- Page 1 TN0041A User Manual Car Audio Model Name Model Number TN0041A Index 1-Rating 2-Button function spec 3-Bluetooth Device Pairing Procedure DENSO TEN CONFIDENTIAL...
- Page 2 1.Rating Item Contents RATED VOLTAGE 12.0V negative ground LOAD IMPEDANCE 8Ω BACK UP CURRENT 1mA OR LESS RATED CURRENT 3.0A OR LESS (VCC =14.4V 0.5W Output) DENSO TEN CONFIDENTIAL...
- Page 3 2. Button Function Spec DENSO TEN CONFIDENTIAL...
- Page 4 Select the source FUNCTION 設定モードの選択 Select to the Function setting mode. FUNCTIONモードへの移行 Move to FUNCTION mode ⑫ FUNC FUNCTIONモードの解除 Release to FUNCTION mode FUNCTIONモードの解除 － Release to FUNCTION mode ③ ∨ ソース切替モードの解除 － Release to source change mode DENSO TEN CONFIDENTIAL...
- Page 5 Below 0.8sec 0.8sec以上1.5sec 未満 ③ ∨ SEEK DOWN Over 0.8sec and Below 1.5sec 1.5sec以上 － Non-Stop SEEK DOWN Over 1.5sec P.CHの呼び出し 1.7sec未満 Call preset channel. Below 1.7sec ⑤～ Preset 1～6 ⑩ P.CHへの書込み 1.7sec以上 Write preset channel. Over 1.7sec DENSO TEN CONFIDENTIAL...
- Page 6 Release list category select mode (During Category selection mode.) ③ ∨ 1階層上がる（ﾘｽﾄ選択ﾓｰﾄﾞ中） 0.8sec未満 Back to the previous hierarchy. Below 0.8sec (During list selection mode.) 通常再生モードへの移行（ﾘｽﾄ選択ﾓｰﾄﾞ中） 0.8sec以上 Move to normal playback mode. Over 0.8sec (During list selection mode.) DENSO TEN CONFIDENTIAL...
- Page 7 － ⑫ FUNC Switching the TEXT page Over 0.8sec TEXT切替モードの解除 － － Release TEXT change mode. ⑬ LIST 0.8sec以上 TEXT切替モードへの移行 － Over 0.8sec Move to TEXT change mode. TEXT切替モードの解除 － － ③ ∨ Release TEXT change mode. DENSO TEN CONFIDENTIAL...
- Page 8 AUX部操作機能 AUX Part Operation Function 釦名称 時間 機能 BEEP Button Name Time Function TURN ⑪ (Rotary) Mini Jack Volume Control DENSO TEN CONFIDENTIAL...
- Page 9 TELモードの解除 Release TEL mode 送話音量UP － － MIC Volume UP トーン送出 ② ∧ － － Tone Sending 入力桁の切替 － － Switch input digit 送話音量DOWN － － MIC Volume DOWN ③ ∨ 入力文字の削除 － － Delete input character DENSO TEN CONFIDENTIAL...
- Page 10 Switching the TEXT page Over 0.8sec 電話番号マニュアル入力モードの解除 － － Release phone number manual input mode トーンデータマニュアル入力モードの解除 － － ③ Release tone data manual input mode ∨ 履歴選択リストの解除 － － Release history select list TELモードの解除 － － Release TEL mode DENSO TEN CONFIDENTIAL...
- Page 11 For Bluetooth devices not supporting Secure Simple Pairing (SSP): Enter the passkey into the Bluetooth device. For Bluetooth devices supporting Secure Simple Pairing (SSP): Select "Yes" to register the Bluetooth device. ・ Depending on the Bluetooth device type, registration may perform automatically. DENSO TEN CONFIDENTIAL...
- Page 12 FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body. Type：TN0041A Car Audio DENSO TEN AMERICA Limited 30155 Hudson Dr. Novi, MI 48377, U.S.A 1(734)414-6620 DENSO TEN CONFIDENTIAL...
