Z Series
Reach-In Refrigeration
Models:
Standard Refrigerator Models
29" Solid Door
#178Z1RHC
29" Glass Door
#178Z1RGHC
54" Solid Door
#178Z2RHC
54" Glass Door
#178Z2RGHC
Standard Freezer Models
29" Solid Door
#178Z1FHC
54" Solid Door
#178Z2FHC
Note:
Read this manual in its entirety prior to equipment setup, operation, and maintenance.
www.AvantcoRefrigeration.com
User Manual
WiFi-Enabled Refrigerator Models
29" Glass Door
#178Z1RGWMS
29" Solid Door
#178Z1RWMS
54" Glass Door
#178Z2RGWMS
54" Solid Door
#178Z2RWMS
WiFi-Enabled Freezer Models
29" Solid Door
#178Z1FWMS
54" Solid Door
#178Z2FWMS
06/2024
Advertisement
Table of Contents
Related Manuals for Avantco Equipment Z Series
Summary of Contents for Avantco Equipment Z Series
- Page 1 User Manual 06/2024 Z Series Reach-In Refrigeration Models: Standard Refrigerator Models WiFi-Enabled Refrigerator Models 29" Solid Door 29" Glass Door #178Z1RHC #178Z1RGWMS 29" Glass Door 29" Solid Door #178Z1RGHC #178Z1RWMS 54" Solid Door 54" Glass Door #178Z2RHC #178Z2RGWMS 54" Glass Door 54"...
-
Page 2: Table Of Contents
User Manual Z Series Reach-In Refrigerators and Freezers Table of Contents Warnings ..........................3 Installation ..........................4 Electrical ..........................5 Adjusting Temperature .....................5 Automatic Alarms .......................6 Manual Defrost ........................7 Safety and Warning......................8 Operation and Maintenance ...................8 Troubleshooting ........................10 NEMA 5-15P 3029079 3029079 www.AvantcoRefrigeration.com... -
Page 3: Warnings
User Manual Z Series Reach-In Refrigerators and Freezers Warnings DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY TRAINED SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING. PELIGRO – RRIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARA SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO. -
Page 4: Installation
User Manual Z Series Reach-In Refrigerators and Freezers Installation Read this manual thoroughly prior to equipment setup, operation, and maintenance. This unit is intended for use in a temperature-controlled environment of less than 75°F and 60% relative humidity. Before Installation •... -
Page 5: Electrical
User Manual Z Series Reach-In Refrigerators and Freezers • Select a location away from heat and moisture-generating equipment. • Ambient temperatures above 75°F may cause the compressor to malfunction. • Malfunctions due to ambient temperatures above 75°F will void the warranty. -
Page 6: Automatic Alarms
Your Z Series unit compressor will continue to run when the door is left ajar. After 15 minutes of being left ajar, an audible alarm will sound. At the same time, the display board will display “dor.”... -
Page 7: Manual Defrost
User Manual Z Series Reach-In Refrigerators and Freezers Manual Defrost This unit is pre-programmed to run automatic defrost cycles at pre-set intervals. However, if you would like to run a manual defrost cycle at any time, follow the steps below: 1. -
Page 8: Safety And Warning
User Manual Z Series Reach-In Refrigerators and Freezers Safety Warning Pay close attention to the safety notices in this section. Disregarding these notices may lead to serious injury and/or damage to the unit. Attention • To minimize shock and fire hazards, be sure not to overload outlet. Designate one outlet for your unit. -
Page 9: Cleaning The Interior Of The Unit
User Manual Z Series Reach-In Refrigerators and Freezers Cleaning the Interior of the Unit • When cleaning the cabinet interior, use a solvent of warm water and mild soap. • Do not use steel wool, caustic soap, abrasive cleaners, or bleach that may damage the interior finish. -
Page 10: Troubleshooting
User Manual Z Series Reach-In Refrigerators and Freezers Troubleshooting Problem Possible Cause Possible Solution Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker. Power cord unplugged. Plug in power cord. Compressor not running. Thermostat set too high.
