SIDEBOARD MONZA 3D1DR3H W06/25 APARADOR MONZA 3P1C3H BUFFET MONZA 3P1T3N 18826 NOTICE DE MONTAGE ASSEMBLY INSTRUCTIONS MONTAGEANLEITUNG ISTRUZIONI DI MONTAGGIO INSTRUÇÕES DE MONTAGEM INSRUCCIONES DE MONTAJE UPUTE ZA MONTAZU MONTAJ KLAVUZU EAN CODE 8435178365958 1PC/2CNTS AVANT DE COMMENCER,SE REPORTER AUX CONSEILS...
Page 2
max. 8 kg max. 40 kg max. 8 kg max. 5 kg CAJA/COLIS 1/2 CAJA/COLIS 2/2 1 x PIECES 08 1 x PIECES 01 1 x PIECES 09 1 x PIECES 02 1 x PIECES 10 1 x PIECES 03 1 x PIECES 18 1 x PIECES 04 1 x PIECES 20...
Page 4
LISTADO DE PIEZAS - COMPOSANTS - PARTS LIST 01 pc 01 pc 01 pc 600x440x18mm 1764x56x18mm 370x554x2,7mm 01 pc 01 pc 01 pc 600x440x18mm 764x380x18mm 616x349x2,7mm 01 pc 01 pc 01 pc 543x401x18mm 359x380x18mm 616x198x2,7mm 01 pc 01 pc 01 pc 543x401x18mm 411x380x18mm 350x120x12mm...
Page 5
HERRAJES QUINCAILLERIE HARDWARE A x38 8,0x30 F x02 M4x10 H x71 3,5x18 L x09 Ø6,3x50 4/20...
Page 6
A -04x D -04x E -01x H -02x A -04x D -02x 1° 2° 5/20...
Page 7
U -02x H -08x T -02x A -04x 180° B -04x 6/20...
Page 8
A -14x L -05x D -04x E -01x H -02x D -06x 2° 1° 7/20...
Page 25
Tipp over ID LABEL ES: En caso de reclamación, facilitar la información de la etiqueta. FR : En cas de réclamation, merci de transmettre les informations contenues sur l' étiquette fixée sur le produit. EN: lf you may have whatever complaint, please, provide label information.
