Page 1
Cod. Art. Descrizione Gruppo pompa per circuito di riscaldamento non miscelato Pump unit for unmixed circuit 512245250 Pumpengruppe für ungemischten Heizkreis Groupe pompe pour circuit non mélangé Pompunit voor ongemengd circuit Introduzioni per l’installazione, l’uso e la manutenzione Installation, operation and maintenance instructions Installations-, Bedienungs- und Wartungsanleitung Instructions pour l’installation, l’utilisation et l’entretien...
Introduzione e avvertenze generali PACKING LIST N.1 Modulo diretto N.1 Manuale istruzioni N.1 Foglio avvertenze AVVERTENZE GENERALI Consultare attentamente il presente manuale prima di procedere a qualsiasi intervento sull’apparecchiatura. Il costruttore, al fine di adeguare l’apparecchiatura al progresso tecnologico ed a specifiche esigenze di carattere produttivo o di installazione e posizionamento, può decidere, senza alcun preavviso, di apportare su di essa modifiche.
Dati tecnici Dati tecnici Perdita di carico / curva prestazioni Portata consigliata 2260 l/h Temperatura max. 110°C Pressione massima di esercizio 6 bar Temperatura min. 10°C Materiale valvola a sfera/miscelatrice OT CW617N Materiale isolamento EPP 38 g/l Trasmittanza termica (λ 40°C) 0.038 W/mk Classe di reazione al fuoco ISO 3795...
Descrizione del prodotto I moduli diretti sono moduli di distribuzione compatti per impianti termici e di climatizzazione estiva. Il modulo viene fornito standard con mandata a destra ma con semplici operazioni può essere predisposto con mandata a sinistra. Ritorno Mandata impianto impianto Rif.
Page 5
Funzionalità isolamento MODALITA’ RISCALDAMENTO Collocare il tappo A come indicato. Assicurarsi che l’inserto scorrevole B sia posizionato come indicato in figura. MODALITA’ RISCALDAMENTO (periodo invernale) Con ricircolo d’aria per non surriscaldare eccessivamente i componenti elettrici. MODALITA’ RAFFRESCAMENTO Rimuovere il tappo A e collocarlo come indicato. Assicurarsi che l’inserto scorrevole B sia posizionato come in figura.
Installazione Esempio di installazione su collettore Ritorno Mandata Ritorno Mandata Ritorno Mandata impianto impianto impianto impianto impianto impianto Mandata Ritorno primario primario Montaggio su staffa a parete Rif.2 Rif.1 IMPORTANTE! POSIZIONARE IL MODULO IN MANIERA CORRETTA Rif.3 Fissare la staffa alla parete Tagliare la parte posteriore dell’isolamento contrassegnata nell’immagine (Rif.1) Avvitare le viti a brugola e rondelle (Rif.2) nei...
Introduction and general warnings PACKING LIST 1 Direct module 1 Instructions manual 1 Safety sheet GENERAL WARNINGS Consult this manual carefully before carrying out any work on the equipment. The manufacturer may decide to make changes to equipment without prior notice in order to adapt it to technological progress and specific production or installation and positioning requirements.
Technical specifications Technical specifications Pressure drop / performance curve Recommended flow rate 2260 l/h Max. temperature 110 °C Maximum operating pressure 6 bar Min. temperature 10 °C Ball valve/mixing valve material OT CW617N Insulation material EPP 38 g/l Thermal transmittance (λ 40°C) 0.038 W/mk Fire reaction class ISO 3795...
Product description The direct modules are compact distribution modules for heating and summer air conditioning systems. The module is supplied as standard with delivery on the right but with simple operations it can be set up with delivery on the left. System System return...
Insulation function HEATING MODE Place cap A as indicated. Make sure that the sliding insert B is positioned as shown in the figure. HEATING MODE (winter period) With air recirculation to avoid electrical component overheating. COOLING MODE Remove cap A and position it as shown. Make sure that the sliding insert B is positioned as in the figure.
Installation Example of installation on manifold System System System System System System return delivery return delivery return delivery Primary Primary Wall bracket mounting delivery return Ref.2 Ref.1 IMPORTANT! POSITION THE MODULE CORRECTLY Ref.3 Secure the bracket to the wall. Cut the rear part of the insulation as indicated in the image (Ref.1).
Einleitung und allgemeine Warnhinweise PACKLISTE Nr.1 direktes Modul Nr.1 Bedienungsanleitung Nr.1 Warnhinweisblatt ALLGEMEINE WARNHINWEISE Lesen Sie dieses Handbuch sorgfältig durch, bevor Sie Arbeiten an dem Gerät durchführen. Der Hersteller behält sich das Recht vor, das Gerät ohne vorherige Ankündigung zu ändern, um es an den technologischen Fortschritt und an spezifische Produktions- oder Installations- und Positionierungsanforderungen anzupassen.
Technische Daten Technisch Druckabfall / Leistungskurve e Daten Empfohlene Durchflussmenge 2260 l/h Max. Temperatur 110 °C Max. Betriebsdruck 6 bar Min. Temperatur 10 °C Material Kugelhahn/Mischerventil OT CW617N Material Isolierung EPP 38 g/l Wärmedurchgangskoeffizient (λ 40°C) 0.038 W/mk Brandverhaltensklasse ISO 3795 Material der Dichtung SESALIT Anlagenseitige Anschlüsse...
Page 16
Produktbeschreibung Die direkte Module sind kompakte Verteilermodule für Heizungs- und Sommerklimasysteme. Das Modul wird standardmäßig mit einem rechtsseitigen Vorlauf geliefert, kann aber mit einfachen Vorgängen für einen linksseitigen Vorlauf vorbereitet werden. Anlage Anlage Rücklauf Vorlauf Ref. Beschreibung Metallthermometer mit rotem Siebdruck (VORLAUF) mit im Kugelhahn integrierter Tauchhülse, Messskala 0 - 160°C ø...
Page 17
Funktionalität der Isolierung HEIZMODUS Setzen Sie die Kappe A wie gezeigt ein. Stellen Sie sicher, dass der Schiebeeinsatz B wie in der Abbildung gezeigt positioniert ist. HEIZMODUS (Winterperiode) Mit Luftumwälzung, um die elektrischen Komponenten nicht zu stark zu erwärmen. KÜHLMODUS Entfernen Sie die Kappe A und setzen Sie sie wie angegeben ein.
Page 18
Installation Installationsbeispiel an einem Verteiler Anlage Anlage Anlage Anlage Anlage Anlage Rücklauf Vorlauf Vorlauf Vorlauf Rücklauf Rücklauf Vorlauf Rücklauf Primärkreis Primärkreis Montage an der Wandhalterung Rif.2 Rif.1 WICHTIG! DAS MODUL RICHTIG POSITIONIEREN Rif.3 Befestigen Sie die Halterung an der Wand Schneiden Sie den in der Abbildung markierten hinteren Teil der Isolierung ab (Ref.1) Schrauben Sie die Inbusschrauben und...
Introduction et mises en garde générales LISTE DE COLISAGE N.1 Module direct N.1 Manuel d'instructions N.1 Notice de mises en garde MISES EN GARDE GÉNÉRALES Consulter attentivement ce manuel avant toute intervention sur l'appareil. Afin d'adapter l'appareil au progrès technologique et aux exigences spécifiques en termes de production ou d'installation et de positionnement, le constructeur peut décider, sans aucun préavis, d'apporter des modifications sur ce dernier.
Données techniques Données techniques Perte de charge / courbe des performances Débit conseillé 2260 l/h Température max. 110 °C Pression maximum de service 6 bars Température min. 10 °C Matériel robinet à boisseau OT CW617N sphérique/vanne mélangeuse Matériel isolation EPP 38 g/l Transmission thermique (λ...
Description du produit Les modules directs sont des modules de distribution compacts pour les installations de chauffage et de climatisation. Le module est fourni standard avec refoulement à droite mais de simples interventions permettent de le prédisposer avec refoulement à gauche. Circuit de Circuit de retour...
Page 23
Fonction isolation MODALITÉ CHAUFFAGE Placer le couvercle A comme indiqué. S’assurer que la partie coulissante B soit placée comme indiqué sur l’illustration. MODALITÉ CHAUFFAGE (période hivernale) Avec circulation d’air pour ne pas surchauffer excessivement les composants électriques. MODALITÉ FRAÎCHEUR Retirer le couvercle A et le placer comme indiqué. S’assurer que la partie coulissante B soit placée comme indiqué...
Page 24
Installation Exemple d'installation sur collecteur Circuit de Circuit de Circuit de Circuit de Circuit de Circuit de départ retour départ retour départ retour installation installation installation installation installation installation Circuit de Circuit de départ retour Montage sur étrier mural primaire primaire Réf.2 Réf.1...
Page 26
Inleiding en algemene mededelingen PAKLIJST Nr.1 Directe module Nr.1 Handleiding Nr.1 Mededelingenblad ALGEMENE MEDEDELINGEN Bestudeer deze handleiding aandachtig voordat met werkzaamheden aan de apparatuur wordt aangevangen. De fabrikant kan zonder mededeling besluiten om de handleiding te wijzigen als dit voor de aanpassing van de apparatuur aan het technologische proces en aan specifieke installatie-, plaatsings- of productie-eisen noodzakelijk wordt geacht.
Technische gegevens Technisch Ladingverlies / prestatiecurven Aanbevolen debiet 2260 l/h gegevens Max. temperatuur 110°C Maximale bedrijfsdruk 6 bar Min. temperatuur 10°C Materiaal meng-/veiligheidsklep OT CW617N Isolatiemateriaal EPP 38 g/l Warmtedoorlating (λ 40°C) 0.038 W/mk Brandklasse ISO 3795 Materiaal afdichtingen SESALIT Aansluitingen installatiezijde 1”...
Page 28
Productbeschrijving Directe modules zijn compacte distributiemodules voor airco- en verwarmingsinstallaties. De module wordt standaard geleverd met de intrede rechts, maar met een aantal eenvoudige handelingen kan de intrede naar links worden verplaatst. Uittrede Intrede installatie installatie Ref. Beschrijving Metalen thermometer met rode opdruk (INTREDE) met zitting in de veiligheidsklep, meetbereik 0 –...
Page 29
Isolatiefunctie VERWARMEN Sluit de dop A aan volgens de aanwijzingen. Controleer of het schuifelement B is geplaatst zoals op de afbeelding is getoond. VERWARMEN (winterperiode) Met luchtrecirculatie zodat de elektrische onderdelen niet oververhit raken. KOELEN Verwijder de dop A en breng hem aan zoals is getoond. Controleer of het schuifelement B is geplaatst zoals op de afbeelding is getoond.
Page 30
Installatie Voorbeeld van de installatie op een collector Intrede Uittrede Uittrede Intrede Intrede Uittrede installatie installatie installatie installatie installatie installatie Primaire Primaire uittrede intrede Montage op wandbeugel Ref.2 Ref.1 BELANGRIJK! PLAATS DE MODULE OP CORRECTE WIJZE Ref.3 Bevestig de beugel aan de wand Snijd het achterste deel van de isolatie door dat op de afbeelding is aangegeven (Ref.1) Draai de inbusschroeven en onderlegringen...
