Cool Gear CG-10XU3CPD Product Manual

10 & 20 port usb-c 3.2 gen 1 industrial power delivery charging hubs w/ esd surge protection & port status leds

Hide thumbs

Quick Links

Download this manual

10 & 20 Port USB-C 3.2 Gen 1 Industrial

Power Delivery Charging Hubs

w/ ESD Surge Protection & Port Status LEDs

Model Number:

CG-10XU3CPD / CG-20XU3CPD

Product Manual

Coolgear, Inc.

Version: 1

Date: 2024-07-16

6. Charging & Syncing

7. Daisy-Chain (Cascading)

8. Additional Information

Revision History

Revision

Date

1.0

2024-07-16

Comments

First Release

Need help?

Do you have a question about the CG-10XU3CPD and is the answer not in the manual?

Questions and answers

Summary of Contents for Cool Gear CG-10XU3CPD

Page 1: Table Of Contents
10 & 20 Port USB-C 3.2 Gen 1 Industrial Power Delivery Charging Hubs w/ ESD Surge Protection & Port Status LEDs Model Number: CG-10XU3CPD / CG-20XU3CPD Product Manual Coolgear, Inc. Version: 1 Date: 2024-07-16 Table of Contents 1. Introduction 2. Speciﬁcations 3.
Page 2: Introduction
ON) if it idles without connected devices. Manually turn on the power switch either for a single unit or cascaded connection to start charging again. Supports connection of up to 10 or 20 USB 3.2 Gen 1 devices (CG-10XU3CPD) or up ✔...
Page 3: Specifications
10 & 20 Port Charging Hubs – Product Manual 2. Speciﬁcations Model No. USB-C1030PD USB-C2030PD USB Specification USB 3.2 Gen1 / 2.0 / 1.1 compliant Data Transfer Rate 1.5M / 12M / 480M / 5Gbps Current per Port 5V 3A / 9V 3A / 12V 2.25A / 15V 1.8A max. (27W) SYNC Mode Charging USB PD 2.0 / USB PD 3.0 (PPS) / QC 2.0 / QC 3.0 / USB...
Page 4: Connector Layouts
10 & 20 Port Charging Hubs – Product Manual 3. Connector Layouts 10-Port Charging Hub | CG-10XU3CPD <Front View> <Rear View> 20-Port Charging hub <Front View> Need help? Visit: coolgear.com/support...
Page 5 10 & 20 Port Charging Hubs – Product Manual <Rear View> USB Ports - Allows connecting iOS, Android devices and MacBook Air, MacBook Pro or Chromebook etc. ● Beware that this unit does not require a host computer connected to the hub for it to charge compatible devices.
Page 6: Rack Mounting
10 & 20 Port Charging Hubs – Product Manual 4. Rack Mounting To install, attach the mounting brackets to the unit’s side panels (one on each side) and secure them with the screws provided. Use the mounting brackets and screws onto rack. User may install on the applicable cabinet, rack environments such as a cage or trolley cart.
Page 7: Connection
10 & 20 Port Charging Hubs – Product Manual 5. Connection (1) To turn off the power switch. <Front Panel> (1) Plug the power adaptor to the unit’s power jack. (2) Put the plug of power adaptor into the wall outlet.
Page 8 10 & 20 Port Charging Hubs – Product Manual (1) Turn on the power switch. <Front Panel> (2) Using the USB 3.2 Gen1 Type C male to male cable provided and connects the USB Type C end on the unit. (3) Using the USB 3.2 Gen1 Type C male to male cable end and connects to your host computer.
Page 9: Charging & Syncing
10 & 20 Port Charging Hubs – Product Manual 6. Charging & Syncing Please follow below ways for charging or syncing USB Type C devices. (1) Follows the step of connection with host computer, and connects host computer with the unit.
Page 10 10 & 20 Port Charging Hubs – Product Manual (3) The Green Energy function When charging is at Charge mode; the Type C charging hub designed with the Green Energy function (push button at the rear panel) may cut off the power when all the charging is finished.
Page 11: Daisy-Chain (Cascading)
10 & 20 Port Charging Hubs – Product Manual 7. Daisy-Chain (Cascade) Connection The 10 / 20-Port Type C charging hub can extend another unit for Daisy-chain (Cascade) connection, the 2 unit can sync simultaneously as well. ● Maximum 2 units can be connected. (It allows connecting or charging maximum up to 20 / 40 USB Type C devices simultaneously.) ●...
Page 12 10 & 20 Port Charging Hubs – Product Manual (3) Plug the power adaptor to the power jack of the 2 unit. (4) Put the plug of power adaptor into the wall outlet. <Rear Panel> (5) Turn on the power switch of the 2 unit.
Page 13: Additional Information
10 & 20 Port Charging Hubs – Product Manual 8. Additional Information The 10 / 20-Port Type C Charging Hub may start/cut off the fans automatically when the unit temperature goes higher/lower limits. (Not recommend putting the unit at places of high temperature such as computer facilities, boiler/steam room, glass workshop, casting work, kiln plants etc.) ●...
Page 14 10 & 20 Port Charging Hubs – Product Manual This product requires external power source to function. If the power Notes LED is not illuminating after connecting, check that the power source is connected to the hub correctly, and is powered on. Read the entire Product Manual before implementing this ●...
Page 15 10 & 20 Port Charging Hubs – Product Manual otherwise applicable to new parts. THE FOREGOING DESCRIBES COOLGEAR’S SOLE LIABILITY, AND YOUR SOLE REMEDY, FOR ANY BREACH OF WARRANTY. IF YOU DO NOT AGREE WITH THE TERMS OF THIS LIMITED WARRANTY, YOU MUST RETURN THE PRODUCTS UNUSED AND IN THEIR ORIGINAL CONTAINERS TO YOUR ORIGIN OF PURCHASE.

This manual is also suitable for:

Cg-20xu3cpd Usb-c1030pd Usb-c2030pd
