HDMI OVER IP EXTENDER
• Power supply: DC 5V, usage only the supplied power unit, do not
use the power supply if it is damaged.
• Don't mixed up HDMI Extender Sender with HDMI Extender
Receiver.
INTRODUCTION
This product is a 4K@60Hz HDMI Extender kit consisting in a sender
and a receiver. The 4K@60Hz HDMI signal can be extended up to
120m via Cat.6 and above network cable, supporting one-to-one
connection, one-to-many connections via gigabit switch or switch
cascades and can be widely used in meetings, home entertainment,
educational presentations and other fields.
FEATURES
• High definition and low-latency transmission.
• Support up to 4096x2160@60Hz resolution, backward compatible.
• Compatible with Cat5e/6 or above network cables, transmission
distance of Cat6 cable is 120 meters.
• Support one-to-one or one-to many connections through the
gigabit switch.
• Lightning protection, surge protection, ESD protection.
• Support stable 24/7 operation.
PACKAGE CONTENTS
• HDMI EXTENDER sender TX x 1pc
• HDMI EXTENDER receiver RX x 1pc
• User manual x 1pc
• DC5V/1A x 2pcs
Note: above accessories are contented in the regular package
for the kit with transmitter and receiver. If buy HDMI Extender TX
or HDMI Extender RX separately, the package contents would
be different.
INSTALLATION REQUIREMENTS
1 HDMI source device (computer graphics card, DVD, PS3, HD
monitoring equipment, etc..)
2. HDMI display device like SDTV, projector with HDMI port.
3. Network cables: UTP/STP Cat5e/6 networking cables, which
following the standard of EIA568B
