- Page 1 Tuzio Savoy ® Towel Warmer Installation Guide Code: W1051 & W1053 23.5” x 47.75” Hardwired Technical Helpline: Toll-Free 1-877-757-8990 www.icocanada.com...
-
Page 2: Installation Instructions
Towel Warmer Installation Procedure Rough-in Requirements (see figure 3) 1. The incoming power feed goes to a deep single gang electrical box (for timer). This electrical box can be located anywhere in the room, although we recommend it be alongside your light switches. 2. - Page 3 Specifications & Drawings Model # Description Finish Weight (lb) Element Size Output WxH (mm) WxH (Inches) Metal Type 3120Btu W1051 Savoy Electric Hardwire White 44.4 300W 600 x 1210 23.5” x 47.75” Mild Steel W1053 Savoy Electric Hardwire Chrome 44.4 300W 3120Btu 600 x 1210...
-
Page 4: Troubleshooting
Timer Installation Procedure Installation Programming Install the timer as shown in figure 3. You can set up to 7 programs. To set a program, you need to Apply power at the circuit breaker. enter its start time (ON) and its end time (OFF). Pry the timer door open using a small screwdriver.
