- Page 1 Installation Manual MICROWAVE DRAWERS MWD MODELS zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ....1 BEFORE INSTALLATION ....... 5 Product Specifications . -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING • Before installation and operation, please read and follow these important instructions for the safety of your home and the people living in it. • Installation and service must be performed by a qualified installer. The oven should not be adjusted or repaired by anyone except properly qualified service personnel. - Page 6 IMPORTANT SAFETY INSTRUCTIONS • This appliance must be grounded or connected to a properly grounded outlet. • Install this appliance only in accordance with the provided installation instructions. • Some products such as whole eggs and sealed containers (i.e. closed glass jars) should not be heated in this oven. •...
- Page 7 IMPORTANT SAFETY INSTRUCTIONS • When cleaning surfaces of the door and oven that come together when closing the door, use only mild, nonabrasive soaps or kitchen-safe cleaners applied with a sponge or soft cloth. Do not clean with metal scouring pads.
- Page 8 IMPORTANT SAFETY INSTRUCTIONS • HOT CONTENTS CAN CAUSE SEVERE BURNS. DO NOT ALLOW CHILDREN TO USE THE MICROWAVE. Use caution when removing hot items. • Liquids such as water, coffee, or tea may be heated beyond the boiling point without appearing to be boiling. •...
-
Page 9: Before Installation
BEFORE INSTALLATION PRODUCT SPECIFICATIONS Remove the microwave and all materials from the carton and inside the oven. Your appliance comes with the following accessories: MWD-1 SERIES MICROWAVES Touch pad Control box Right mounting plate Handle Window Cord is 48" (1219 mm) long SETTING UP YOUR OVEN BEFROE... -
Page 10: Model And Serial Number Location
BEFORE INSTALLATION PRODUCT SPECIFICATIONS MWD-1 SERIES MWD-30 SERIES Rated Voltage 120 VAC, 60 Hz, 13A 120 VAC, 60 Hz, 13A Rated Input Power 1500 W 1500 W Rated Output Power 1000 W 1000 W Oven Capacity 1.2 Cu. Ft. 1.2 Cu. Ft. External Dimensions 23 1/2"... -
Page 11: Electrical Connection
BEFORE INSTALLATION WARNING ELECTRICAL CONNECTION • This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. • This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. -
Page 12: Installation
If there is any damage, do not operate the microwave drawer and contact your dealer or ZLINE. IMPORTANT NOTES TO THE INSTALLER Read the entire installation portion of the manual before installing the microwave drawer. -
Page 13: Installation Notices
INSTALLATION INSTALLATION NOTICES Dimensions shown are precise, and cutout dimensions provide minimum clearances. • Contact surface must be solid and level. The cabinet floor of the opening should be constructed of plywood strong enough to support roughly 100 lb (45 kg). •... - Page 14 INSTALLATION MWD-1 SERIES MWD-30 SERIES *NOTE: Cabinet opening width varies with the MWD-30 model. See page 12 for details.
-
Page 15: Electrical Outlet And Anti-Tip Block
INSTALLATION 3 1/2" (89 mm) 6" (152 mm) 5" (127 mm) 4" (102 mm) ELECTRICAL OUTLET AND ANTI-TIP BLOCK • To reduce the risk of tipping the drawer, an anti-tip block must be located a minimum of 15" (381 mm) above the cabinet floor on which the microwave drawer will sit, as outlined above. -
Page 16: Installing The Drawer
INSTALLATION INSTALLATION DRAWER INSTALL ATION Figure 4 INSTALLATION THE DRAWER DRAWER INSTALL ATION INSTALLING THE DRAWER Figure 4 24" Microwaves MWD-1 SERIES Mounting plate Mounting plate DRAWER INSTALLATION 1. Place the drawer adjacent to the wall or cabinet opening. DRAWER INSTALLATION Mounting screws Plug the power supply cord into the electrical outlet. -
Page 17: Handle Installation
INSTALLATION HANDLES HANDLE INSTALLATION NOTE: The Allen/hex key needed to remove the handle is only included with Autograph Edition handles (Champagne Bronze, Gold, and Matte Black). Autograph Edition handles 1. Locate the holes on the underside of each handle base. 2. -
Page 18: Trim Kit Installation
INSTALLATION TRIM KIT TRIM KIT INSTALLATION NOTE: This trim kit is available for purchase as a separate accessory for ZLINE’s MWD-1 series microwave drawer in stainless steel only. The trim kit is only available for the MWD-1 unit; it is not available in black stainless. -
Page 19: Tools Needed
INSTALLATION TRIM KIT TOOLS NEEDED: • Phillips-head screwdriver • Marker • Drill PARTS INCLUDED: PART QUANTITY IMAGE Outer trim (1) Support beam (2) Front bracket (1) Rear bracket (1) Buckle seat (4) Buckle (4) Finishing washers (4) #1 Screw (4) #2 Screw (16) #3 Screw (2) - Page 20 INSTALLATION TRIM KIT 1. Lay the support beams flat on the bottom of the cabinet cutout with the open sides facing each other (see Figure 1). Figure 1 To gauge proper width, temporarily place the rear and front brackets onto the support beams so the rear bracket lips slide into rear holes on top of the beams and the front Front bracket screw holes match to the front of the beams (see Figure 2).
- Page 21 INSTALLATION TRIM KIT 2. Remove the screws from the front bottom of your microwave. Using two of those screws, secure the front bracket to the bottom of the microwave, ensuring the lip of the bracket is Front bracket extending down and facing you. Next, remove the screws from the back bottom of the microwave and fasten the rear bracket, ensuring the two small lips are extended down and facing back (see Figures 4 and 5).
- Page 22 INSTALLATION TRIM KIT ① 将安装好卡扣的外观框放在橱柜上作出比对；用记号笔画上安 4. Next, slide the outer trim into the cabinet cutout and use a marker or pencil to mark 装位置 卡扣的外观框放在橱柜上作出比对；用记号笔画上安 where the buckles line up. Then, remove the trim and secure the four buckle seats into Place the trim kit which install buckle on the cabinet for ②...
- Page 23 INSTALLATION TRIM KIT 5. Using two people, lift the microwave and push it into the cabinet until the two small lips in the rear bracket slide into both holes in the rear of the support beams fastened in Step 1 to the bottom of the cutout (see Figure 10). 6.
- Page 24 INSTALLATION TRIM KIT ① Insert the trim kit into the corresponding buckle seat 将 预装好外观框卡进对应卡扣座里 7. Insert the outer trim kit into the cutout (see Figure 13). Clip each buckle onto its corresponding buckle seat to complete the trim kit installation (see Figure 14). Figure 13 Figure 14 Finish...
-
Page 25: Warranty
It is the responsibility of the customer to install all replacement parts, as ZLINE does not perform service repairs on its microwave products. ZLINE’s liability is limited to the original purchase price of the product. Additional injuries, losses, damages, or other inconveniences caused by product malfunction or defects in materials are not covered under the terms of this warranty. - Page 26 All warranty procedures must be followed to maintain warranty coverage. If ZLINE is unable to replace the defective part after a reasonable number of attempts, ZLINE reserves the right to offer to replace the product or provide the original purchaser a full refund of the purchase price of the product (not including installation, removal, or other charges that were not included in the original purchase price).
-
Page 27: Serial Number Location
Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help. - Page 28 Customer Experience Portal. Scan the QR code to view the most up-to-date version of our Installation Manual and User Manual. Need to purchase a part or accessory for your ZLINE product? Visit www.zlineparts.com, ZLINE’s official parts distribution partner.
