18: Smart Technology
SMART TECH | OVERVIEW & INSTRUCTIONS This product is fitted with a 3rd Party Smart Sensor | UC50x Outdoor LoRaWAN® Controller For formal documentation and full instructions on this sensor, refer to www.milesight-iot.com DOWNLOAD THE APP TO YOUR DEVICE (required for access) SENSOR PASSWORD is supplied with To access information on the sensor,... -
Page 19: Solar Lighting
SOLAR LIGHTING | OVERVIEW & INSTRUCTIONS Water stations which are fitted with lighting, should be turned on and checked during the installation process. ACCESSING AND TESTING THE LIGHTING REMOVE THE TOP ASSEMBLY (See panel replacement instructions) I look like this. Solar Top This system is fitted with an automatic low light sensor. - Page 20 Meet PAT™ products must be installed in accordance with the provisions of AS/NZS3500 and any relevant local regulations. Installations not complying with AS/NZS3500 may void the product and performance warranty provisions. All recommendations within this document should be used as a guide only. Users and installers should seek suitable assistance to ensure units comply with all standards and are safe for use.
