  • Page 1 H610-Swordsman-WIFI User Manual (English)
  • Page 2 Any problem, please feel free to contact us. Contents Specifications ......................1 Overview of Components ..................2 Install CPU & Fan..................... 3 Install Memory......................4 Install Expansion Card....................5 Back Panel Connectors.................... 5 USB 2.0 Port......................5 USB 3.2 Gen 2 Type-A Port................5 VGA Port......................5 Display Port.......................
  • Page 3 Any problem, please feel free to contact us. Specifications H610-Swordsman-WIFI Inte 12th and 13th gen Core i9/i7/i5/i3/Pentium/Celeron LGA 1700 pin series Processor processor Southbridge H610 Chipset Technology Dual channel DDR4 Maximum 64GB (32GB*2) Capacity Memory Slot 2 * DDR4 Display Interface 1 * HDMI;...
  • Page 4 Any problem, please feel free to contact us. Overview of Components Package List: H610-Swordsman-WIFI Motherboard * 1 SATA Cable * 1 I/O Blocking * 1...
  • Page 5 Any problem, please feel free to contact us. Install CPU & Fan Please install the CPU into the CPU socket (LGA 1700) as shown below. Important • Make sure that the motherboard supports the CPU. • Always unplug the power cord from the power outlet before installing or removing the CPU to prevent hardware damage.
  • Page 6 Any problem, please feel free to contact us. Install Memory The motherboard provides 2 DDR4 DIMM slots, and each with a maximum capacity of 32GB. 1. Wrench the latches on both sides of the memory slot outwards. 2. Insert the memory into the slot by aligning it with the notch in the slot. 3.
  • Page 7 Any problem, please feel free to contact us. Install Expansion Card The motherboard provides a PCI Express 4.0 x16 expansion slot. Place the expansion card in an available PCI Express slot and press the expansion card until it is fully inserted into the slot. Important •...
  • Page 8 Any problem, please feel free to contact us. Display Port DisplayPort (DP) delivers high-quality digital imaging and audio. You can use this port to connect your DisplayPort-supported monitor. HDMI Port The HDMI port supports 4K and 1080px. You can use this port to connect your HDMI-supported monitor.
  • Page 9 Any problem, please feel free to contact us. Internal Connectors FPANEL1 Connector F_AUDIO2 Connector This connector allows you to connect audio jacks on the front panel. Important • An incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it.
  • Page 10 Any problem, please feel free to contact us. M.2 Slot Insert your M.2 SSD into the M.2 slot at a 30-degree angle. Secure the M.2 SSD in place with the scr ew. JCMOS: Clear CMOS Jumper Use this jumper to clear the BIOS configuration and reset the CMOS values to factory defaults. To clear the CMOS values, use a metal object like a screwdriver to touch the two pins for a few seconds.
  • Page 11 Any problem, please feel free to contact us. ATXPWR1, PWR12V1: Power Connectors With the use of the power connector, the power supply can provide enough stable power to all the components on the motherboard. Before connecting the power connector, make sure the power supply is turned off and all devices are properly installed.
  • Page 12 Any problem, please feel free to contact us. CFAN, SFAN: Fan Connectors All fan headers on this motherboard are 4-pin. When connecting a fan cable, be sure to connect it in the correct orientation (the black connector wire is the ground wire). Important •...
  • Page 13 Any problem, please feel free to contact us. FUSB2: USB 2.0 Connector The headers conform to USB 2.0 specification. This connector allows you to connect USB 2.0 ports on the front panel. FUSB30_1: USB 3.0 Connector The header conforms to USB 3.0 and USB 2.0 specification. This connector allows you to connect USB 3.0 ports on the front panel.
  • Page 14 Any problem, please feel free to contact us. BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the CMOS on the motherboard. BIOS identifies, configures, tests and connects computer hardware to the OS immediately after a computer is turned on. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters and loading the operating system, etc.
  • Page 15 Any problem, please feel free to contact us. Enter BIOS Setup Entering BIOS Setup When the computer starts up, BIOS enters the self-test process. When the self-test is completed, the following message is displayed: Press DEL key to enter Setup Menu. At this time, Press <Delete>...
  • Page 16 Any problem, please feel free to contact us. H610-Swordsman-WIFI Benutzerhandbuch (Deutsch)
  • Page 17 Any problem, please feel free to contact us. Inhalt Spezifikationen ......................1 Übersicht der Komponenten ................2 Installieren Sie CPU und Lüfter................3 Arbeitsspeicher installieren..................4 Erweiterungskarte installieren.................5 Anschlüsse auf der Rückseite.................. 5 USB 2.0-Anschluss.....................5 USB 3.2 Gen 2 Typ-A-Anschluss................ 5 VGA-Anschluss....................
  • Page 18 Any problem, please feel free to contact us. Spezifikationen H610-Swordsman-WIFI Integrierter Core i9/i7/i5/i3/Pentium/Celeron LGA 1700-Pin-Prozessor der 12. Prozessor und 13. Generation Südbrücke H610 Chipsatz Technologie Dual-Channel DDR4 Maximale 64 GB (32 GB*2) Kapazität Speichersteckplatz 2 * DDR4 Anzeigeschnittstel 1 * HDMI; 1 * VGA; 1 * DP 3 * USB 2.0;...
  • Page 19 Any problem, please feel free to contact us. Übersicht der Komponenten Paketliste: H610-Swordsman-WIFI Mainboard * 1 SATA-Kabel * 1 E/A-Blockierung * 1...
  • Page 20 Any problem, please feel free to contact us. Installieren Sie CPU und Lüfter Bitte installieren Sie die CPU wie unten gezeigt im CPU-Sockel (LGA 1700). Wichtig • Stellen Sie sicher, dass das Motherboard die CPU unterstützt. • Ziehen Sie immer das Netzkabel aus der Steckdose, bevor Sie die CPU installieren oder entfernen, um Hardwareschäden zu vermeiden.
  • Page 21 Any problem, please feel free to contact us. Arbeitsspeicher installieren Das Motherboard bietet 2 DDR4-DIMM-Steckplätze mit jeweils einer maximalen Kapazität von 32 GB. 1. Drehen Sie die Riegel auf beiden Seiten des Speichersteckplatzes nach außen. 2. Setzen Sie den Speicher in den Steckplatz ein, indem Sie ihn an der Kerbe im Steckplatz ausrichten.
  • Page 22 Any problem, please feel free to contact us. Erweiterungskarte installieren Das Motherboard bietet einen PCI Express 4.0 x16-Erweiterungssteckplatz. Platzieren Sie die Erweiterungskarte in einem freien PCI-Express-Steckplatz und drücken Sie auf die Erweiterungskarte, bis sie vollständig in den Steckplatz eingesetzt ist. Wichtig •...
  • Page 23 Any problem, please feel free to contact us. VGA-Anschluss VGA (Video Graphics Array) unterstützt analoge Videosignalübertragung, hohe Auflösung, schnelle Anzeigerate und satte Farben. Display-Anschluss DisplayPort (DP) liefert hochwertige digitale Bilder und Audio. Sie können diesen Anschluss verwenden, um Ihren DisplayPort-unterstützten Monitor anzuschließen. HDMI-Anschluss Der HDMI-Anschluss unterstützt 4K und 1080px.
  • Page 24 Any problem, please feel free to contact us. Interne Anschlüsse FPANEL1-Anschluss F_AUDIO2-Anschluss Mit diesem Anschluss können Sie Audiobuchsen auf der Vorderseite anschließen. Wichtig • Eine falsche Verbindung zwischen dem Modulanschluss und dem Motherboard-Header führt dazu, dass das Gerät nicht funktioniert oder sogar beschädigt wird. SATA1~4: SATA 3.0-Anschlüsse Diese SATA 3.0-Anschlüsse sind SATA 6 Gb/s-Schnittstellenanschlüsse.
  • Page 25 Any problem, please feel free to contact us. M.2-Steckplatz Setzen Sie Ihre M.2-SSD in einem 30-Grad-Winkel in den M.2-Steckplatz ein. Befestigen Sie die M.2-SSD mit der Schraube. JCMOS: CMOS-Jumper löschen Verwenden Sie diesen Jumper, um die BIOS-Konfiguration zu löschen und die CMOS-Werte auf die Werkseinstellungen zurückzusetzen.
  • Page 26 Any problem, please feel free to contact us. ATXPWR1, PWR12V1: Stromanschlüsse Mit der Verwendung des Stromanschlusses kann das Netzteil alle Komponenten auf dem Motherboard ausreichend stabil mit Strom versorgen. Stellen Sie vor dem Anschließen des Netzsteckers sicher, dass die Stromversorgung ausgeschaltet und alle Geräte ordnungsgemäß...
  • Page 27 Any problem, please feel free to contact us. CFAN, SFAN:: Lüfteranschlüsse Alle Lüfteranschlüsse auf diesem Motherboard sind 4-polig. Achten Sie beim Anschließen eines Lüfterkabels darauf, es in der richtigen Ausrichtung anzuschließen (das schwarze Anschlusskabel ist das Erdungskabel). Wichtig • Die Geschwindigkeitsregelungsfunktion erfordert die Verwendung eines Lüfters mit Lüftergeschwindigkeitsregelung.
  • Page 28 Any problem, please feel free to contact us. F_USB2: USB 2.0-Anschluss Die Header entsprechen der USB 2.0-Spezifikation. Dieser Anschluss ermöglicht Ihnen den Anschluss von USB 2.0-Anschlüssen auf der Vorderseite. FUSB30_1: USB 3.0-Anschluss Der Header entspricht der USB 3.0- und USB 2.0-Spezifikation. Über diesen Anschluss können Sie USB 3.0-Anschlüsse an der Vorderseite anschließen.
  • Page 29 Any problem, please feel free to contact us. BIOS-Setup Das BIOS (Basic Input and Output System) zeichnet die Hardwareparameter des Systems im CMOS auf der Hauptplatine auf. Das BIOS identifiziert, konfiguriert, testet und verbindet die Computerhardware unmittelbar nach dem Einschalten eines Computers mit dem Betriebssystem.
  • Page 30 Any problem, please feel free to contact us. Rufen Sie das BIOS-Setup auf Wenn der Computer hochfährt, tritt das BIOS in den Selbsttestprozess ein. Wenn der Selbsttest abgeschlossen ist, wird die folgende Meldung angezeigt: Drücken Sie die DEL-Taste, um das Setup-Menü aufzurufen. Drücken Sie zu diesem Zeitpunkt die Taste <Delete> , um das BIOS-Setup aufzurufen.
  • Page 31 Any problem, please feel free to contact us. H610-Swordsman-WIFI Manual do usuário (Português)
  • Page 32 Any problem, please feel free to contact us. Conteúdo Especificações ......................1 Visão geral dos componentes ................2 Instalar CPU e Ventilador..................3 Instalar memória......................4 Instalar Placa de Expansão..................5 Conectores do painel traseiro................. 5 Porta USB 2.0....................5 Porta USB 3.2 Gen 2 tipo A................5 Porta VGA......................5 Porta DP......................
  • Page 33 Any problem, please feel free to contact us. Especificações H610-Swordsman-WIFI Processador Intel Core i9/i7/i5/i3/Pentium/Celeron LGA 1700 pin da 12ª e 13ª Processadora geração ponte sul H610 Chipset Tecnologia DDR4 de canal duplo Capacidade máxima 64GB (32GB*2) Slot de memória 2 * DDR4 Interface de Exibição...
  • Page 34 Any problem, please feel free to contact us. Visão geral dos componentes Lista de pacotes: Placa Mãe H610-Swordsman-WIFI * 1 Cabo SATA * 1 Bloqueio de E/S * 1...
  • Page 35 Any problem, please feel free to contact us. Instalar CPU e Ventilador Instale a CPU no soquete da CPU (LGA 1700) conforme mostrado abaixo. Importante • Certifique-se de que a placa-mãe suporta a CPU. • Sempre desconecte o cabo de alimentação da tomada antes de instalar ou remover a CPU para evitar danos ao hardware.
  • Page 36 Any problem, please feel free to contact us. Instalar memória A placa-mãe oferece 2 slots DDR4 DIMM, cada um com capacidade máxima de 32 GB. 1. Aperte as travas em ambos os lados do slot de memória para fora. 2. Insira a memória no slot alinhando-a com o entalhe no slot. 3.
  • Page 37 Any problem, please feel free to contact us. Instalar Placa de Expansão A placa-mãe fornece um slot de expansão PCI Express 4.0 x16. Coloque a placa de expansão em um slot PCI Express disponível e pressione a placa de expansão até que esteja totalmente inserida no slot. Importante •...
  • Page 38 Any problem, please feel free to contact us. Porta DP DisplayPort (DP) oferece imagem digital e áudio de alta qualidade. Você pode usar esta porta para conectar seu monitor compatível com DisplayPort. Porta HDMI A porta HDMI suporta 4K e 1080px. Você pode usar esta porta para conectar seu monitor compatível com HDMI.
  • Page 39 Any problem, please feel free to contact us. Conectores Internos Conector FPANEL1 Conector F_AUDIO2 Este conector permite conectar conectores de áudio no painel frontal. Importante • Uma conexão incorreta entre o conector do módulo e o header da placa-mãe fará com que o dispositivo não funcione ou até...
  • Page 40 Any problem, please feel free to contact us. Ranhura M.2 Insira seu SSD M.2 no slot M.2 em um ângulo de 30 graus. Prenda o SSD M.2 no lugar com o parafuso. JCMOS1: Limpar Jumper CMOS Use este jumper para limpar a configuração do BIOS e redefinir os valores do CMOS para os padrões de fábrica.
  • Page 41 Any problem, please feel free to contact us. ATXPWR1, PWR12V1: Conectores de alimentação Com o uso do conector de alimentação, a fonte de alimentação pode fornecer energia estável suficiente para todos os componentes da placa-mãe. Antes de conectar o conector de alimentação, certifique-se de que a fonte de alimentação esteja desligada e que todos os dispositivos estejam instalados corretamente.
  • Page 42 Any problem, please feel free to contact us. CFAN/SFAN: Conectores do Ventilador Todos os conectores de ventoinha nesta placa-mãe são de 4 pinos. Ao conectar um cabo de ventilador, certifique-se de conectá-lo na orientação correta (o fio conector preto é o fio terra).
  • Page 43 Any problem, please feel free to contact us. FUSB2: Conector USB 2.0 Os cabeçalhos estão em conformidade com a especificação USB 2.0. Este conector permite conectar portas USB 2.0 no painel frontal. FUSB30_1: Conector USB 3.0 O cabeçalho está em conformidade com as especificações USB 3.0 e USB 2.0. Este conector permite conectar portas USB 3.0 no painel frontal.
  • Page 44 Any problem, please feel free to contact us. Configuração da BIOS O BIOS (Basic Input and Output System) registra os parâmetros de hardware do sistema no CMOS da placa-mãe. O BIOS identifica, configura, testa e conecta o hardware do computador ao sistema operacional imediatamente após o computador ser ligado. Suas principais funções incluem conduzir o autoteste de inicialização (POST) durante a inicialização do sistema, salvar os parâmetros do sistema e carregar o sistema operacional, etc.
  • Page 45 Any problem, please feel free to contact us. Entrar na configuração do BIOS Quando o computador inicializa, o BIOS entra no processo de autoteste. Quando o autoteste é concluído, a seguinte mensagem é exibida: Pressione a tecla DEL para entrar no Menu de Configuração.
