Summary of Contents for Rabbit 1-10test
- Page 1 TesTer 1-10test English...
- Page 3 Thank you for purchasing the DALItest tester Please, read the operation manual and follow the rules thereof. Table of contents Intended use and mode of operation Device launching and description of functions Device power supply Tester connection fig. 1 DALItest...
- Page 4 INTENDED USE AND MODE OF OPERATION The DALItest device servers to verify proper operation of lamps adjusted to be controlled via the DALI interface. Testing may be performed in two ways. The first - automatic. In this mode, the lamp’s power at the test’s initial stage is smoothly adjusted from a minor value to the maximum value (ramping).
- Page 5 DEVICE LAUNCHING AND DESCRIPTION OF FUNCTIONS Turning the device on or off, you need to press the ON/OFF button without holding. Turning on is confirmed by activating the LED next to the ON/OFF button. While launching the autotest mode, you need to make sure that the LED beside the ON/OFF button is on as well as press and hold for about 2 second the AUTO button, until the LED beside the AUTO button turns on.
- Page 6 DEVICE POWER SUPPLY The tester is supplied from a 9V battery. The manufacturer recommends the ER9V battery with 1200 mAh capacity. TESTER CONNECTION Connecting the tester to a lamp with power supply adapted to a DALI interface. The device has two single-color wires with connectors adapted to be braced on DALI bus wires. It is possible to connect wires to a single lamp without maintaining any polarity, in contrary to the 1-10 standard, where maintenance thereof has a significant influence on proper control of the lamp’s power.
-
Page 7: Warranty Card
WARRANTY CARD WArrANTY CONDITIONs 1. The manufacturer assures the highest quality of products included in this Warranty Card. 2. The warranty period is 2 years from the sale date. 3. The warranty condition is to deliver the claimed product with intact seal to the service company with the warranty card and purchase proof. -
Page 8: Device Name And Type
DEVICE NAME AND TYPE SALE DATE ........... wariant 1 IDENTIFICATION NO............ SERVICE COMPANY ADDRESS Rabbit Sp. z o.o. ul. Krakowska 141-155 Pantone 2748 CV 50-428 Wrocław Pantone Warm Red CV c-coated (papier powlekany) u-uncoated (papier niepowlekany) tel./fax: +48 71 328 50 65 v-vernished (lakierowany) e-mail: rabbit@rabbit.pl...
