KOSTAD UNITY 150 Manual

Hide thumbs Also See for UNITY 150:

Advertisement

Quick Links

Download this manual
MANUAL
UNITY CHARGER
UNITY 150 – 360
EN V1.0
11/2023

Advertisement

loading
Need help?

Need help?

Do you have a question about the UNITY 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KOSTAD UNITY 150

Summary of Contents for KOSTAD UNITY 150

  • Page 1 MANUAL UNITY CHARGER UNITY 150 – 360 EN V1.0 11/2023...
  • Page 3 Technical data ....................................30 Technical data User interface ........................31 Configuration ................................. 31 General ..................................31 Directives and standards ..........................32 3.4.1 Guidelines ................................32 3.4.2 Standards ................................. 32 3.4.3 Standards relating to electromagnetic compatibility ................. 32 UNITY 150-360 Description 11/2023 V1.0...
  • Page 4 Cooling ..................................52 7.2.2.2 Impact protection ..............................53 AC - alternating current connection ......................54 7.3.1 Mains-side voltage and power supply ......................54 7.3.2 Equipotential bonding on site ........................54 7.3.3 Connection concept ............................54 UNITY 150-360 Description 11/2023 V1.0...
  • Page 5 Replacing the charging cable .......................... 95 12.2.2.1 Replacing the CCS type 2 charging cable with / without liquid cooling ........95 12.2.3 Checking the front door for standing water ................... 97 13 Troubleshooting ....................................99 UNITY 150-360 Description 11/2023 V1.0...
  • Page 6 Table of contents 14 Decommissioning and disposal .............................. 100 14.1 Decommissioning .............................. 100 14.2 Disposal .................................. 101 15 Notes ........................................ 102 UNITY 150-360 Description 11/2023 V1.0...
  • Page 7 This document is the operating manual for the modular KOSTAD charging stations UNITY 150/180/240/300/360. This document is part of the KOSTAD charging station and must be kept with the product. Read this document before carrying out any work on the charging station.
  • Page 8 The target groups of this document are persons who are responsible for the following activities. · Planning and preparation for installation and operation · Installation · Commissioning and decommissioning · Operation · Maintenance · Troubleshooting UNITY 150-360 Description 11/2023 V1.0...
  • Page 9 Potentially imminent danger Indicates an imminent danger that can lead to death or serious injury if not avoided. • Instruction 1 to avoid hazards • Instruction 2 to avoid hazards • Instruction n to avoid hazards UNITY 150-360 Description 11/2023 V1.0...
  • Page 10 CAUTION Potentially imminent danger Indicates an imminent danger that can lead to minor injuries if not avoided. • Instruction 1 to avoid hazards • Instruction 2 to avoid hazards • Instruction n to avoid hazards UNITY 150-360 Description 11/2023 V1.0...
  • Page 11 Danger of falling parts Draws attention to the risk of being hit by falling parts. Warning of falling parts Draws attention to the danger of falling parts. Risk of slipping Indicates slippery surfaces. Table 3: Warning symbols UNITY 150-360 Description 11/2023 V1.0...
  • Page 12 The last step of an instruction is always followed by the statement that the action is complete. 1. Perform the first step. [Figure] 2. Perform the first step. [Figure] 3. Perform the third step. [Figure] The plot is complete. UNITY 150-360 Description 11/2023 V1.0...
  • Page 13 Brands All designations marked with the ® trademark symbol are registered trademarks of KOSTAD Steuerungsbau GmbH. The other designations in this document may be trademarks whose use by third parties for their own purposes may infringe the rights of the owner.
  • Page 14 We have checked the contents of this publication for compliance with the hardware and software described. Nevertheless, deviations cannot be ruled out, so that we cannot guarantee complete conformity. The information in this publication is checked regularly and any necessary corrections are included in subsequent editions. UNITY 150-360 Description 11/2023 V1.0...
  • Page 15 Light Emitting Diodes Measurement Instruments Directive Near Field Communication Normal zero point OCPP Open Charge Point Protocol Personal protective equipment RFID Radio frequency identification Subscriber Identity/Identification Module Software Wide Area Network WiFi Wireless Fidelity Table 6: Abbreviations UNITY 150-360 Description 11/2023 V1.0...
  • Page 16 General risk of electric shock. Damaged cables, exposed wires, uncovered cables, electrical components inside the housing. • Unity must be earthed via a fixed wiring system or an appliance earthing conductor. • Safety stickers on protective covers and components. UNITY 150-360 Description 11/2023 V1.0...
  • Page 17 • Wear suitable PPE. CAUTION Person hit by equipment Weight of charging cable and plug - drop the plug/cable on your feet. • Pay attention to the warnings on the Unity. UNITY 150-360 Description 11/2023 V1.0...
  • Page 18 Ensure communication between the crane operator and assembly personnel. • Wear suitable PPE. WARNING Squeeze Unity not correctly mounted on foundation - risk of falling over. • Follow the instructions in the documentation for installation. UNITY 150-360 Description 11/2023 V1.0...
  • Page 19 • Use the tools correctly. WARNING Eye injury Risk of an eye injury The ends of protruding power cables can cause eye injuries. • Wear suitable PPE. UNITY 150-360 Description 11/2023 V1.0...
  • Page 20 Fit the edge protection. • Wear suitable PPE. CAUTION Cut injury Risk of a cut injury When drilling the anchor holes, cuts can occur due to improper handling of the drill. • Use the tools correctly. UNITY 150-360 Description 11/2023 V1.0...
  • Page 21 Connecting the network cables can result in cuts to exposed cable ends. • Wear suitable PPE. 2.2.2 Commissioning WARNING Electric shock Housing is live due to missing or insufficient earthing. • Check earthing and associated resistance values. • Wear suitable PPE. UNITY 150-360 Description 11/2023 V1.0...
  • Page 22 Cables can cause injuries if they come loose while being "stretched" to reach a vehicle. • Pay attention to the warnings on the product. CAUTION Cut injury Injuries to fingers when removing and installing cables and measuring wires. • Wear suitable PPE. UNITY 150-360 Description 11/2023 V1.0...
  • Page 23 Danger of being hit by a door swinging open. • Lock the door in position before starting work. CAUTION Risk of slipping Danger of slipping in a liquid. Coolant may escape during maintenance work on the cable cooling system. • Wear suitable PPE. UNITY 150-360 Description 11/2023 V1.0...
  • Page 24 2. Secure against restarting 3. Determine absence of voltage 4. Earthing and short-circuiting 5. Cover or cordon off neighboring live parts On completion of the work, reverse the order in which the measures were taken. UNITY 150-360 Description 11/2023 V1.0...
  • Page 25 The maximum permissible voltage drop is country-specific according to legislation. You must comply with the legal and normative regulations of the respective country when placing the product on the market. It may be necessary to increase the cross-section. UNITY 150-360 Description 11/2023 V1.0...
  • Page 26 Operational electrical or electromagnetic fields that can be dangerous for wearers of pacemakers, implants or metal objects, for example, if the distance is insufficient. Release of environmentally harmful substances and emissions in the event of improper operation or improper disposal of components. UNITY 150-360 Description 11/2023 V1.0...
  • Page 27 (DC) or alternating current (AC). The UNITY charging station may only be used for charging electric vehicles. Kostad products may only be used for the applications specified in the catalog and the associated technical documentation. If third-party products and components are used, they must be recommended or approved by Kostad.
  • Page 28 Any changes to the charging station must be discussed with the manufacturer in advance and their approval obtained. All documentation, including these operating instructions, must be updated or extended accordingly. Unauthorized modifications and changes to the system will void any liability and warranty of the manufacturer! UNITY 150-360 Description 11/2023 V1.0...
  • Page 29 The specific installation and safety regulations and the regulations on the use of personal protective equipment are complied with. Use the support and services of the responsible Service Center for planning, installation, commissioning and service tasks. UNITY 150-360 Description 11/2023 V1.0...
  • Page 30 Optional: MID measurement for AC & DC outputs Optional: Calibration- Energy measurement compliant design of the AC & DC outputs (Q4 2023) Network connection GSM / 4G / LTE Table 7: Technical data - UNITY UNITY 150-360 Description 11/2023 V1.0...
  • Page 31 UNITY 180 UNITY 240 UNITY 300 UNITY 360 Softwareupdate Over-the-air updates via Kostad German, English and more than 15 other languages available Control & configuration Kostad HMI on the display configurator Languages German, English and more than 15 other languages available...
  • Page 32 • EN 301489-34 V1.4.1 3.4.4 IEC 15118 • DIN EN ISO 15118 3.4.5 Low Voltage Directive • EN 61851-1:2011 • EN 61851-23:2014 • EN 61851-1:2010 • IEC 61851-1:2010 • IEC 61851-23:2014 • EN IEC 62311:2020 UNITY 150-360 Description 11/2023 V1.0...
  • Page 33 Technical data 3.4.6 Equipment • IP54 - Protected against ingress IEC 60529:1989+A1:1999+A2:2013 • IK 10 housing - impact protection in accordance with EN 62262 • IK 8 screen - impact protection in accordance with EN 62262 UNITY 150-360 Description 11/2023 V1.0...
  • Page 34 Description 4 Description This chapter deals with the product description of the KOSTAD charger. UNITY product description The UNITY is a multi-standard charging station that is used to charge electric vehicles using AC or DC charging standards. The charging station can be configured with 2 or 3 charging points and charge 2 vehicles simultaneously.
  • Page 35 EMERGENCY STOP button. LED lighting The standard colors of the LED lighting show • Free charging station: green • Reserved charging station: violet • Charging station in use: blue The colors can be adjusted by the operator. UNITY 150-360 Description 11/2023 V1.0...
  • Page 36 EN62196-2 (VDE-AR-E 2623-2-2) is integrated into the charging station if this option is selected. A phase imbalance monitor can also be selected in addition to this option in accordance with VDE-AR-N 4100. UNITY 150-360 Description 11/2023 V1.0...
  • Page 37 Control cabinet lock or locking system (cylinder) • Charging outlet type, cable length without/with cable cooling • Payment-Terminals • Backend connection and remote service • AC charging HMI navigation For information on the HMI and operation, see document: UNITY_OperatingInstructions_Release2023_EN_V1.0.pdf UNITY 150-360 Description 11/2023 V1.0...
  • Page 38 4.6.3 KOSTAD service connection The KOSTAD service connection is established via the integrated modem and a separate SIM card. KOSTAD can connect to UNITY via the service connection to perform the following tasks. • Access to the UNITY charging station for service and maintenance •...
  • Page 39 Type plate The charging station is identified by a type plate. The type plate is located on the left side panel of the charging station. Figure 2: UNITY typeplate Figure 3: UNITY position typeplate (example Unity360) UNITY 150-360 Description 11/2023 V1.0...
  • Page 40 You will find the relevant article number for your charging station on the type plate on the left-hand side panel in the upper front area. The features and functions described below are order- dependent and therefore not available for all stations. They represent available options. UNITY 150-360 Description 11/2023 V1.0...
  • Page 41 Various forms exist for the option "AC and DC measurement method and AC energy metering for AC and DC charging outlets in compliance with calibration law". 5.1.2 Connector and cable Cable outlet Cable outlet detail UNITY 150-360 Description 11/2023 V1.0...
  • Page 42 5.1.6 Packaging, foiling and color selection options Several options are available (packaging, foiling and color selection of the charging station). If you have any questions, please contact the Kostad Customer Support Center (support@kostad.at). UNITY 150-360 Description 11/2023 V1.0...
  • Page 43 Pay attention to the markings on the packaging. ATTENTION Risk of material damage due to incorrect storage. Improper storage may result in damage to the appliance. • Follow the storage instructions. • Pay attention to markings for correct handling. UNITY 150-360 Description 11/2023 V1.0...
  • Page 44 • Pay attention to the surroundings. 6.2.2 Transportation with forklift truck It is not possible to transport the charging station with a forklift truck without a transport pallet. UNITY 150-360 Description 11/2023 V1.0...
  • Page 45 Only use suitable tools. Shackles, chains, straps, etc. Note the weight of the charging station. You can find information on this in chapter 3 Technical data. Figure 4: Transport by crane - lifting with crane eyelets UNITY 150-360 Description 11/2023 V1.0...
  • Page 46 Please refer to the information in chapter 7.2.2.1 Cooling. If the selected locations do not meet the spatial requirements, you must contact the KOSTAD Customer Support Center (support@kostad.at) in advance. UNITY 150-360 Description 11/2023 V1.0...
  • Page 47 • You can route the hose required for the cable feed lines into the ground at any position depending on the local conditions. Figure 5: Charging station in the parking lot in the outdoor area UNITY 150-360 Description 11/2023 V1.0...
  • Page 48 Site preparation for installation Example of a foundation Figure 6: Mounting dimensions [mm] and cable entries for mains supply Figure 7: Mounting dimensions [mm] and cable entries for mains supply and LAN UNITY 150-360 Description 11/2023 V1.0...
  • Page 49 The height of the concrete base must comply with local building regulations. The 800 mm dimension in the figure stands for installations in Austria/Germany and guarantees a frost-free foundation. Figure 8: Hose for network supply (left) and cable feed (right) UNITY 150-360 Description 11/2023 V1.0...
  • Page 50 - 150 mm² can be installed according to the power rating. The permissible bending radius for the 150 mm² cable is at least 610 mm. Foundation with cable for mains supply Base with cable for mains supply and optional Ethernet LAN cable UNITY 150-360 Description 11/2023 V1.0...
  • Page 51 ATTENTION Risk of material damage due to fire. Cable fire in the housing due to blockage of the ventilation. • The clearances around the Unity must be maintained to prevent overheating by blocking the ventilation. UNITY 150-360 Description 11/2023 V1.0...
  • Page 52 Wall Charger Figure 10: Free space for cooling and service access If the selected locations do not meet the spatial requirements, you must contact the KOSTAD Customer Support Center (support@kostad.at) in advance. 7.2.2.1 Cooling The charging station has a central fan that is switched on when the set temperature is exceeded.
  • Page 53 The impact protection must not prevent the front door from opening properly. If you have any questions about impact protection or possible design variants, please contact the Kostad Customer Support Center (support@kostad.at). UNITY 150-360 Description 11/2023 V1.0...
  • Page 54 It may be necessary to increase the cross-section. 7.3.3 Connection concept The connection concept is defined on site with KOSTAD. If you have any questions, please contact Kostad Customer Support (support@kostad.at). UNITY 150-360 Description 11/2023 V1.0...
  • Page 55 CPO/MSP and for the optional remote maintenance function. 7.3.5 LAN / WAN When using LAN, the installation location must be prepared accordingly. The LAN cable must be at least 800 mm long from the foundation. UNITY 150-360 Description 11/2023 V1.0...
  • Page 56 Site preparation for installation 7.3.6 Access with Sinema Remote and Smart Server Information can be found in the following document: UNITY_OperatingInstructions_Release2023_EN_V1.0.pdf UNITY 150-360 Description 11/2023 V1.0...
  • Page 57 Moving Unity to the installation location may cause damage to other objects. • Pay attention to surrounding objects, walls, ceilings, etc. • Plan the transportation route and method according to the conditions at the installation site. UNITY 150-360 Description 11/2023 V1.0...
  • Page 58 The AC power supply cables must be in the correct position and length to carry out the installation. Check the following points before starting the installation. • AC cables emerge from the foundation at the correct position • AC cables are at least 950 mm long from the foundation UNITY 150-360 Description 11/2023 V1.0...
  • Page 59 ATTENTION Risk of material damage due to fire. Cable fire in the housing due to blockage of the ventilation. • The clearances around the Unity must be maintained to prevent overheating by blocking the ventilation. UNITY 150-360 Description 11/2023 V1.0...
  • Page 60 The use of cutting tools to remove plastic can damage the Unity housing. • Do not use cutting tools to open and remove the packaging. • Cabinet • Charging cable • Charging plug • • RFID field • Emergency stop button • Crane eyelets UNITY 150-360 Description 11/2023 V1.0...
  • Page 61 1. Check the positions of the holes according to the drawing. 2. Drill holes for the expansion anchors in the foundation. 3. Drive in the expansion anchor. Follow the manufacturer's instructions. The expansion anchors are installed in the foundation. UNITY 150-360 Description 11/2023 V1.0...
  • Page 62 The following steps will guide you through the process of detaching the UNITY from the EUR pallet. 1. Unscrew the 4 screws of the two plinth panels. 2. Remove both base covers. 3. Remove both fastening screws. UNITY is detached from the EURO pallet. UNITY 150-360 Description 11/2023 V1.0...
  • Page 63 EMERGENCY STOP button and is held securely in place with a cable tie. 1. Attach the hoist to the crane eyelets. 2. Position the beam on the foundation. Pay attention to the alignment / position of the UNITY in relation to the foundation. UNITY 150-360 Description 11/2023 V1.0...
  • Page 64 Handle the device with care. Achtung Risk of material damage to the power cables. Damage to the power cables may occur when inserting the cabling. • Pay attention to the presence of the edge protection. UNITY 150-360 Description 11/2023 V1.0...
  • Page 65 6. Feed the AC cable through the opening provided in the base of the UNITY / cable routing grommets. 7. Raise UNITY a few mm. 8. Remove bars. 9. Lower the UNITY onto the expansion anchors on the foundation. UNITY 150-360 Description 11/2023 V1.0...
  • Page 66 12. Tighten the 4 x M10 nuts to a torque of 35 Nm. 13. Detach the hoist from the 4 crane eyelets. 14. Mount the 4 plinth panels. 15. Fasten the 4 plinth panels with a torque of 4.7 Nm. UNITY 150-360 Description 11/2023 V1.0...
  • Page 67 16. Remove the crane eyelets. 17. Fasten the screw plugs with the existing seals. 18. OPTION Cable management Install the cable management with locking screws. The installation of the UNITY on the foundation is complete. UNITY 150-360 Description 11/2023 V1.0...
  • Page 68 Pay attention to the corresponding guidelines for cable terminations. The following steps will guide you through connecting UNITY to the power supply. 1. Shorten the cable to 650 mm from the foundation. 2. Strip 500 mm of the cables. UNITY 150-360 Description 11/2023 V1.0...
  • Page 69 5. For OPTION with AC socket, connect the N conductor to the right busbar (2). Jumper (3) must not be fitted to the AC socket. 6. Connect phases L1, L2 and L3 to terminals 1X1 (tightening torque 40Nm) UNITY 150-360 Description 11/2023 V1.0...
  • Page 70 The power supply cables are connected to UNITY. Testing the electrical system Switch on the system and carry out a test. The following tests must NOT be carried out: • Insulation test (carried out by the manufacturer) UNITY 150-360 Description 11/2023 V1.0...
  • Page 71 When inserting the SIM card, the card or the router may be damaged. • Make sure that the card slot and card orientation have been selected correctly. • Insert the SIM card without excessive force. 1. Connect the LAN cable to the LAN plug. UNITY 150-360 Description 11/2023 V1.0...
  • Page 72 Installation 2. Lay the cable in UNITY as shown in the picture. The network cable is connected. UNITY 150-360 Description 11/2023 V1.0...
  • Page 73 ATTENTION Risk of material damage due to incorrectly set operating parameters. Incorrectly set operating parameters may result in damage to the appliance. • Make sure that the configuration is carried out according to the specifications. UNITY 150-360 Description 11/2023 V1.0...
  • Page 74 Fuse protection socket cabinet 31F1 Fuse protection SITOP PSU300S 30F1 Fuse protection SITOP PSU8600 31F2 Fuse protection DC 24 V 30F4 Fuse protection DC 24 V SIMATIC ET 31F3 Fuse protection DC 24 V 200SP Analog output module UNITY 150-360 Description 11/2023 V1.0...
  • Page 75 6. 30F4 Fuse protection DC 24 V Power supply unit 2 A switch on. 7. 31F1 Fuse protection DC 24 V Power supply unit 10 A switch 8. 31F2 Switch on DC 24 V fuse protection. UNITY 150-360 Description 11/2023 V1.0...
  • Page 76 20 A fuse. 3. 31F2 Switch off DC 24 V fuse. 4. 31F1 Switch off DC 24 V power supply unit 10 A fuse. 5. 30F4 Switch off DC 24 V power supply unit 10 A fuse. UNITY 150-360 Description 11/2023 V1.0...
  • Page 77 20 A fuse. 8. 27F1 Fuse protection Switch off cable cooling. 9. 1F3 Fuse protection Switch off voltage monitoring and surge arrester. 10. Close the cabinet door. The charging station is switched off. UNITY 150-360 Description 11/2023 V1.0...
  • Page 78 Risk of material damage to the vehicle. Dropping the charging plug can cause damage to the vehicle if the plug hits the vehicle. • Pay attention to the stickers on the Unity. • Be careful when handling the charging cables. UNITY 150-360 Description 11/2023 V1.0...
  • Page 79 Handling the charging cable When handling the charging cable and plug, you must observe the manufacturer's instructions provided by the charging cable manufacturer, e.g. Phoenix. Please note the schematic diagram (image source/copyright: PHOENIX CONTACT GmbH & Co. KG). UNITY 150-360 Description 11/2023 V1.0...
  • Page 80 Do not use any liquids for cleaning. ATTENTION Risk of material damage due to unsuitable cleaning agents. The use of unsuitable cleaning agents can cause damage to surfaces and components of the Unity. • Do not use solvents for cleaning. UNITY 150-360 Description 11/2023 V1.0...
  • Page 81 Apply neutral or slightly alkaline cleaning solutions (pH value between 6 and 8). Allow the cleaning solution to take effect. • Remove contamination with a nylon fleece hand cloth. Never use abrasive tools or scouring agents for cleaning. • Rinse the charging station thoroughly with tap water. UNITY 150-360 Description 11/2023 V1.0...
  • Page 82 Apply sticker with date of inspection and next inspection ATTENTION Risk of material damage to doors and door hinges. Improper handling may result in damage to the doors and door hinges of the appliance. • Handle the device with care. UNITY 150-360 Description 11/2023 V1.0...
  • Page 83 1. Press the EMERGENCY STOP button when the system is switched 2. Disconnect any connections to connected EVs. 3. Unlocking the EMERGENCY STOP button The display returns to the main menu after a short time. UNITY 150-360 Description 11/2023 V1.0...
  • Page 84 EMERGENCY STOP status Check auxiliary relay earth fault 1. Open the front door. 2. Check auxiliary relay earth fault (- 8P1, -8P2 and -9P1, -9P2). replace if necessary. Heating, ventilation, LEDs For tests, see document UNITY_OperatingInstructions_Release2023_EN_V1.0.pdf UNITY 150-360 Description 11/2023 V1.0...
  • Page 85 1. Visually check the insulation of all charging cables. Check for damage, cracks, foreign objects? 2. Carry out a visual check of all charging plugs and charging plug positions. Check for damage, chipping, foreign bodies, ... UNITY 150-360 Description 11/2023 V1.0...
  • Page 86 4. Perform loop impedance and short- circuit current measurement. 5. Test button of the residual current circuit breaker - Actuate -27F2 6. OPTION Test button of the residual current circuit breaker -85F1 with AC socket outlet UNITY 150-360 Description 11/2023 V1.0...
  • Page 87 See document 2. Calibrate control panel UNITY_OperatingInstructions_Release2023_E N_V1.0.pdf System book 1. Document system See document log/measurement logs Maintenance_log _Unity50-360_EN_V1.0.pdf PT 100 function test 1. Open service menu See document 2. Check PT100 for plausibility Maintenance_log _Unity50-360_EN_V1.0.pdf UNITY 150-360 Description 11/2023 V1.0...
  • Page 88 (number of charges CP1 - CP3) N_V1.0.pdf Rough cleaning 1. Rough cleaning of the charging station - should be carried out [4 x per year] Inspection sticker 1. Check the inspection sticker The annual inspection has been completed. UNITY 150-360 Description 11/2023 V1.0...
  • Page 89  Check filter mats regularly for soiling  Replace soiled filter mats Material Article Filter mat Item number M20FPF5K Manufacturer Fandis Comment Same filter mats for side panels Table 13: Article information Filter mats UNITY 150-360 Description 11/2023 V1.0...
  • Page 90 The charging station must be switched off in accordance with chapter 9.3 Switching off the charging station. Replacing filter mats 1. Open the left side panel. 2. Remove the hexagon socket screws. The earthing cable is also screwed in. UNITY 150-360 Description 11/2023 V1.0...
  • Page 91 5. Insert new filter mats. 6. Push in the extension. 7. Fasten screws with hexagon socket. 8. Close the side panel. The replacement of the filter mats on the left side panel has been completed. UNITY 150-360 Description 11/2023 V1.0...
  • Page 92 2. Remove the old filter mat from the openings. 3. Insert the new filter mats through the openings and align them. 4. Close the side panel. The filter mats on the right-hand side panel have been replaced. UNITY 150-360 Description 11/2023 V1.0...
  • Page 93 Rotation speed-controlled fan Item number R2E225-RA92-09 / CGD15050H24B Manufacturer Ebmpapst /Alternative manufacturer Comment Table 14: Article information speed-controlled fan Preconditions The charging station must be switched off in accordance with chapter 9.3 Switching off the charging station. UNITY 150-360 Description 11/2023 V1.0...
  • Page 94 4. Remove the old fan. 5. Insert the new fan. 6. Screw on the new fan. 7. Connect the cable of the new fan. 8. Close left panel. The speed-controlled fan has been replaced. UNITY 150-360 Description 11/2023 V1.0...
  • Page 95 The charging station must be switched off in accordance with chapter 9.3 Switching off the charging station. Replacing the charging cable 1. Open the side panel. 2. Loosen and remove the charging cable screw connection. UNITY 150-360 Description 11/2023 V1.0...
  • Page 96 5. Remove the charging cable. 6. Install new charging cable. Make sure that the wires of the charging cable are long enough to connect them back to the terminals provided for this purpose. UNITY 150-360 Description 11/2023 V1.0...
  • Page 97 The charging station must be switched off according to chapter 9.3 Switching off the charging station. 1. Open the front door. 2. Open the inner door. 3. Check the compartment under the RFID reader for condensation. UNITY 150-360 Description 11/2023 V1.0...
  • Page 98 Maintenance / Servicing 4. Check the drain for soiling, clean the drain if necessary. 5. Close the inner door. 6. Close the front door. The front door was checked for standing water. UNITY 150-360 Description 11/2023 V1.0...
  • Page 99 Troubleshooting 13 Troubleshooting For more information, see document UNITY_OperatingInstructions_Release2023_EN_V1.0.pdf UNITY 150-360 Description 11/2023 V1.0...
  • Page 100 2. Remove the SD card from the ET200 PLC and/or the vehicle controller. 3. Remove the GSM SIM card of the CPO / operator. 4. Disconnect all electrical connections and remove all cables. 5. Loosen the machine fastenings. UNITY 150-360 Description 11/2023 V1.0...
  • Page 101 The decommissioning of the charging station is complete. 14.2 Disposal Separate the components for recycling according to the following categories: • Components • Auxiliary materials and chemicals • Packaging materials Dispose of the respective categories in accordance with local regulations. UNITY 150-360 Description 11/2023 V1.0...
  • Page 102 Notes 15 Notes UNITY 150-360 Description 11/2023 V1.0...
