Please Read Before Installation
Please read these instructions carefully before starting installation and
keep in a safe place for future reference.
It is recommended to use a qualified electrician for all electrical wiring
procedures.
Please turn off all power to site prior to installation.
Check the contents of the package carefully before installation and
disposal of packaging.
Mirror must be wired directly to a dimmable wall switch to operate the
dimming feature on the mirror.
Mechanical switch located on the bottom of the mirror must remain on
when operating the mirror with the wall switch.
The defogging feature will deactivate when the mirror is dimmed.
LEDPLM2436
24"Wx36H
110V
72W
LEDPLM3436
34"Wx36"H
110V
102W
LEDPLM4836
48"Wx36"H
110V
145W
LEDPLM6036
110V
180W
60"Wx36"H
LEDPLM7036
110V
209W
70"Wx36"H
24"/34"/48"/60"/70"(W)
Copper-free sliver mirror
Arpella
2770
5000K
50,000
3280
5000K
50,000
4020
5000K
50,000
4630
5000K
50,000
5130
5000K
50,000
Arpella
LEDPLM2436/LEDPLM3436/LEDPLM4836/LEDPLM6036/LEDPLM7036
1" Frosted
Front View
IMPORTANT SAFETY INSTRUCTION
When using an electrical furnishing, basic precautions should always be
followed, including the following:
Read all instructions before using this product.
DANGER – To reduce the risk of electric shock:
1. Always suspend power to mirror before servicing the item if service is
needed.
2. Close supervision is necessary when this mirror is used by , or near
children, invalids, or disabled persons.
3. Use this furnishing only for its intended use as described in these
instructions.
Do not use attachments not recommended by Arpella.
5. Never operate this furnishing if it has a damaged cord or plug, if it is not
working properly during testing, if it has been dropped or damaged, or
exposed to water.
6. Keep the cord away from heated surfaces.
7. Never drop or insert any object into any opening in the electrical box.
8. This product is not intended for use outdoors.
9. To disconnect, turn all controls to the off position, then suspend power
to the mirror.
"WARNING: Risk of Electric Shock – Connect this furnishing to a properly
grounded outlet only. See Grounding Instructions.
1.5"(D)
Wire
Mechanical ON-OFF Switch
Side View
Bracket
Back
Advertisement
Related Manuals for Arpella LEDPLM2436
Summary of Contents for Arpella LEDPLM2436
- Page 1 Do not use attachments not recommended by Arpella. The defogging feature will deactivate when the mirror is dimmed. 5. Never operate this furnishing if it has a damaged cord or plug, if it is not working properly during testing, if it has been dropped or damaged, or exposed to water.
