OMNI-5215-SKU
Industrial Touch Panel PC
With 6
th
Gen. Intel® Core™ Processor
(Formerly code name: Skylake)
User's Manual 1
Ed
st
Last Updated: July 14, 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AAEON OMNI-5215-SKU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asus AAEON OMNI-5215-SKU

Summary of Contents for Asus AAEON OMNI-5215-SKU

  • Page 1 All manuals and user guides at all-guides.com OMNI-5215-SKU Industrial Touch Panel PC With 6 Gen. Intel® Core™ Processor (Formerly code name: Skylake) User’s Manual 1 Last Updated: July 14, 2017...

  • Page 2: Copyright Notice

    All manuals and user guides at all-guides.com Copyright Notice This document is copyrighted, 2017. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.
  • Page 3 All manuals and user guides at all-guides.com Acknowledgement All other products’ name or trademarks are properties of their respective owners. Microsoft Windows is a registered trademark of Microsoft Corp.  Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel Corporation ...

  • Page 4: Pin Terminal Block

    All manuals and user guides at all-guides.com Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity OMNI-5000-SKU Series Panel PC  Product CD with User’s Manual (in pdf) and drivers  3 Pin Terminal block ...

  • Page 5: About This Document

    All manuals and user guides at all-guides.com About this Document This User’s Manual contains all the essential information, such as detailed descriptions and explanations on the product’s hardware and software features (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product.

  • Page 6: Safety Precautions

    All manuals and user guides at all-guides.com Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. All cables and adapters supplied by AAEON are certified and in accordance with the material safety laws and regulations of the country of sale.
  • Page 7 All manuals and user guides at all-guides.com As most electronic components are sensitive to static electrical charge, be sure to ground yourself to prevent static charge when installing the internal components. Use a grounding wrist strap and contain all electronic components in any static-shielded containers.
  • Page 8 All manuals and user guides at all-guides.com FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
  • Page 9 All manuals and user guides at all-guides.com China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON Panel PC/ Workstation 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 ○ ○ ○ ○ ○ ○ 及其电子组件 外部信号 ○ ○...
  • Page 10 All manuals and user guides at all-guides.com China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products AAEON Panel PC/ Workstation Poisonous or Hazardous Substances or Elements Hexavalent Polybrominated Polybrominated Component Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd)

  • Page 11: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents Chapter 1 - Product Specifications ..................1 Specifications ......................2 1.1.1 OMNI-5215-SKU ..................4 Chapter 2 – Hardware Information ..................6 Dimensions ....................... 7 List of Jumpers ......................9 2.2.1 mSATA/Mini-Card Operating VCC Selection (JP1) ......
  • Page 12 All manuals and user guides at all-guides.com 2.3.12 USB 3.0 Ports (CN19) ................25 2.3.13 Battery (CN20) ..................26 2.3.14 CPU FAN (Optional) (CN21) ..............26 2.315. LAN (RJ45) Connector (CN23) ............... 26 2.316. External Power Input (CN25) ..............28 2.3.17 COM Port 2 (CN26)..................
  • Page 13 All manuals and user guides at all-guides.com Panel Configuration ..............57 3.5.2 Chipset: PCH-IO COnfiguration ............59 Setup submenu: Security ..................60 Setup submenu: Boot ................... 61 Boot: BBS Priorities....................62 Setup submenu: Save & Exit ................63 Chapter 4 – Drivers Installation & Touchscreen Settings ..........64 Product CD/DVD ....................

  • Page 14: Chapter 1 - Product Specifications

    All manuals and user guides at all-guides.com Chapter 1 Chapter 1 - Product Specifications...

  • Page 15: Specifications

    All manuals and user guides at all-guides.com Specifications System Intel Core™ i5-6300U, 2.4 GHz ® Processor  Intel Celeron™ 3955U, 2 GHz ® 204-pin DDR4 1866/2133 SODIMM x 1 System Memory  I0/100/1000Base-TX, RJ-45 x 3 Ethernet  USB 3.0 Type A x 2 Side I/O ...

  • Page 16: Power Supply

    All manuals and user guides at all-guides.com *AAEON suggests users use industrial grade wide temperature DRAM and wide temperature storage devices. -20 ~ 70°C (-4 ~ -158°F) Storage Temperature  90% @ 40°C, non-condensing Operating Humidity  Anti-Vibration 1 Grms/ 5 ~ 500 Hz/ Operation (HDD) ...

  • Page 17: Omni-5215-Sku

    All manuals and user guides at all-guides.com 1.1.1 OMNI-5215-SKU Mechanical IP65/ NEMA 4 for aluminum front bezel Construction  IP30 ECC chassis VESA 100 / Panel Mount / Stand Mounting  550 x 373 x 70 mm Dimension (W x H x D) ...
  • Page 18 All manuals and user guides at all-guides.com Lifetime —  Chapter 1 – Product Specifications...

  • Page 19: Chapter 2 - Hardware Information

    All manuals and user guides at all-guides.com Chapter 2 Chapter 2 – Hardware Information...

  • Page 20: Dimensions

    All manuals and user guides at all-guides.com Dimensions Chapter 2 – Hardware Information...
  • Page 21 All manuals and user guides at all-guides.com Chapter 2 – Hardware Information...

  • Page 22: List Of Jumpers

    All manuals and user guides at all-guides.com List of Jumpers Please refer to the table below for all of the system’s jumpers that you can configure for your application Label Function mSATA/Mini-Card Operating VCC Selection Resistive Touch Mode LVDS Port Backlight Lightness Control Mode Selection LVDS Port Backlight Inverter VCC Selection Auto Power Button Enable/Disable Selection Clear CMOS Jumper...

  • Page 23: Msata/Mini-Card Operating Vcc Selection (Jp1)

    All manuals and user guides at all-guides.com 2.2.1 mSATA/Mini-Card Operating VCC Selection (JP1) mSATA Mini-Card (Default) 2.2.2 Resistive Touch Mode (JP2) 4/8 Wires Mode 5 Wires Mode (Default) 2.2.3 LVDS Port Backlight Lightness Control Mode Selection (JP3) 1 2 3 VR Mode PWM Mode (Default) 2.2.4 LVDS Port Backlight Inverter VCC Selection (JP4)

  • Page 24: Auto Power Button Enable/Disable Selection (Jp5)

    All manuals and user guides at all-guides.com 2.2.5 Auto Power Button Enable/Disable Selection (JP5) Disable (Default) Enable 2.2.6 Clear CMOS (JP7) Normal (Default) Clear CMOS 2.2.7 COM2 Pin8 Function Selection (JP9) Ring(Default) +12V Chapter 2 – Hardware Information...

  • Page 25: Com1 Pin8 Function Selection (Jp10)

    All manuals and user guides at all-guides.com 2.2.8 COM1 Pin8 Function Selection (JP10) Ring(Default) +12V Chapter 2 – Hardware Information...

  • Page 26: List Of Connectors

    All manuals and user guides at all-guides.com List of Connectors Please refer to the table below for all of the system’s connectors that you can configure for your application Label Function Front Panel Connector VGA Connector(Optional) Mini-Card Slot (Full-Mini Card) Touch Screen Connector Micro SIM Card Socket eDP/LVDS Port...

  • Page 27: Front Panel Connector (Jp6)

    All manuals and user guides at all-guides.com CN24 USB 3.0/2.0 Port CN25 External Power Input CN26 COM Port 2 CN27 COM Port 1 2.3.1 Front Panel Connector (JP6) Signal Signal PWR_BTN- PWR_BTN+ HDD_LED- HDD_LED+ SPEAKER- SPEAKER+ PWR_LED- PWR_LED+ H/W RESET- H/W RESET+ 2.3.2 Mini-Card Slot (Full-Mini Card) (CN2) Pin Name...
  • Page 28 All manuals and user guides at all-guides.com Pin Name Signal Type Signal Level PCIE_CLK_REQ# PCIE_REF_CLK- DIFF PCIE_REF_CLK+ DIFF W_DISABLE# +3.3V PCIE_RST# +3.3V PCIE_RX-/MSATA_RX+ DIFF +3.3VSB +3.3V PCIE_RX+/MSATA_RX- DIFF +1.5V +1.5V SMB_CLK +3.3V PCIE_TX-/MSATA_TX- DIFF SMB_DATA +3.3V PCIE_TX+/MSATA_TX+ DIFF Chapter 2 – Hardware Information...

  • Page 29: Touch Screen Connector (Cn3)

    All manuals and user guides at all-guides.com Pin Name Signal Type Signal Level USB_D- DIFF USB_D+ DIFF +3.3VSB +3.3V +3.3VSB +3.3V +1.5V +1.5V +3.3VSB +3.3V 2.3.3 Touch Screen Connector (CN3) Chapter 2 – Hardware Information...
  • Page 30 All manuals and user guides at all-guides.com Signal Signal TOP EXCITE BOTTOM EXCITE LEFT EXCITE RIGHT EXCITE TOP SENSE BOTTOM SENSE LEFT SENSE RIGHT SENSE Signal Signal BOTTOM LEFT RIGHT Signal Signal UL(Y) Chapter 2 – Hardware Information...

  • Page 31: Micro Sim Card Socket (Cn4)

    All manuals and user guides at all-guides.com UR(H) LL(L) LR(X) SENSE(S) 2.3.4 Micro SIM Card Socket (CN4) Pin Name Signal Type Signal Level UIM_PWR UIM_RST UIM_CLK UIM_VPP UIM_DATA 2.3.5 eDP/LVDS Port (CN5) PIN 29 PIN 30 PIN 1 PIN 2 Chapter 2 –...
  • Page 32 All manuals and user guides at all-guides.com * LVDS LCD_PWR can be set to +3.3V or +5V by cable LVDS Function Pin Name Signal Type Signal Level BKL_ENABLE BKL_CONTROL LCD_PWR +3.3V/+5V LVDS_A_CLK- DIFF LVDS_A_CLK+ DIFF LCD_PWR +3.3V/+5V LVDS_DA0- DIFF LVDS_DA0+ DIFF LVDS_DA1- DIFF...
  • Page 33 All manuals and user guides at all-guides.com Pin Name Signal Type Signal Level LVDS_DB3- DIFF LVDS_DB3+ DIFF LCD_PWR +3.3V/+5V LVDS_B_CLK- DIFF LVDS_B_CLK+ DIFF eDP Function Pin Name Signal Type Signal Level BKL_ENABLE BKL_CONTROL LCD_PWR +3.3V/+5V eDP_TX3_D- DIFF eDP_TX3_D+ DIFF LCD_PWR +3.3V/+5V eDP_TX2_D- DIFF...

  • Page 34: Lvds Port Inverter / Backlight Connector (Cn8)

    All manuals and user guides at all-guides.com Pin Name Signal Type Signal Level eDP_AUX_D+ +3.3V LCD_PWR +3.3V/+5V 2.3.6 LVDS Port Inverter / Backlight Connector (CN8) Pin Name Signal Type Signal Level BKL_PWR +5V / +12V BKL_CONTROL BKL_ENABLE * LVDS BKL_PWR can be set to +5V or +12V by JP4 Chapter 2 –...

  • Page 35: Lpc Port (Cn11)

    All manuals and user guides at all-guides.com * LVDS BKL_CONTROL can be set by JP3 2.3.7 LPC Port (CN11) Pin Name Signal Type Signal Level LAD0 +3.3V LAD1 +3.3V LAD2 +3.3V LAD3 +3.3V +3.3V +3.3V LFRAME# LRESET# +3.3V LCLK LDRQ0 LDRQ1 SERIRQ +3.3V...

  • Page 36: Sata Port (Cn13)

    All manuals and user guides at all-guides.com Pin Name Signal Type Signal Level 2.3.9 SATA Port (CN13) Pin Name Signal Type Signal Level SATA_TX+ DIFF SATA_TX- DIFF SATA_RX- DIFF SATA_RX+ DIFF 2.3.10 BIOS Debug Port (CN14) Pin Name Signal Type Signal Level SPI_MISO SPI_CLK...

  • Page 37: Hdmi Connector (Cn15)

    All manuals and user guides at all-guides.com Pin Name Signal Type Signal Level SPI_CS 2.3.11 HDMI Connector (CN15) Pin Name Signal Type Signal Level DVI_D2+ DVI_D2- DVI_D1+ DVI_D1- DVI_D0+ DVI_D0- DVI_CLK+ DVI_CLK- Chapter 2 – Hardware Information...

  • Page 38: Usb 3.0 Ports (Cn19)

    All manuals and user guides at all-guides.com 2.3.12 USB 3.0 Ports (CN19) Pin Name Signal Type Signal Level +5VSB DIFF USB_D- DIFF USB_D+ DIFF USB_SSRX− DIFF USB_SSRX+ DIFF USB_SSTX− DIFF USB_SSTX+ +5VSB DIFF USB_D- DIFF USB_D+ DIFF USB_SSRX− DIFF USB_SSRX+ DIFF USB_SSTX−...

  • Page 39: Battery (Cn20)

    All manuals and user guides at all-guides.com 2.3.13 Battery (CN20) Pin Name Signal Type Signal Level +3.3V 3.3V 2.3.14 CPU FAN (Optional) (CN21) Pin Name Signal Type Signal Level +12V FAN_POWER FAN_TAC 2.315. LAN (RJ45) Connector (CN23) Signal Signal MDI0+ MDI0- MDI1+ MDI2+...
  • Page 40 All manuals and user guides at all-guides.com MDI3+ MDI3- Chapter 2 – Hardware Information...

  • Page 41: External Power Input (Cn25)

    All manuals and user guides at all-guides.com 2.316. External Power Input (CN25) Pin Name Signal Type Signal Level +9~+24V (or +12V +12V) 2.3.17 COM Port 2 (CN26) RS-232 Pin Name Signal Type Signal level ±5V ±5V ±5V RI/+5V/+12V IN/ PWR +5V/+12V RS-422 Pin Name...

  • Page 42: Com Port 1 (Cn27)

    All manuals and user guides at all-guides.com RS422_RX- NC/+5V/+12V +5V/+12V RS-485 Pin Name Signal Type Signal level RS485_D- ±5V RS485_D+ ±5V NC/+5V/+12V +5V/+12V * COM2 RS-232/422/485 can be set through BIOS setting. Default is RS-232. * Pin 8 function can be set by JP11. 2.3.18 COM Port 1 (CN27) RS-232 Pin Name...
  • Page 43 All manuals and user guides at all-guides.com ±5V ±5V ±5V RI/+5V/+12V IN/ PWR +5V/+12V RS-422 Pin Name Signal Type Signal level RS422_TX- ±5V RS422_TX+ ±5V RS422_RX+ RS422_RX- NC/+5V/+12V +5V/+12V RS-485 Pin Name Signal Type Signal level RS485_D- ±5V RS485_D+ ±5V Chapter 2 –...
  • Page 44 All manuals and user guides at all-guides.com NC/+5V/+12V +5V/+12V * COM1 RS-232/422/485 can be set through BIOS setting. Default is RS-232. * Pin 8 function can be set by JP9. Chapter 2 – Hardware Information...

  • Page 45: Installing The Hard Disk Drive

    All manuals and user guides at all-guides.com Installing the Hard Disk Drive Put the rubber provided onto the holes of the bracket. Place the HDD onto the bracket and secure with the screws provided * Users are advised to use storage devices provided and installed by AAEON. Chapter 2 –...

  • Page 46: Mount The Omni Onto The Wall

    All manuals and user guides at all-guides.com Mount the OMNI onto the wall Step 1 - Glue the water-proof rubber along back side of the panel Step 2 - Screw the provided mounting brackets into back of the panel Chapter 2 – Hardware Information...
  • Page 47 All manuals and user guides at all-guides.com Step 3 - Secure the panel with wall-mount brackets onto the wall with screws Chapter 2 – Hardware Information...

  • Page 48: P-Cap Touch Screen Operating

    All manuals and user guides at all-guides.com P-CAP Touch Screen Operating Always touch the screen with finger pads. The force of finger should be lower than 10g. Chapter 2 – Hardware Information...

  • Page 49: Chapter 3 - Ami Bios Setup

    All manuals and user guides at all-guides.com Chapter 3 Chapter 3 - AMI BIOS Setup...

  • Page 50: System Test And Initialization

    All manuals and user guides at all-guides.com System Test and Initialization The system uses certain routines to perform testing and initialization. If an error, fatal or non-fatal, is encountered, a few short beeps or an error message will be outputted. The board can usually continue the boot up sequence with non-fatal errors.

  • Page 51: Ami Bios Setup

    All manuals and user guides at all-guides.com AMI BIOS Setup The AMI BIOS ROM has a pre-installed Setup program that allows users to modify basic system configurations, which is stored in the battery-backed CMOS RAM and BIOS NVRAM so that the information is retained when the power is turned off. To enter BIOS Setup, press <Del>...

  • Page 52: Setup Submenu: Main

    All manuals and user guides at all-guides.com Setup Submenu: Main Chapter 3 – AMI BIOS Setup...

  • Page 53: Setup Submenu: Advanced

    All manuals and user guides at all-guides.com Setup Submenu: Advanced Chapter 3 – AMI BIOS Setup...

  • Page 54: Advanced: Cpu Configuration

    All manuals and user guides at all-guides.com 3.4.1 Advanced: CPU Configuration Chapter 3 – AMI BIOS Setup...
  • Page 55 All manuals and user guides at all-guides.com Chapter 3 – AMI BIOS Setup...
  • Page 56 All manuals and user guides at all-guides.com Options summary: Hyper-threading Disabled Enabled Optimal Default, Failsafe Default Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology). When Disabled only one thread per enabled core is enabled. Intel Virtualization Disabled Technology...

  • Page 57: Advanced: Sata Configuration

    All manuals and user guides at all-guides.com 3.4.2 Advanced: SATA Configuration Options summary: SATA Controller(s) Enabled Optimal Default, Failsafe Default Disabled Enable or Disable SATA Device. Port 0 Enabled Optimal Default, Failsafe Default Disabled Enable or Disable SATA Port. Hot Plug Enabled Disabled Optimal Default, Failsafe Default...

  • Page 58: Advanced: Hardware Monitor

    All manuals and user guides at all-guides.com 3.4.3 Advanced: Hardware Monitor Chapter 3 – AMI BIOS Setup...

  • Page 59: Advanced: Sio Configuration

    All manuals and user guides at all-guides.com 3.4.4 Advanced: SIO Configuration Chapter 3 – AMI BIOS Setup...

  • Page 60: Sio Configuration: Serial Port 1 Configuration

    All manuals and user guides at all-guides.com 3.4.4.1 SIO Configuration: Serial Port 1 Configuration Options summary: Use This Disabled Device Enabled Optimal Default, Failsafe Default Enable or Disable this Logical Device. Possible: Use Automatic Settings Optimal Default, Failsafe Default IO=2F8; IRQ=3; IO=3F8;...

  • Page 61: Sio Configuration: Serial Port 2 Configuration

    All manuals and user guides at all-guides.com 3.4.4.2 SIO Configuration: Serial Port 2 Configuration Options summary: Use This Disabled Device Enabled Optimal Default, Failsafe Default Enable or Disable this Logical Device. Possible: Use Automatic Settings Optimal Default, Failsafe Default IO=2F8; IRQ=3; IO=3F8;...

  • Page 62: Advanced: Usb Configuration

    All manuals and user guides at all-guides.com 3.4.5 Advanced: USB Configuration Options summary: Legacy USB Support Enabled Optimal Default, Failsafe Default Disabled Auto Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. Chapter 3 –...

  • Page 63: Advanced: Trusted Computing

    All manuals and user guides at all-guides.com 3.4.6 Advanced: Trusted Computing Chapter 3 – AMI BIOS Setup...
  • Page 64 All manuals and user guides at all-guides.com Options summary: Security Device Support Enabled Optimal Default, Failsafe Default Disabled Enables or Disables BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. TPM State Enabled Optimal Default, Failsafe Default...

  • Page 65: Advanced: Power Management

    All manuals and user guides at all-guides.com 3.4.7 Advanced: Power Management Chapter 3 – AMI BIOS Setup...
  • Page 66 All manuals and user guides at all-guides.com Options summary: Power Mode ATX Type Optimal Default, Failsafe Default AT Type Select power supply mode. Restore AC Power Last State Optimal Default, Failsafe Default Loss Power On Power Off Select power state when power is re-applied after a power failure. RTC wake system Disabled Optimal Default, Failsafe Default...

  • Page 67: Setup Submenu: Chipset

    All manuals and user guides at all-guides.com Setup submenu: Chipset Chapter 3 – AMI BIOS Setup...

  • Page 68: Chipset: System Agent (Sa) Configuration

    All manuals and user guides at all-guides.com 3.5.1 Chipset: System Agent (SA) Configuration Options summary: Max TOLUD Dynamic Optimal Default, Failsafe Default 1 GB 1.25 GB 1.5 GB 1.75 GB 2 GB 2.25 GB 2.5 GB 2.75 GB 3 GB Maximum Value of TOLUD (Top of Low Usable DRAM)\nDynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller.\nChanging this value may cause side effect, if reserved memory is lesser...

  • Page 69: System Agent (Sa) Configuration: Graphics Configuration

    All manuals and user guides at all-guides.com 3.5.1.1 System Agent (SA) Configuration: Graphics Configuration Options summary: Primary IGFX Boot VBIOS default Display HDMI LVDS Optimal Default, Failsafe Default Secondary IGFX Boot Disabled Optimal Default, Failsafe Default Display HDMI Select the Video Device which will be activated during POST. This has no effect if external graphics present.

  • Page 70: System Agent (Sa) Configuration: Graphics Configuration: Lvds

    All manuals and user guides at all-guides.com 3.5.1.1.1 System Agent (SA) Configuration: Graphics Configuration: LVDS Panel Configuration Chapter 3 – AMI BIOS Setup...
  • Page 71 All manuals and user guides at all-guides.com Options summary: LVDS Enabled Optimal Default, Failsafe Default Disabled Enable/Disable this panel Panel Type Auto Optimal Default, Failsafe Default Selection Manual Select LCD panel type by OMNI panel ID OMNI Panel Type OMNI-2155 Optimal Default, Failsafe Default OMNI-3105 OMNI-3125/3155...

  • Page 72: Chipset: Pch-Io Configuration

    All manuals and user guides at all-guides.com 3.5.2 Chipset: PCH-IO COnfiguration Options summary: HD Audio Disabled Enabled Optimal Default, Failsafe Default Control Detection of the HD-Audio device. Disabled = HDA will be unconditionally disabled Enabled = HDA will be unconditionally enabled Auto = HDA will be enabled if present, disabled otherwise.

  • Page 73: Setup Submenu: Security

    All manuals and user guides at all-guides.com Setup submenu: Security Change User/Administrator Password You can set a User Password once an Administrator Password is set. The password will be required during boot up, or when the user enters the Setup utility. Please Note that a User Password does not provide access to many of the features in the Setup utility.

  • Page 74: Setup Submenu: Boot

    All manuals and user guides at all-guides.com Setup submenu: Boot Options summary: Quiet Boot Disabled Enabled Optimal Default, Failsafe Default Enables or disables Quiet Boot option. Launch PXE OpROM Disabled Optimal Default, Failsafe Default Enabled Controls the execution of UEFI and Legacy PXE OpROM. Chapter 3 –...

  • Page 75: Boot: Bbs Priorities

    All manuals and user guides at all-guides.com Boot: BBS Priorities Chapter 3 – AMI BIOS Setup...

  • Page 76: Setup Submenu: Save & Exit

    All manuals and user guides at all-guides.com Setup submenu: Save & Exit Chapter 3 – AMI BIOS Setup...

  • Page 77: Chapter 4 - Drivers Installation & Touchscreen Settings

    All manuals and user guides at all-guides.com Chapter 4 Chapter 4 – Drivers Installation & Touchscreen Settings...

  • Page 78: Product Cd/Dvd

    All manuals and user guides at all-guides.com Product CD/DVD The OMNI-BT series comes with a product DVD that contains all the drivers and utilities you need to setup your product. Insert the DVD and follow the steps in the autorun program to install the drivers.
  • Page 79 All manuals and user guides at all-guides.com Follow the instructions Drivers will be installed automatically Step 5 – Install USB 3.0 Drivers Open the STEP5 - USB3.0 folder and select your OS Open the .exe file in the folder Follow the instructions Drivers will be installed automatically Step 6 –...
  • Page 80 All manuals and user guides at all-guides.com Chapter 4 – Driver Installation & Touchscreen Settings...
  • Page 81 All manuals and user guides at all-guides.com Reboot and log in as administrator Chapter 4 – Driver Installation & Touchscreen Settings...
  • Page 82 All manuals and user guides at all-guides.com Run patch.bat as administrator Chapter 4 – Driver Installation & Touchscreen Settings...
  • Page 83 All manuals and user guides at all-guides.com For Windows 8: Open the Apps Screen, right click on the Command Prompt tile and select Run as Administrator Chapter 4 – Driver Installation & Touchscreen Settings...
  • Page 84 All manuals and user guides at all-guides.com To install the driver (patch.bat), you will first have to locate the file in command prompt. To do that, first go to the directory which contains the file by entering <drive letter>: eg. if the driver is in D drive, enter D: You are now at the directory containing the installation file.
  • Page 85 All manuals and user guides at all-guides.com For Windows 10 Open the STEP8 – Serial Port Driver (Optional) folder and select Win10_32_64 Open the Setup.exe file in the folder Follow the instructions Drivers will be installed automatically Step 9 – Install DIO Driver (for DIO module only) Please refer to Appendix D –...

  • Page 86: Pcap Dual Monitor Touch Settings

    All manuals and user guides at all-guides.com PCAP Dual Monitor Touch Settings When two panels are used, they can set to be the primary and secondary display. The instruction below shows how this can be done: Go to Display Panel and choose your preferred primary display. Chapter 4 –...
  • Page 87 All manuals and user guides at all-guides.com Go to Tablet PC Settings in Control Panel. Under Display options, select the primary display from step 1. Apply the changes and exit. *Do NOT calibrate the screen on your own. Doing so might disrupt the device’s factory calibration Chapter 4 –...

  • Page 88: Appendix A - Watchdog Timer Programming

    All manuals and user guides at all-guides.com Appendix A Appendix A - Watchdog Timer Programming...

  • Page 89: Watchdog Timer Initial Program

    All manuals and user guides at all-guides.com Watchdog Timer Initial Program Table 1 : Super I/O relative register table Default Value Note SIO MB PnP Mode Index Register Index 0x2E(Note1) 0x2E or 0x4E SIO MB PnP Mode Data Register Data 0x2F(Note2) 0x2F or 0x4F Table 2 : Watchdog relative register table...
  • Page 90 All manuals and user guides at all-guides.com ******************************************************************************** // SuperIO relative definition (Please reference to Table 1) #define byte SIOIndex //This parameter is represented from Note1 #define byte SIOData //This parameter is represented from Note2 #define void IOWriteByte(byte IOPort, byte Value); #define byte IOReadByte(byte IOPort);...
  • Page 91 All manuals and user guides at all-guides.com ************************************************************************************ Main VOID // Procedure : AaeonWDTConfig // (byte)Timer : Time of WDT timer.(0x00~0xFF) // (boolean)Unit : Select time unit(0: second, 1: minute). AaeonWDTConfig(); // Procedure : AaeonWDTEnable // This procudure will enable the WDT counting. AaeonWDTEnable();...
  • Page 92 All manuals and user guides at all-guides.com ************************************************************************************ // Procedure : AaeonWDTEnable AaeonWDTEnable () VOID WDTEnableDisable( EnableLDN, EnableReg, EnableBit, 1 // Procedure : AaeonWDTConfig AaeonWDTConfig () VOID // Disable WDT counting WDTEnableDisable( EnableLDN, EnableReg, EnableBit, 0 // Clear Watchdog Timeout Status WDTClearTimeoutStatus();...
  • Page 93 All manuals and user guides at all-guides.com ************************************************************************************ SIOEnterMBPnPMode() VOID IOWriteByte(SIOIndex, 0x87); IOWriteByte(SIOIndex, 0x87); SIOExitMBPnPMode() VOID IOWriteByte(SIOIndex, 0xAA); SIOSelectLDN(byte LDN) VOID IOWriteByte(SIOIndex, 0x07); // SIO LDN Register Offset = 0x07 IOWriteByte(SIOData, SIOBitSet(byte LDN, byte Register, byte BitNum, byte Value) VOID Byte TmpValue;...

  • Page 94: Appendix B - I/O Information

    All manuals and user guides at all-guides.com Appendix B Appendix B - I/O Information...

  • Page 95: I/O Address Map

    All manuals and user guides at all-guides.com I/O Address Map Note: There is no PS/2 interface on the OMNI-SKU series, hence the exclamation marks Appendix B – I/O Information...
  • Page 96 All manuals and user guides at all-guides.com Appendix B – I/O Information...

  • Page 97: Memory Address Map

    All manuals and user guides at all-guides.com Memory Address Map Appendix B – I/O Information...
  • Page 98 All manuals and user guides at all-guides.com Appendix B – I/O Information...

  • Page 99: Irq Mapping Chart

    All manuals and user guides at all-guides.com IRQ Mapping Chart Appendix B – I/O Information...
  • Page 100 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 101 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 102 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 103 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 104 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 105 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 106 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 107 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 108 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 109 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 110 All manuals and user guides at all-guides.com Appendix B – I/O Information...
  • Page 111 All manuals and user guides at all-guides.com Appendix B – I/O Information...

  • Page 112: Appendix C - Canbus Utility (For Canbus Module)

    All manuals and user guides at all-guides.com Appendix C Appendix C – CANBus Utility (for CANBus Module)

  • Page 113: Canbus Driver Installation

    All manuals and user guides at all-guides.com CANBus Driver Installation Before using the utility, please follow the instructions below to install the drivers. For Windows 8.1 Locate the CANBus in Device Manager Right click and select Update driver Appendix C – CANBus Utility (for CANBus Module)
  • Page 114 All manuals and user guides at all-guides.com Choose Browse my computer for driver software and Next Click Have Disk and browse to the driver’s directory Appendix C – CANBus Utility (for CANBus Module)
  • Page 115 All manuals and user guides at all-guides.com After selecting the directory, click next and install the drivers Appendix C – CANBus Utility (for CANBus Module)
  • Page 116 All manuals and user guides at all-guides.com You should see this after the driver is successfully installed. Appendix C – CANBus Utility (for CANBus Module)

  • Page 117: Canbus Utility

    All manuals and user guides at all-guides.com C.2 CANBus Utility PORT NUMBER PORT BAUD RATE 115200 57600 iii. 38400 19200 9600 ONNECTION BUTTON IRMWARE VERSION BUS PORT SELECTOR BUS BAUD RATE PRESS SET TO APPLY CHANGE 125K Appendix C – CANBus Utility (for CANBus Module)
  • Page 118 All manuals and user guides at all-guides.com 500K iii. BUS MODE TANDARD OR XTENDED PRESS SET BUTTON TO APPLY CHANGE : ID 000~0 TANDARD RANGE WILL BE : ID 00000000~0 1FFFFFFF XTENDED RANGE WILL BE NABLE ISABLE MODE PRESS SET BUTTON TO APPLY CHANGE IS ENABLED A REMOTE FRAME WILL BE TRANSMITTED VIA THE BUS HIS MEANS THAT...

  • Page 119: Mask And Filter Function

    All manuals and user guides at all-guides.com C.3 Mask and Filter Function PECIFIED CANNOT BE RECEIVED ILTER NLY SPECIFIED CANNOT BE RECEIVED ORKS ON PORT THAT APPLY TO RECEIVE PORT Appendix C – CANBus Utility (for CANBus Module)

  • Page 120: Appendix D -Electrical Specifications For I/O Ports

    All manuals and user guides at all-guides.com Appendix D Appendix D –Electrical Specifications for I/O Ports...

  • Page 121: Digital I/O Register

    All manuals and user guides at all-guides.com Digital I/O Register Table 1 : SuperIO relative register table Default Value Note SIO MB PnP Mode Index Register Index 0x2E(Note1) 0x2E or 0x4E SIO MB PnP Mode Data Register Data 0x2F(Note2) 0x2F or 0x4F Table 2 : Digital Input relative register table Register BitNum...

  • Page 122: Digital I/O Sample Program

    All manuals and user guides at all-guides.com Digital I/O Sample Program ************************************************************************************ // SuperIO relative definition (Please reference to Table 1) #define byte SIOIndex //This parameter is represented from Note1 #define byte SIOData //This parameter is represented from Note2 #define void IOWriteByte(byte IOPort, byte Value); #define byte IOReadByte(byte IOPort);...
  • Page 123 All manuals and user guides at all-guides.com ************************************************************************************ // Digital Output control relative definition (Please reference to Table 3) #define byte DOutput1LDN // This parameter is represented from Note27 #define byte DOutput1Reg // This parameter is represented from Note28 #define byte DOutput1Bit // This parameter is represented from Note29 #define byte DOutput1Val // This parameter is represented from Note30 #define byte DOutput2LDN // This parameter is represented from Note31 #define byte DOutput2Reg // This parameter is represented from Note32...
  • Page 124 All manuals and user guides at all-guides.com ************************************************************************************ Main VOID Boolean PinStatus ; // Procedure : AaeonReadPinStatus // Input : Example, Read Digital I/O Pin 3 status // Output : InputStatus : 0: Digital I/O Pin level is low 1: Digital I/O Pin level is High PinStatus = AaeonReadPinStatus(DInput3LDN, DInput3Reg, DInput3Bit);...
  • Page 125 All manuals and user guides at all-guides.com ************************************************************************************ AaeonReadPinStatus(byte LDN, byte Register, byte BitNum) Boolean Boolean PinStatus ; PinStatus = SIOBitRead(LDN, Register, BitNum); Return PinStatus ; AaeonSetOutputLevel(byte LDN, byte Register, byte BitNum, byte Value) VOID ConfigToOutputMode(LDN, Register, BitNum); SIOBitSet(LDN, Register, BitNum, Value); ************************************************************************************ Appendix D –...
  • Page 126 All manuals and user guides at all-guides.com ************************************************************************************ SIOEnterMBPnPMode() VOID IOWriteByte(SIOIndex, 0x87); IOWriteByte(SIOIndex, 0x87); SIOExitMBPnPMode() VOID IOWriteByte(SIOIndex, 0xAA); SIOSelectLDN(byte LDN) VOID IOWriteByte(SIOIndex, 0x07); // SIO LDN Register Offset = 0x07 IOWriteByte(SIOData, SIOBitSet(byte LDN, byte Register, byte BitNum, byte Value) VOID Byte TmpValue;...
  • Page 127 All manuals and user guides at all-guides.com ************************************************************************************ SIOBitRead(byte LDN, byte Register, byte BitNum) Boolean Byte TmpValue; SIOEnterMBPnPMode(); SIOSelectLDN(LDN); IOWriteByte(SIOIndex, Register); TmpValue = IOReadByte(SIOData); TmpValue &= (1 << BitNum); SIOExitMBPnPMode(); If(TmpValue == 0) Return 0; Return 1; ConfigToOutputMode(byte LDN, byte Register, byte BitNum) VOID Byte TmpValue, OutputEnableReg;...

Table of Contents
