Skullcandy STOMP XXL Quick Start Manual

Block party on wheels

Advertisement

Available languages

Available languages

Quick Links

MANUAL (EN)
FRONT PANEL
STOMP XXL
BLOCK PARTY ON WHEELS
EXTENDABLE TROLLEY HANDLE
LED BATTERY INDICATOR
POWER ON / OFF
VOLUME UP / NEXT TRACK
PLAY / PAUSE
VOLUME DOWN / PREVIOUS TRACK
LIGHT SHOW / STROBE LIGHT
STATUS LED INDICATOR
MULTI
BT
TWS
LINK
TM
RESET
MIC
ECHO
VOLUME
AUDIO/2.4A
IN
OUT
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated within 20cm minimum distance
between the radiator & your body.
Canada warning:
- English:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada's licence-exempt RSS(s). Operation is subject to
the following two conditions: This device may not cause interference. This device must accept
any interference, including interference that may cause undesired operation of the device.
- French:
Cet appareil contient des émetteurs/récepteurs exemptés de licence qui sont conformes aux
flux RSS exemptés de licence de Innovation, Science et développement économique Canada.
L'exploitation est soumise aux deux conditions suivantes: Cet appareil ne doit pas causer
d'interférences. Ce dispositif doit accepter toute interférence, y compris toute interférence
pouvant causer un fonctionnement indésirable du dispositif.
MODEL: 2SKSK1852
1 YEAR WARRANTY
Skullcandy.com
info.skullcandy.com/Support.
2024© Skullcandy is a registered trademark Marketed and distributed by
Lifeworks technology Group LLC., New York, NY 10018. USB Type-A™, USB
Type-C™ and USB-C™ are trademarks of USB Implementers Forum. The
Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Lifeworks Technology
Group LLC. is under license. All brands are registered trademarks of their
respective companies. *Actual product may differ slightly from images.
Made in China *Playtime listed is based on playing "M-Noise" at 84dB SPL
(C) slow with lightshow, strobe, and base boost in off mode. Actual playtime
will vary depending on audio content, transmitting device, and listening
conditions.
STICKER PACK
AC POWER INPUT
TROLLEY WHEELS
BLUETOOTH® PAIRING
TWS BUTTON
MULTI-LINK™ BUTTON
FACTORY RESET
MICROPHONE INPUT
MIC ECHO ADJUSTMENT
MIC VOLUME UP/DOWN
AUX 3.5MM INPUT/OUTPUT
USB-A AUDIO INPUT/POWER OUT
USB-C POWER OUT
Packaging Includes:
(1) STOMP™ XXL Party Speaker
(1) 6ft. Power Cord
(1) User Manual
FUNCTIONS
Power ON / OFF:
Press and hold the "O" button for 2s. If not connected to a Bluetooth® device or
connected but idle (not playing audio) the speaker will turn OFF automatically after 15 min.
Play / Pause:
Press the " " button once to play or pause audio.
Volume Up:
Press "+" button to increase the volume.
Volume Down:
Press "-" button to decrease the volume.
Next Track:
Press and hold "+" button for 2s to skip track.
Previous Track:
Press and hold "-" button for 2s to go to last track.
Bluetooth
Pairing:
®
Press and hold the "Bluetooth®" button for 2s to enter Bluetooth® Pairing Mode. The speaker
will disconnect from any paired device and will become available to pair to new devices. The
speaker will stay in pairing mode for 60s, or until connected. Status LED will blink blue while in
Bluetooth® Pairing Mode.
True Wireless Stereo Pairing:
Press the "TWS" button on any two Stomp XXL™ speakers to pair them together and play
audio in stereo. Status LED will be cyan to indicate Right channel and yellow to indicate Left
channel.
Exit True Wireless Stereo Mode:
Press the "TWS" button to exit TWS pairing.
SKDY Multi-link™ Transmitting:
First, connect to the Stomp XXL™ speaker by BT, AUX, or USB-A audio input connection.
Press and hold the "Multi-link(TM)" button for 2s to set the speaker as transmitting. Any
receiving speaker enabled SKDY Multi-link™ will now be able to join. Status LED will be purple.
*When pairing different SKDY speakers together, it's recommended to set the newest
speaker (or the one with the most features) as the transmitting speaker.
SKDY Multi-link™ Mode Receiving:
Single press the "Multi-link™" button to set the speaker as receiving (the speaker will
automatically disconnect from any paired Bluetooth® devices). Status LED will be green. Up
to 99 receiving speakers can be connected to a single transmitting speaker.
Check Battery Status:
The 4 LED indicators show the battery level. Press and hold "+" and "-" buttons together for 1s
to initiate a voice prompt of the battery level.
Light Show Mode
Press and hold the "Light Show" button for 2s to turn the light show ON or OFF. Single press
the "Light Show" button to cycle between different light show modes.
Strobe Light ON/OFF
Double press the "Light Show" button to toggle the strobe light ON or OFF.
Dual-Device Connection:
You can pair two transmitting devices (mobile phones for example) to the Stomp XXL™
speaker at the same time to DJ together. Pause the music on the first device to play a song
from the second device.
Charge Out:
While the speaker is ON, plug a USB-C™ or USB-A cable into the appropriate port to begin
charging your compatible portable device automatically.
CHARGING THE Stomp XXL™
Use the included power cord to connect the speaker to an appropriate power source to
begin charging. The LED indicators will show the battery is charging. When all 4 LEDs are ON
the battery is fully charged.
Warning:
1. To avoid damage to the speaker and battery, it is important to only use a power source
that matches the power requirements listed on the speaker's rating label.
2. To avoid overheating, it's recommended not to place the speaker in direct sunlight,
especially while charging and playing music.
3. (If applicable) where the mains plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable. In order to disconnect the
equipment from the power supply, a disconnection device should be provided. Disconnect
the main plug from the AC outlet when the unit in not it use for extended periods.
Battery status indication (not charging):
0-5% - speaker is OFF all 4 LEDs are OFF
5-10% - 1st LED blinks white, status LED blinks red
10-25% - 1st LED is ON white, other LEDs are OFF
25-50% - 1st + 2nd LEDs are ON white, other LEDs are OFF
50-75% - 1st + 2nd + 3rd LEDs are ON white, other LEDs are OFF
75-100% - All LEDs are ON white
Battery status indication (while charging):
0-25% - 1st LED blinks white, other LEDs are OFF
25-50% - 1st LED is ON white, 2nd LED is blinking.
Other LEDs are OFF
50-75% - 1st + 2nd LEDs are ON white, 3rd LED is blinking.
Other LEDs are OFF
75-99% - 1st + 2nd + 3rd LEDs are ON white, 4th LED is blinking.
Other LEDs are OFF
100% - All 4 LEDs are ON whiteOperating ambient temperature: -10 - 40°C,
Storage and transportation ambient temperature: -20 - 70°C, altitude not higher than 2000m
(air pressure not less than 80kPa).
WARNING:
– replacement of a battery with an incorrect type may defeat a safeguard;
– disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a
battery, may result in an explosion;
– leaving a battery in an extremely high temperature environment, such as sunshine, fire, or
hot surface may result in an explosion or the leakage of flammable liquid or gas;
– a battery subjected to extremely low air pressure may result in an explosion or the leakage
of flammable liquid or gas.
CAUTION
Risk of fire or explosion if the battery is replaced by an incorrect type!
CONNECTION PRIORITY
AUX > USB > BT (Bluetooth®)
To play from an AUX source, simply plug in an AUX cable to the speaker and your audio
source device. It will automatically have priority over USB and BT.
To play from a USB source, plug in a USB flash drive and make sure that AUX is
disconnected. It will automatically have priority over BT (but not over AUX).
To play from BT source, connect a Bluetooth® enabled device and make sure that AUX and
USB are disconnected.
Microphone Proper Use:
HOLD MICROPHONE
HANDLE, NOT GRILLE
[2]
TROUBLESHOOTING
AVOID FEEDBACK (HOWLING)
[3]
Factory Reset:
Press and hold "-" and "+" buttons at the same time for 10s to initiate factory
reset. The speaker will revert to factory settings and all previously paired
devices will be deleted. Status LED will blink between blue and red while
resetting. Alternatively, use a pin to press the "RESET" button.
Speaker is not playing wirelessly:
If the speaker is not playing audio although it's connected to a
Bluetooth™ device, it may be because of the audio connection
priority. Disconnect any AUX or USB-A connections to the
speaker and try again.
SPECIFICATIONS
Bluetooth® Version:5.3
Battery Capacity: 11.1V 4000mAh
Charging Input: AC 110-220V
Playtime: 12 hours (Based on 80dBSPL(c) with light show OFF)
Charging Time: 4.5-5 hours
Operating Range: 10M
Audio Inputs: Bluetooth®, USB-A, Aux 3.5mm
Charging Outputs: USB-C, USB-A
Battery Standby Time: 365 Days
IPX Rating: IPX5 (Splashproof)
EN: SCAN FOR SUPPORT
FR: NUMÉRISER POUR OBTENIR UN SOUTIEN
ES: ESCANEAR PARA OBTENER ASISTENCIA
PL: ZESKANUJ, ABY UZYSKAĆ POMOC
SV: SKANNA FÖR SUPPORT
NL: SCANNEN VOOR ONDERSTEUNING
IT: SCANSIONE PER ASSISTENZA
DE: FÜR SUPPORT SCANNEN
BACK PANEL
Double sided pritning - Accordian Style Booklet
GROOVE
KEY
TAB
[1]
