VOLA 080ST
Fitting instruction
Montageanleitung
Monteringsvejledning
Monteringsvägledning
Montage hanleiding
Manuel de montage
www.vola.com
mnt_080ST_V5_40999800
5 703182 372303
Data
Bar:
1
2
3
080ST
(l/min)
14.4
20.4
25
29
(Gal/min)
3.8
5.4
6.6
7.7
Max. 65°C, 150°F
0 1
2 3 4
5
6 7
8 9 10
Ø70 mm
Ø2 3/4"
3/4"
1
24 mm
VR161F: 14 l/min
4
VR161:
4
5
VR161K: 7 l/min - 1.8 Gal/min
32.3
VR161D: 9 l/min - 2.5 Gal/min
8.5
VR161F: 14 l/min - 3.7 Gal/min
VR161K
VR161D
-100:
Std.:
+100:
400 mm 500 mm 600 mm 700 mm
16"
19"
23"
2
3
3.7 Gal/min
VR161F
+200:
27"
2,5 mm
Ø32 mm
1 1/4"
4 - 8 mm
1/8" - 3/8"
