- Page 1 ＠ Primal Personal Series Rack System PSSS0205...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions -------------------------------------------- 1 Instructions -------------------------------------------------------------- 2 Parts List ----------------------------------------------------------------- 3 Exploded View ------------------------------------------------------------ 7 Measurement Guide ------------------------------------------------------ 9 Assembly Instructions --------------------------------------------------- 11 Assembly ---------------------------------------------------------------- 12 Barbell Plate Spec ------------------------------------------------------- 36 Maintenance Schedule --------------------------------------------------- 37 General Maintenance Information --------------------------------------- 38 The weight stack group is optional Weight Training Tips ---------------------------------------------------- 40 Specifications ------------------------------------------------------------ 40... -
Page 3: Important Safety Instructions
Important Safety Instructions Instructions Before beginning assembly please take the time to read Before beginning any fitness program, you should obtain a instructions thoroughly. Please use the various lists in this complete physical examination from your physician. When using manual to make sure that all parts have been included in your exercise equipment, basic precautions should always be taken, carton. -
Page 4: Parts List
Parts List Note: some of these parts may come pre-installed. Item Name Spec Item Name Spec Left Bottom Support Assembly Sub Weight Plates Assembly Right Bottom Support Assembly Long Lined Pipe Assembly Left Rear Column Assembly Left bumper Assembly Right Rear Column Assembly Right bumper Assembly Upper Rear Connection Assembly Left Parallel Bar Assembly... - Page 5 Item Name Spec Item Name Spec HPA402 Cable 2 φ16 Flat Washer Φ30×Φ17.5×3 Iron based powder set Φ10.2×Φ16×24 Powder metallurgy sleeve Φ10.2×Φ16×20 φ89 Pulley Group Φ89×25.4 Buffer pad Φ50×Φ20×25 Flat Washer Φ11×Φ30×2.5 Buffer pad Φ60×Φ26×26 Weight plate(6kg-15) Compression Spring Φ26×70×Φ6 15 Hole Selection Shaft Φ25×475 Gourd Hook...
-
Page 6: Exploded View
Exploded View Without weight stack configuration 1 : 15 This part is available without weight stack configuration This part is available without weight stack configuration With weight stack configuration 1 : 15 With weight stack configuration This part is available with weight stack configuration Without weight stack configuration... -
Page 7: Measurement Guide
Measurement Guide Exploded View Cross Recessed Pan Head Tapping Screw Hex Socket Set Screw with Flat Point Flat Head Cap Screw Button Head Cap Screw Socket Head Cap Bolt Hex Bolt Item Name Spec Left Bottom Support Assembly Right Bottom Support Assembly Left Rear Column Assembly Right Rear Column Assembly Upper Rear Connection Assembly... -
Page 8: Assembly Instructions
Assembly Instructions Assembly Step 1 Assembly of the equipment takes professional installers about 2 1.Attach Left Rear Column Assembly (3) and Right Rear Column Assembly (4) to Left hours. If this is the first time you have assembled this type of Bottom Support Assembly (1) and Right Bottom Support Assembly (2). -
Page 9: Assembly
Step 2: Exploded View Assembly Step 2: The splint faces to the clamping column side Slide sleeve into stainless steel slide rail Item Name Spec Item Name Spec Pull Up Assembly Hex Bolt M10×85 Left Sliding Frame Assembly Hex Bolt M12×25 Right Sliding Frame Assembly Hex Bolt... - Page 10 Step 2 Assembly Step 3: with Weight Plates 1.Attach Left column assembly (28) and Right column assembly (29) to Left Bottom Support Assembly (1) and Right Bottom Support Assembly (2). 82 89 32 Using: Hex Bolt M12×25(83), Hex Bolt M12×85(85), Φ12 Flat Washer(90), M12 Nut(94) and L-Shape Contecting Piece165×165×5 (55).
- Page 11 Assembly Step 3: with Weight Plates Step 3: with Weight Plates 1.Put Buffer pad (65) on Rear Guide Pipe(12) and put them into the hole of Left Bottom Support Assembly(1) and Right Bottom Support Assembly(2),Place 15 weight plates on each side. 2.Attach Pulley Frame Assembly (10),Barbell Plate Support Assembly(17),15 Hole Selection Shaft(97) to Load Bearing Support Assembly(9).
- Page 12 Assembly Assembly Step 3: with Weight Plates Step 3: W/O Weight Plates 82 89 32 69 72 Teflon Pasted Teflon Pasted Item Name Spec Item Name Spec Load Bearing Support Assembly Guid Rod Φ25×2027 Pulley Frame Assembly Ring Plate Φ60×Φ26×3 Rear Guide Pipe Buffer pad Φ50×Φ20×25...
- Page 13 Step 3: W/O Weight Plates Step 4: Exploded View 1.Put Buffer pad (65) into Rear Guide Pipe(12),then attach to the hole of Left Bottom Support Mark: The upper four pulleys W/O wahsers Assembly(1) and Right Bottom Support Assembly(2),Barbell Plate Support Assembly(17),Buffer pad(65). 2.Attach Pulley Frame Assembly(10),Barbell Plate Support Assembly(17),15 Hole Selection Shaft(97)to Load Bearing Support Assembly(9).
- Page 14 Assembly Step 4: Step 4: 1.Attach Φ 89 Pulley Group(64), HPA402 Cable 1(60) to the double pulley board of Left Sliding Frame Assembly(26) and Right Sliding Frame Assembly(27), Using: Button Head Cap Bolt(74), Hex Bolt M12×85(85), Φ 10 Flat Washer(89), M10Nut(93). Cable ball end in outside.
- Page 15 Assembly Assembly Step 5: Exploded View Step 5: Short steel cable The upper two pulleys w/o washers Mark：the cable rope nose on the inside of the pulley sleeve Mark：the cable rope nose on the inside of the pulley sleeve Rope nose leftside Item Name Spec...
- Page 16 Step 5: Assembly Step 6: Exploded View 1.Attach HPA402 Cable 2 (61) to inside of the upper splint, Using: Hex Bolt(82), M10Nut(93), Iron based powder set(62), Φ 89 Pulley Group(64). 2.Fix the rope nose at one end of HPA402 Cable 2 (61) to the Left Connection Part Assembly(19) and Right Connection Part Assembly (20).
- Page 17 Step 6: Assembly Step 7: Exploded View 1.Attach Barbell rack assembly (30) to Left Rear Column Assembly (3) and Right Rear Column Assembly (4), Using: Hex Bolt(80), Φ 10Flat Washer(89). 2.Attach Left Shield (51) and Right Shield (52) to the main frame. Using: Hex BoltM6×16 (79).
- Page 18 Step 7: Assembly Step 8: Exploded View 1.Attach Left bumper Assembly (33) and Right bumper Assembly (34),Left Parallel Bar Assembly (35) and Right parallel bar Assembly (36),Left hook Assembly (37) and Right hook Assembly (38) to Left Sliding Frame Assembly (26) and Right Sliding Frame Assembly (27) separately.
- Page 19 Step 8: Assembly Step 9: Exploded View 1.Attach Poster Support Frame Assembly (8) to Upper Rear Connection Assembly (5), Using: Hex Bolt(83), Φ 12Flat Washer(90). 2.Attach Display Board Assembly Welding(11) to Poster Support Frame Assembly (8), Using: Button Head Cap Bolt(71), Φ 8 Flat Washer(88). 3.Attach Butterfly Clip (59) to Barbell Rack Assembly (25).
-
Page 20: Barbell Plate Spec
Step 9: Barbell Plate Spec 1.Attach High Pull Tube Assembly (42),High Tie Rod Assembly (43),Low Pull Tube Assembly (44), Ring Plate (53),Foot Pull (57) to the hook of Upper Rear Connection Assembly (5). Weight 10KG 15KG 20KG 25KG 2.Attach Rowing Grip Attachment Assembly (40) to the barbell tube on the rear of the main frame. -
Page 21: Maintenance Schedule
Maintenance Schedule COMMERCIAL HOME ROUTINE LATEST DATE ENTRY MAINTENANCE MAINTEMANCE Inspect: Links, Pull Pins, Snap Locks, Swivels, Weight Stack DAILY WEEKLY Pins Clean: Upholstery DAILY WEEKLY Inspect: Cables or Belts and DAILY WEEKLY their tension Inspect: Accessory Bars, and WEEKLY 3 MONTHS Handles Inspect: All Decals...
