PLASMA DISPLAY
PDP-503PE
PDP-503PU
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Type
PDP-503PE
?
WYVI6
−
KUC
This product is component of system.
Component
Plasma Display System
Media Receiver
Plasma Display
For details, refer to "Important symbols for good services".
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
c
PIONEER CORPORATION 2002
Model
PDP-503PU
−
AC220 - 240V
?
AC120V
System
PDP-503HDE
PDP-R03E
PDP-503PE
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
Power Requirement
Service Manual
PDP-5030HD
PDP-R03E : ARP3110
PDP-R03U
PDP-R03U : ARP3113
ARP3107
PDP-503PU
ARP3108
ORDER NO.
ARP3107
Remarks
Remaks
This service manual
T – IZE JAN. 2002 Printed in Japan
