Summary of Contents for Warehouse DL01P12
- Page 1 USE AND CARE GUIDE 25 INCH CEILING FAN DL01P12...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..........2 Assembly..........8 Assembly—Hanging the fan..9-10-11-12 Safety Information ..........3 Operation..........13 Warranty ..............4 Operation(continued)......13 Pre-Installation(continued) ........4 Care and Cleaning........14 Pre-Installation(continued) ........5 6 Troubleshooting........14 Installation.............7... -
Page 3: Safety Information
Safety Information INTSTRUCTIONS READ AND SAVE THESE 1. To reduce the risk of electric shock, ensure the electricity WARNING: To Reduce The Risk Of Personal Injury,Do Not has been turned off at the circuit breaker or fuse box Bend The Blade Brackets When Installing The Brackets, before you begin. -
Page 4: Warranty
Warranty The supplier warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a lifetime after the date of purchase by the original purchaser. The supplier warrants that the light kit, excluding any glass, to be free from defects in workmanship and material at the time of shipment from the factory for a period of three years after the date of purchase by the original purchaser. -
Page 5: Hardware Included
Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size . Description Quantity Part Setscrew(preassembled) Remote control holder mounting screw(not to scale) Collar setscrew (preassembled) Clevis pin (preassembled) Cotter pin (preassembled) Cross pin (preassembled) 1.5V AAA Battery Expansion bolt(not to scale) Hanger bracket mounting screws(not to scale) -
Page 6: Pre-Installation(Continued)
Pre-Installation (continued) PACKAGE CONTENTS Description Description Part Part Quantity Quantity Mounting bracket (preassembled) Lamp body Canopy Receiver Coupling ring(preassembled) Remote control Remote control holder Hanger ball/downrod assembly Coupling cover Glass shade... -
Page 7: Installation
Installation MOUNTING OPTIONS WARNING: To reduce the risk of fire, electric shock, or NOTE: You may need a longer downrod to maintain proper personal injury, mount the fan to an outlet box marked blade clearance when installing on a steep, sloped ceiling. acceptable for fan support using the screws provided with the The maximum angle allowable is 18°... -
Page 8: Assembly
Assembly 1.Install the suspension system components 1. Insert the ball/downrod (B) through the canopy(C) and canopy bottom cover (D), and then slide the decorative motor collar cover (E) onto the end of the ball/downrod(B). Make sure the slots on the canopy (C) are on top. 2.Assembling the fan WARNING: Failure to properly install the locking pin could result in the fan becoming... -
Page 9: Assembly-Hanging The Fan
Assembly— Hanging the Fan 3.Description of mounting bracket 1.Lossen the two outlet boxscrews in the WARNING: To reduce the risk of fire,electric shock or other outlet box. personal injury, mount the fan only to an outlet box or Supporting system marked acceptable for fan support and 2.Pass the 120-Volt supply wires through use the mounting screws provided with the outlet box. -
Page 10: Install The Light Bulb
Assembly— Hanging the Fan (continued) 4.Install the light bulb 1.Install the six G9 bulbs by WARNING :The G9 The light bulb screwing them into the light MAX 25W Type C bulb*6PCS. bulb sockets. 2.Take the outer lamp holder ring out, install the glass shade on the lamp holder in turn, and tighten the lamp holder ring again. -
Page 11: Making The Electrical Connections
Assembly— Hanging the Fan (continued) 6. Making the electrical connections WARNING: To avoid possible electrical Shock turn WARNING: Check to see that all connections are tight, the electricity off at the main fuse box before wiring. including ground, and that no bare wire is visible at the If you feel you do not have enough electrical wiring connect Terminal blocks,except for the ground wire. - Page 12 Assembly— Hanging the Fan (continued) 7. How to install the canopy ring cover 1.Align the top cover (B)with the hole knob of the mounting bracket (A)and tighten with screws. Slide the lower cover (C) upwards until the lower cover (B) is firmly sucked.
-
Page 13: Operation
Operation REMOTE CONTROL OPERATING INSTRUCTIONS 1.Fan button.Press and release the button to turn the fan on off Fan off. The fan memory function will store the current setting for the next time the fan is in use. 2.Light functions Press and release one time will turn the light on or of 3.Speed functions Number 1/2/3/4/5/6, speed button. -
Page 14: Care And Cleaning
Care and Cleaning Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. Because of the fan's natural movement, some connections may become loose over time. It is not necessary to remove the fan from the ceiling. Clean your fan periodically.
