What's in the box
What's in the box
Overview
LCD Screen Guide
Recharging Your Power
Station
Powering On / Off
Powering Your Devices
Anker SOLIX F3800 Plus
Uninterruptible Power
Portable Power Station
Supply (UPS)
Overview
Connect With an
Expansion Battery
Connect with Anker SOLIX
Home Power Panel
Connect Two Anker SOLIX
F3800 Plus Power Stations
Anker App for Smart
Control
Light
Carry Your Power Station
FAQ
Retractable Handle (To extend, press the
Specifications
handle button, then pull)
On/Off Button
IoT Button
Car Socket Button
NEMA L14-30R AC Output Port
NEMA 5-20R AC Output Port (Left 3 Ports
Have UPS)
AC Input Port
Overcharge Protection (AC Input)
Expansion Battery Port
Wheel Brake
Wheels
Solar Charging Cable
AC Charging Cable
1
10
8
9
5
2
6
11
3
7
12
4
Display Button
USB Ports
Car Socket
NEMA TT-30R AC Output Port
AC Outlet Button
Overcharge Protection (AC
Output)
Home Power Panel Port
Dual Solar Input
Anker SOLIX Smart Generator Port
Bottom Handle
User Manual &
(x2)
Warranty Card
14
13
15
16
17
18
21
19
20
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Anker SOLIX F3800 Plus
Summary of Contents for Anker SOLIX F3800 Plus
- Page 1 Overview LCD Screen Guide Recharging Your Power Station Powering On / Off Powering Your Devices Solar Charging Cable User Manual & Anker SOLIX F3800 Plus AC Charging Cable Uninterruptible Power (x2) Warranty Card Portable Power Station Supply (UPS) Overview Connect With an...
- Page 2 LCD Screen Guide Remaining Battery for Power Station and Expansion Battery Overload Warning This icon appears when a port is overloaded. The port will turn off to avoid any damage. Please remove the device causing overload. Current Output Power Current Input Power Whole-Home Power Mode USB-A Output Port USB-C Output Port...
- Page 3 Plus via the Home Power Panel port. After connecting the 240V Generator, one Anker SOLIX F3800 Plus recharges at a maximum power of 3300W; if Anker SOLIX F3800 Plus is connected to Expansion Batteries, recharging power can be up to 6000W.
- Page 4 1. Recharge your power station with a maximum solar input of 3200W. 2. Wiring Instructions: Series Wiring The solar input voltage range for Anker SOLIX F3800 Plus is 11-165V. Ensure the total solar voltage is within this range. Voltage exceeding 165V will damage the product.
- Page 5 Parallel Wiring • The solar input current for Anker SOLIX F3800 Plus is 17A. Please ensure the total solar current is near 17A. If it exceeds 17A, the output power of the solar panel cannot be fully utilized. • To connect solar panels in parallel, purchase the Solar Parallel Connection Connector from the Anker official website.
- Page 6 (N) and ground (PE) wires may cause appliances damaged on the circuit. • The LRA (Locked Rotor Amps) of Anker SOLIX F3800 Plus is 80A. You will need a soft starter if your air conditioner requires higher LRA to start.
- Page 7 1. Press the AC outlet button and connect the power station to your inlet box or transfer switch via the L14-30R AC output port. The max output power via this port is 6000W. To ensure safe power supply to your inlet box or transfer switch via the 240V AC ports, check and confirm that the neutral and ground wires of the inlet box or transfer switch are properly connected.
- Page 8 USB Charging Connect your devices to the USB ports. If the output current of the USB port remains below 60mA continuously for two hours, the USB charging will automatically stop to save power. Car Socket Charging Turn on the car socket and connect your devices to start charging. On / O...
- Page 9 AC output ports. Connect With an Expansion Battery You can purchase Anker SOLIX BP3800 Expansion Batteries and connect them with your power station to increase the capacity up to 26880Wh. Please refer to the user manual of Anker SOLIX BP3800 Expansion Battery for detailed instructions.
- Page 10 Connect with Anker SOLIX Home Power Panel You can purchase Anker SOLIX Home Power Panel to enhance your home backup and power utility. Please refer to the user manual of Anker SOLIX Home Power Panel for detailed instructions. Connect Two Anker SOLIX F3800 Plus Power Stations You can purchase Anker SOLIX Double Power Hub to connect two Anker SOLIX F3800 Plus Stations via the Home Power Panel ports to double power output.
- Page 11 Anker App for Smart Control You can remotely control your power station using the Anker app. 1. Download the Anker app from the App Store (iOS devices) or Google Play (Android devices), or by scanning the QR code. 2. Connect the device to a network before using the app for the first time. After connecting successfully, you can connect your device off-grid.
- Page 12 Carry Your Power Station 1. Lay the power station flat. 2. Open the bottom folding handle. 3. Grab the bottom and top handles to lift the power station.
- Page 13 Q2: What should I do when using a solar charger to charge my power station? Anker SOLIX F3800 Plus Portable Power Station has 2 solar input ports. Each solar input port supports an 11-165V solar charger with a solar charging connector, the current supports 17A max.
- Page 14 Q9: When recharging Anker SOLIX F3800 Plus Portable Power Station with a 120V AC input, can I use its 240V outlet to charge other devices? No, when Anker SOLIX F3800 Plus is recharging via the 120V AC input, you can only use its three 120V UPS outlets to charge other devices.
- Page 15 Car Charger Output 6000W Max (AC Input), 6000W Max (AC Output), Home Power Panel Port 120V/240V, L1+L2+N+PE AC Output Power (Total) 6000W Max AC Output 1 (the 3 left ports of 120V~ 20A Max, 60Hz, 2400W Max NEMA 5-20R) AC Output 2 (the 3 right ports 120V~ 20A Max, 60Hz, 2400W Max of NEMA 5-20R) AC Output (NEMA TT-30)
