Introduction
Allow this manual to guide you through the functioning of your smartwatch. Please read it thoroughly before using it for a smooth sail. You may refer to these instructions for later use as well.
PACKAGE CONTAINS:
- boAt Wave Call x1
- USB magnetic charging cable x1
- User Manual x1
- Warranty Card x1
CHARGING THE WATCH
The smartwatch must be charged before initial use. It takes 2.5 hours to be fully charged. Connect and charge the watch with the image below as a reference, using a 5V/2A adapter.
Note: Once your watch is at 10% battery, it will automatically switch to power saving mode which will disable all functions.
TURNING THE WATCH ON/OFF
To turn the watch on/off, long-press the side button for 3-5 seconds. You can wake the screen by lifting your wrist.
CONNECTING TO THE APP
- Download the boAt Crest app on your phone.
Available on both App Store (iOS 12.0 and above) & Google Play Store (Android 7.0 and above)
OR Scan [QR CODE]
![]()
- Connect the device with the boAt Crest app
- Select Wave Call on the home screen of the app and click pair to connect.
- Once you are connected, there will be another prompt on the app screen to connect with classic Bluetooth. Tap on pair to connect with WAVE CALL BT and use the Bluetooth calling feature.
- To use all features of your Wave Call seamlessly, tap on 'yes' to the 'connection' and 'grant access' system prompt.
- Turn your phone's Bluetooth and GPS on.
- Disable battery optimization
![play.google.com]()
![www.apple.com]()
Note: To ensure connectivity throughout your journey, make sure the app is allowed to always run in the background of your phone.
SYNCING YOUR SMARTWATCH TO THE APP
Data Synchronization
- Open the app on your phone.
- Make sure your Wave Call is connected to the app
- Synchronization will start automatically once you enter the app interface.
Note: Synchronize data at least once a day to avoid data loss in the watch.
NAVIGATING THROUGH THE FUNCTIONS
SWIPE UP TO ACCESS ALL DATA
You can access daily activity and sports records, heart rate monitor, sleep monitor, weather, music control from here.
Call Menu
Add your contacts on the phonebook from the boAt Crests app. Go to Device -> Bluetooth Calling -> Sync contacts -> Click on "+" sign from the top right corner to add the contacts. Up to 20 contacts can be saved in the phonebook.
Bluetooth calling
- You will be able to access bluetooth calling feature once you connect WAVE CALL BT in your phone's Bluetooth setting.
- Alternatively, you can enable/disable this feature from watch shortcut screen or calling screen in the menu.
- This will be enabled automatically when the call comes on the watch.
- In idle mode, this option will be disabled to save the battery from draining.
Note: Battery will drain out fast if you are using Bluetooth calling feature.
SWIPE LEFT FOR MAIN MENU
Sports mode
Click on the sports mode icon to choose from 10 different sports modes: Walking, Running, Cycling, Climbing, Yoga, Basketball, Football, Badminton, Skipping & Swimming To pause or stop the exercise, press the home button, click finish to end the exercise.
Notes:
- All records will be available on the app if you keep it synchronized.
- The touch screen will not function when exposed to water. When your watch does get wet, wipe the surface with a soft cloth before using it. Make sure maximum depth of water is 1.5 m & maximum time for exposure to water is 10 minutes
Guided Breathing Mode
Click on the breath training icon to regulate your breathing with the instructions given to relax.
Camera Control Mode
Click on the remote camera icon on your watch Wave Call to click a photo from your phone.
Notes: Turn the camera on from your phone to use this feature.
Blood Oxygen Level Monitor
Wear the watch on your wrist, then click on the icon to start measurements. You can also view the data on the app.
Notes: Measurements are for reference only and not for medical purposes.
Stopwatch
Tap on the icon to start the stopwatch.
Find My Phone
Tap on this icon to find your phone. Once enabled, your phone will start ringing and vibrating. Tap again to stop it.
Note: Your watch Wave Call should be connected to your phone via Bluetooth and within its range for this feature to work.
Reset
Tap on this to reset watch data.
*Note: All data will be erased if watch is reset
Screen timeout
Tap on this icon to set screen timeout duration.
Note: Higher the duration lower will be the battery life
Power off
Tap on this to switch your watch off.
Countdown
Tap on this to begin countdown.
Watch Faces
Using the app
Select cloud watch faces on the app and push your preferred watch face to your smartwatch.
Go to Device -> watch faces -> Select and install the watch face of your choice.
Alternatively, you can also customize the watch faces of your choice by selecting the background from your phone's gallery and make it as your watch face.
Note: Make sure your watch and phone are connected via Bluetooth. Do not exit the downloading interface until it displays 100% downloaded. It may take up to 60 secs to sync the watch face with the app.
Using the watch Wave Call Swipe left on the main interface of your watch screen to enter the main menu → Scroll down → Select 'watch faces' → Tap on your preferred display
SWIPE RIGHT TO ACCESS ALL NOTIFICATIONS
Call and Text Notifications
Turn this feature on from your app to receive notifications on your Wave Call. It will show 5 new notifications and automatically overwrite the last message if there are more than 5.
SWIPE DOWN FOR SHORTCUT MENU
You can access the Sports Menu, Brightness, DND, Find My Phone, Music Control, QR Code, About, and Settings from the shortcut menu.
PRODUCT PARAMETERS
| Model | boAt Wave Call |
| Screen Type | 1.69'' (4.29 cm) HD Display |
| Battery Capacity | 220 mAh |
| Net weight | 46 g |
| Bluetooth version | Bluetooth 5.0 |
| Working temperature | 0 45 Degrees Celsius |
| Charging time | about 2.5. hours |
| Working time Maximum transmission power | about 7 days / up to 2 days with BT calling 7.5dBm |
| Frequency band | 2402 - 2480 MHz |
Maintenance
Regularly clean your wrist and the strap of the smartwatch, especially after sweating during exercise or being exposed to substances such as soap or detergent, which may get stuck on the other end of the product.
Do not wash the strap with a household cleanser. Please use soap-less detergent, rinse thoroughly and wipe with a piece of soft towel or napkin.
For spots or stains that are not easy to remove, scrub the area with rubbing alcohol and then follow the above procedure.
Frequently Asked Questions (FAQs)
Calling feature not working on my watch?
Make sure your watch is connected to both your app and the phone Bluetooth. If not, search for WAVE CALL BT in the phone's Bluetooth setting, pair the watch with it. Also, make sure call notification is enabled from the app.
In Idle mode, the watch will disable the classic Bluetooth 3.0 to save the battery.
Search for the app to connect keeps failing
- Keep the boAt Crests app updated to the latest version
- Close all the programs on the watch → Stop and restart Bluetooth and GPS → Connect again
- Check and enable notification functions of your phone and keep the phone and watch in close contact.
Note: Make sure your phone system meets Android 7.0 and above and iOS 12.0 and above.
My Watch Wave Call is receiving no alerts, texts, or phone calls
Make sure smart reminders on the app are on and synced to the Wave Call.
Also, make sure your watch's Do Not Disturb (DND) mode is off while displaying messages.
Only then will you receive notifications.
Make sure app is running in the background and battery optimization feature on the phone is disabled.
My Bluetooth keeps getting disconnected
- Make sure there is not too much distance between Bluetooth on the phone & the watch.
- There is no obstacle in between the watch and the phone.
- Make sure no app is running in the background that might disrupt the connection.
Which functions of the Wave Call need Bluetooth to work?
Call & Text Notifications, Find My Phone, music control, camera control, weather forecast, cloud and custom watch faces and Bluetooth calling need Bluetooth connectivity to work.
Will it be okay to take a bath wearing the Wave Call?
The IP68 water resistance will only work under the following conditions:
- Maximum depth of water: 1.5 m (2 m Maximum)
- Maximum time for exposure to water: 10 minutes
The watch isn't suitable for hot baths, hot springs, saunas, snorkeling, diving, water skiing and other wading or deep-water activities with high-speed water flow.
SAFETY & PRODUCT INFORMATION
Battery
Do not disassemble, bore or damage the battery.
Do not disassemble the built in batteries of non-replaceable battery devices.
Do not use sharp objects to remove the battery.
Health Warning
If you are wearing a pacemaker or other implanted electronic devices, please consult your doctor before using the heart rate monitor of the watch.
The optical heart rate sensor will glow green on wave Call. If you suffer from epilepsy or are sensitive to blinking light sources, please consult your physician before wearing this device.
The device tracks your daily activities through sensors. This data is intended to tell you about your daily activities such as steps, sleep, distance, heart rate and calories, but may not be completely accurate.
The device accessories, heart rate sensor, oxygen level monitor, and other relevant data is designed for fitness and not for medical purposes. They are not applicable to the diagnosis, monitoring, treatment or prevention of any diseases or symptoms. The heart rate and blood oxygen data data is for reference only. We're not responsible for any deviation in data.
Avoid wearing the watch too tightly. Make sure you keep your skin dry - the area that comes in contact with the watch. If symptoms such as redness or swelling appear on your skin, immediately stop using the watch and consult the doctor.
Things to keep in mind
Sync data everyday days to avoid data loss.
Water Resistance will not work for seawater, acidic and alkaline solutions, chemical reagents & other corrosive liquid. The damage or defects caused by misuse or improper use are not covered by the warranty.
Sports modes support up to 6 hours of exercise at a time.
Avoid wearing the watch too tight in daily use. Keep the parts of skin touching the watch dry.
Keep your arm still while measuring data for accurate measurement.
