- Page 1 TN0012A Operation Manual Model name Car Audio Model No TN0012A Page Index 1-Rating 2-Button Function Spec 3-Radio operation procedure 4-Operating manual (Bluetooth/Handsfree) 5-FCC Operating manual Requirement DENSO TEN CONFIDENTIAL (1/6)
- Page 2 RATED VOLTAGE 12.0V(10.5～16.0V)-ground LOAD IMPEDANCE 4Ω BACK UP CURRENT 2.1mA or less 4.0Ａ or less RATED CURRENT (Vcc=13.2V 0.5W output) AM TUNING RANGE 531 - 1602 kHz (9kHz step) FM TUNING RANGE 87.5 - 108MHz （50kHz step) DENSO TEN CONFIDENTIAL (2/6)
- Page 3 2-Button Function Spec ■AUDIO controls Button No. Button Name Operation ① HOME Transition to home screen Push: Audio ON/OFF ② POWER/VOLUME Turn Right: Volume Up Turn Left: Volume Down ③ BACK Transition to previous screen DENSO TEN CONFIDENTIAL (3/6)
- Page 4 Push this button ⑤下記画面に遷移したら、”<”釦 若しくは、”>”釦を押下してください。 これで、SEEKが始まります。 Confirm that the screen is changed as below, Please push down the ”<”button or ”>”button. This will start to SEEK. Push this button Push this button ※AM/DABモードも同様の手順です。 ※Same as FM/DAB mode. DENSO TEN CONFIDENTIAL (4/6)
- Page 5 ”Connection Completed” is displayed if completed. ⑤”Setting”ボタンを押して、SETTINGS画面に遷移させます。 Please press the "Setting" button on the face panel to move to Settings screen Push this button ⑥”Settings”画面に遷移することを確認し、画面上の"Bluetooth"釦を選択。 Confirm if ”Settings” screen is displayed, select the ”Bluetooth” button on the display. Push this button DENSO TEN CONFIDENTIAL (5/6)
-
Page 6: Fcc Warning
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. DENSO TEN CONFIDENTIAL (6/6)
