PERTRONIC F16e IN-PANEL
1. Installation
a. Install CTU on to Pertronic F16e Fire Alarm Panel Masterboard using supplied
stand-offs
2. Data Interface Connection
a. Connect 5 wire loom (SGD Ribbon) on CTU board C2 connector (cable to the
right)
b. Connect to F16e Masterboard 5 wire loom connector (cable to the bottom)
3. Mains Power Supply (24v DC)
a. Connect one end of supplied 2 wire cable in to DC input on CTU
b. Connect to the 24v DC output on the F16e Masterboard
4. Backup CTU Battery (6v 1.3ah)
a. Connect battery leads in to BATT input on CTU
b. Attach to 6v 1.3ah battery placed behind F16e Masterboard batteries
c. Note light will momentarily illuminate red when charging or running on battery
5. CTU Aerials
a. Dual aerials required. Connect aerial flyleads/cables to both the Main and
Diversity connectors on the CTU
i. Dome Antenna – Run cabling through top of F16e panel and mount
ii. Patch Antenna - Run cabling through top of F16e panel and mount
6. Commissioning Tests
a. Comms light illuminates solid green to show CTU is connected to the cellular
network
b. Contact office on 03 341 0464 to test and commission the CTU and complete
the connection to Fire & Emergency NZ.
M:\General\Technical Info\Pertronic\Pertronic F16e In Panel Instructions\Pertronic F16e In Panel CTU Installation
v0.1.docx
CTU INSTALLATION
following '4G LTE Aerial Installation' recommendations.
following '4G LTE Aerial Installation' recommendations (approx. 150-
200mm apart). Temporarily fix aerials to window ready for commission
testing.
