pardo Bora Merak Quick Reference Sheet

Bora Class/Merak Bed
Q
uick reference sheet
A B
E
B ' c
ed s oMponents
Screwed headboard
A
ABS mattress platform
B
Four tube side rails
C
Screwed footboard
D
www.pardo.es
TECHNICAL SERVICE CENTRE
(+34) 976 300 033
C D
F G
Wired patient control with locking
E
Double wheels Ø10 cm.
F
Centralised braking bar
G
Four tube side rails:
ƒ Rise side rails: Pull of the side rail towards head-
board up to hearing "click" from the lower handle,
then the side rail is locked in highest position.
ƒ Lower side rails: Unlock side rail lower handle pull-
ing of it down. Fold the said rail towards footboard
taking it until lowest position where it remains
locked.
Rise side rails
Lower side rails
c
leaning
Daily cleaning and disinfection with soapy water:
ƒ Rails. Head board. Foot board.
Cleaning and disinfection after a patient leaves or
before a transfer:
ƒ Mattress platform area. Chassis of the bed.
Thorough cleaning and disinfection every two
months:
ƒ Support and lifting area of the bed.
s r
ide ails
Continuous side rails:
ƒ Rise side rails: Pull the side rail up, from upper
board, until listening the locking indicator.
ƒ Lower side rails: Press the button placed in the
headboard and footboard, slightly raise the side
rail, and accompany it to its lowest position while
continuing to press the button.
Rise / Lower side rails
M
aintenance
Always check the correct state of:
ƒ Electrical wiring
ƒ Wheels.
ƒ Braking mechanisms.
For more information, please consult the
use and maintenance manual.
