Pertronic F4 Installation

PERTRONIC F4 IN-PANEL
1. Installation
a. Connect 5 wire loom (SGD Ribbon) on F4 Masterboard (cable to the left)
b. Install CTU on to Pertronic F4 Fire Alarm Panel Masterboard using supplied
stand-offs
c. Screw AC:DC Supply Board to F4 Masterboard earth stud
2. Data Interface Connection
a. Connect 5 wire loom (SGD Ribbon) on CTU board C2 connector (cable to the
right)
3. Mains Power Supply (12v DC)
a. Connect 2 wire power cable from DC input on CTU to 2 pin AC:DC Supply Board
b. Connect 2 wire transformer cable to 3 pin AC:DC Supply Board
c. Connect 3 pin plug from AC:DC Supply Board to F4 Masterboard
4. Backup CTU Battery (6v 1.3ah)
a. Connect battery leads in to BATT input on CTU
b. Attach to 6v 1.3ah battery placed under Masterboard
c. Note light will momentarily illuminate red when charging or running on battery
5. CTU Aerials
a. Dual aerials required. Connect aerial flyleads/cables to both the Main and
Diversity connectors on the CTU
i. Fixed Antenna – Install bulkheads at top of panel following '4G LTE Aerial
ii. Cabled Antenna - Run cabling through top of F4 panel and mount
6. Commissioning Tests
a. Comms light illuminates solid green to show CTU is connected to the cellular
network
b. Contact office on 03 341 0464 to test and commission the CTU and complete
the connection to Fire & Emergency NZ.
M:\General\Technical Info\Pertronic\Pertronic F4 In Panel Instructions\Pertronic F4 In Panel CTU Installation
v0.1.docx
CTU INSTALLATION
Installation' recommendations (approx. 150-200mm apart). Mount fixed
aerials on top of panel vertically using 2x 100mm extension flyleads.
following '4G LTE Aerial Installation' recommendations (approx. 150-
200mm apart). Temporarily fix aerials to window ready for commission
testing.
