- Page 1 Tuzio Verona ® Towel Warmer Installation Guide Code: W9904T 59.5” x 19.5” Hardwired Technical Helpline: Toll-Free 1-877-757-8990 www.icocanada.com...
- Page 2 Towel Warmer Installation Procedure Rough-in Requirements (see figure 3) 1. The incoming power feed goes to a deep single gang electrical box (for timer). This electrical box can be located anywhere in the room, although we recommend it be alongside your light switches. 2.
- Page 3 Specifications & Drawings Model # Description Finish Weight (lb) Element Size Output WxH (mm) WxH (Inches) Metal Type W9904T Verona Electric Hardwire Brushed 48.6 300W 1706Btu 1510 x 950 59.5” x 19.5” Stainless Nickel Steel Heating Element Specifications: 300 watt, 12" long, 120 volt, 60 Htz, IP55 cord, ULC approved Material Specifications: Mild Steel - Din 2394 Quality - ST 34-2 KB / Stainless Steel - Din 17457 Quality - 1.4301...
- Page 4 Timer Installation Procedure Installation Programming Install the timer as shown in figure 3. You can set up to 7 programs. To set a program, you need to Apply power at the circuit breaker. enter its start time (ON) and its end time (OFF). Pry the timer door open using a small screwdriver.
