DJ Controller
DDJ-SB2
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
DDJ-SB2
SXJ
DDJ-SB2
XJCN
This product is based on the DDJ-SB Performance DJ Controller, and some operation
keys have been added, modified, or deleted.
In this service manual, any difference from the DDJ-SB is described in each
corresponding section.
For matters not described in this manual, refer to the service manual of the DDJ-SB.
This service manual should be used together with the following manual(s).
Model No.
DDJ-SB/SXJ5
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
Pioneer DJ Corporation 2015
Power Requirement
DC 5 V (USB-bus power only)
DC 5 V (USB-bus power only)
Order No.
RRV4503
DDJ-SB/SXJ5
1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
DDJ-SB2
Remarks
K-MZV SEPT.
ORDER NO.
RRV4626
Remarks
2015 Printed in Japan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DDJ-SB2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PIONEER DJ DDJ-SB2

  • Page 1 PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 Pioneer DJ Corporation 2015 K-MZV SEPT. 2015 Printed in Japan...
  • Page 2: Table Of Contents

    (Refer to Service Manual for DDJ-SB) 1.2 NOTES ON PARTS REPLACEMENT ..........................3 1.3 SERVICE NOTICE (Refer to Service Manual for DDJ-SB) 1.4 DIFFERENCES BETWEEN THE DDJ-SB2 and DDJ-SB....................3 2. SPECIFICATIONS (Refer to Operating Instructions for DDJ-SB2) 3. BASIC ITEMS FOR SERVICE...............................4 3.1 CHECK POINTS AFTER SERVICING...
  • Page 3: Service Precautions

    After writing to the EEPROM, it will be updated to the latest state. 1.4 DIFFERENCES BETWEEN THE DDJ-SB2 and DDJ-SB The differences in the operating elements on the control panel of the DDJ-SB2 from those of the DDJ-SB are as follows: 1 DECK 3 and 4 buttons added...
  • Page 4: Basic Items For Service

    Mark No. Description Part No. Mark No. Description Part No. LIST OF ASSEMBLIES 1..PNL1 ASSY DWM2593 1..PNL2 ASSY DWM2579 2..PNL1 ASSY DWX3740 2..PNL2 ASSY DWX3741 2..HOLD2-1 ASSY DWX3787 2..CRFD ASSY DWX3742 2..HOLD1 ASSY DWX3743 2..HOLD2-2 ASSY DWX3788 1..IFPW ASSY DWX3569 DDJ-SB2...
  • Page 5: Block Diagram

    4. BLOCK DIAGRAM 1/4- JA501 AKB7181-A J A 1 0 1 D K N 1 2 3 7 - A When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST". IFPW ASSY MASTER OUT The >...
  • Page 6: Overall Block Diagram

    USB B JA101 Power RCA L/R IFPW ASSY JA501 Master L/R XOUT X201 IC201 VSS1210 For Power MUTE 6 MHz X'tal XOUT power supply MAIN UCOM-USB UCOM control line IC501 monitoring IC503 IC502 IC201 IC1001 MASTER_DATA IC401 BCLK NJM4580MD NJM4580MD AK4387ET USB_NRST S-80942CNMC-...
  • Page 7: Power Block Diagram

    V+3R3_D Rotate IC1002 V+3R3_UCOM V+3R3_UCOM MAIN UCOM 98, 99 V+3R3_AD L1003 Rotary VR / Slide VR ferrite bead V+3R3_AD V+3R3_AD Rotary VR to PNL2 / Slide VR V+5_LED V+5_LED V+5_LED V+5_LED to PNL2 IC1701/IC1702 OPAMP for MIC INPUT PNL1(JACK) DDJ-SB2...
  • Page 8: Diagnosis

    If the PWR_ON signal (between Pin 49 of IC1002 and the base of Q301) is "H," the error-detection circuit is not activated. Check the voltages of all power ICs. If they are normal, see "[1-2] Failure in the microcomputer system." DDJ-SB2...
  • Page 9 "8.3 WRITING TO THE EEPROM EEPROM FOR THE FOR THE USB CONTROLLER" above, reload USB CONTROLLER the program via USB. If reloading is successfully performed, the USB Controller (IC201) may be defective. If reloading fails, the EEPROM (IC202) may be defective. DDJ-SB2...
  • Page 10 Defective MAIN PNL1 Assy If the symptom persists after the above The MAIN UCOM (IC1002) may be defective. [7] Basic Operation UCOM (IC1002) corrections. Check of the MAIN UCOM DDJ-SB2...
  • Page 11 7. DISASSEMBLY Jog dial “Measuring method” in “6.1 SERVICE See "Procedure for applying grease during MODE_3 Judging the quality of the Jog reassembly of the jog dial" in "7. DISASSEMBLY." dial load.” DDJ-SB2...
  • Page 12: Usb Connection

    10 and 11 connection of the signal line or by a defective /defective parts of IC501 (DAC for MASTER OUT) to the resistor, capacitor, transistor, operational amps jacks (JA501). (IC502, IC503,) or jacks. DDJ-SB2...
  • Page 13 Identify the point where the audio signal is The audio signal may be interrupted by a loose ——— /defective parts interrupted on the line from CN1601 to the connection of the signal line or by a defective jack (JA1701). resistor, capacitor, or jack. DDJ-SB2...
  • Page 14 If nothing is wrong with these parts, the DAC for MASTER OUT (IC501) or for HP (IC701) or the MAIN UCOM (IC1002) may be defective. DDJ-SB2...
  • Page 15: Basic Operation Check Using Serato Dj Intro

    Connect such devices as a power amplifier, powered speakers, etc., to the [MASTER OUT] terminals. 3 Turn on the computer’ s power. Connect this unit to your computer via a cable. Turn on the power of the devices connected to the output terminals (power amplifier, powered speakers, etc.). DDJ-SB2...
  • Page 16: Starting The System

    3 Press the rotary selector (BACK) to move the cursor to the library panel on the computer screen, then turn the rotary selector (BACK) and select a track. 4 Press the [LOAD] button to load the selected track onto the deck. : Library panel : Crates panel DDJ-SB2...
  • Page 17 1 Press the headphones [CUE] button for the channel 1. 2 Turn the [HEADPHONES LEVEL] control. 1 Set the positions of the controls, etc., as shown below. Adjust the sound level output from the headphones to an appropriate level. 2 Press the [f] button to play the track. DDJ-SB2...
  • Page 18: Service Mode

    It is the mode which judges the quality of attachment of photointerrupter which detects rotation of jog dial. 5 A/D value fluctuation check mode The description of this mode is omitted, because this confirmation mode is provided for use by engineers. 6 Factory reset User settings is reset and it returns to a default. DDJ-SB2...
  • Page 19 * Refer to next clause. 36 Crossfader Slide VR (without center click) * Refer to next clause. 37 FILTER FADE button Tact SW FILTER FADE 41 MIC LEVEL control Rotary VR (without center click) * Firmware is not concerned. DDJ-SB2...
  • Page 20 Rotary selector (rotate) HEADPHONES LEVEL control Jog dial (rotate) (L) Rotary selector (rotate) Channel fader (L) Jog dial (rotate) (R) TRIM 1 control Channel fader (R) Jog dial (rotate) (R) TRIM 2 control Crossfader Jog dial (rotate) (R) — DDJ-SB2...
  • Page 21 (mode6) where push LOAD button and FX 2-3 is on, all LED of HOT CUE / AUTO LOOP / MANUAL LOOP/SAMPLER IN / OUT / RELOOP / 1/2X f / CUE / SYNC / SHIFT of the right deck can light up and reset. DDJ-SB2...
  • Page 22: Disassembly

    (2) Remove the 3 Silider knobs 2, 3 Slider knobs 1, 3 Stoppers/SLD. (Refer to the service manual of DDJ-SB.) The reference of the direction Side on which the line reaches the bottom ×3 Stopper Stopper (right direction) (rear direction) DDJ-SB2...
  • Page 23 (2) Disconnect the 2 flexible cables. (CN101, 102) CN101 IFPW Assy CN102 • CRFD Assy (1) Remove the CRFD Assy by removing the ×4 4 screws. (BPZ30P080FNI) Screw tightening order The other screws are random order. • Bottom view CRFD Assy DDJ-SB2...
  • Page 24 • PNL2 Assy (1) Remove the PNL2 Assy by removing the PNL2 Assy ×14 14 screws. (BPZ30P080FNI) Screw tightening order The other screws are random order. • Bottom view (2) Disconnect the 1 flexible cable. (CN2201) CN2201 PNL2 Assy DDJ-SB2...
  • Page 25: Jog Dial Section

    • Judging the quality of the Jog dial load * at the "NG" judgment execute habituation of the grease again. • PC1551, PC1552 (PNL1 Assy) • Judging the quality of mounting and connection of the PC2251, PC2252 (PNL2 Assy) photointerrupter DDJ-SB2...
  • Page 26: Items For Which User Settings Are Available

    Without the sync mode set Function disabled enabled disabled Jog dial MIDI message sending interval setting Back spin length setting 3 ms 4 ms 5 ms 6 ms 7 ms 9 ms 11 ms 13 ms short normal long DDJ-SB2...
  • Page 27: Exploded Views And Parts List

    NSP 10 Polyethylene Bag AHG7117 NSP 11 Warranty See Contrast table (2) (2) CONTRAST TABLE DDJ-SB2/SXJ and XJCN are constructed the same except for the following: Mark Symbol and Description DDJ-SB2/SXJ DDJ-SB2/XJCN Operating Instructions (Quick Start Guide)(En, Fr, De, It, Nl)
  • Page 28: Exterior Section

    9.2 EXTERIOR SECTION • Bottom view Grease (GEM1100) Grease (GEM1100) DAC3098 Grease (GEM1100) 1/3 - 3/3 DAC2952 1/3 - 3/3 1/2, 2/2 DDJ-SB2...
  • Page 29 DNK6530 38 • • • • • 39 • • • • • 40 Nut (M12) NKX2FNI 41 Washer WA62D095D050 42 Washer YC60FAC 43 Screw BBZ30P060FTC 44 Screw BPZ30P080FNI 45 Screw BPZ30P100FTB 46 Screw (M3*5) DBA1340 47 Screw PMH20P040FTC DDJ-SB2...
  • Page 30: Schematic Diagram

    10. SCHEMATIC DIAGRAM PNL1 ASSY (DWX3740) 4MHz CERAMIC RESONATOR DSS1131-A X1001 1:12B V+3R3_UCOM F 3/4 CN102 RESET IC F 2/4 R1015 2G;5B V+3R3_AD MAIN_NRST 1:11D,8G/2:10D,10C,10E,11E,11D,11G,11B,11C,6G,8B,9D,9C,9G,9E,9B/ F 2/4 F 2/4 V+3R3_UCOM F 2/4 CN1003 F 3/4 VKN2097-A IC1001 1:11D/3:2A,3A,4A,5A/ S-80927CNMC-G8X V+5_LED V+5_LED GND_D L1004...
  • Page 31: Pnl1 Assy (2/4)

    PNL1 ASSY (DWX3740) F 1/4,3/4 1:12B V+3R3_UCOM 1:7C 1:7C 1:7C V+3R3_AD V+3R3_AD V+3R3_AD C1206 C1222 C1236 KEY0 VR1203 VR1210 VR1217 KEY_IN_0 FXCTRL1 HIGH_1 HIGH_2 DCS1096-A DCS1097-A DCS1097-A 1:4G Q1202 LTC124EUB AD_FXCTRL1 AD_HIGH1 AD_HIGH2 1:5G 1:5G 1:8E 1:12B F 1/4 F 1/4 F 1/4 V+3R3_UCOM GND_D...
  • Page 32: Pnl1 Assy (3/4)

    PNL1 ASSY (DWX3740) F 1/4,2/4 1:8B 1:8B 1:8B 1:8B V+5_LED V+5_LED V+5_LED V+5_LED R1441 R1443 R1456 R1458 Q1401 Q1403 Q1405 Q1407 RED:LTL17KRH5D-TS LTC124EUB LTC124EUB LTC124EUB LTC124EUB AMBER:SLI-343YYW(TUV)-TS GND_D GND_D GND_D GND_D GREEN:LTL17KGH5D-TS BLUE:SLR343BD2T(NP)-TS GND_LED GND_LED GND_LED GND_LED FX1-2 FX1-3 FX1-1 CH2 LV5 F 1/4 LSCR523UB...
  • Page 33: D 10.4 Pnl1 Assy (4/4)

    PNL1 ASSY (DWX3740) CN101 HEAD PHONE OUT circuit CN1601 VKN1250-A 4:4F,4G,8F,7F/ V+7_J HP JACK R1616 DKN1653-A R1607 R1604 C1603 L1601 R1614 R1605 HP_R R1619 R1608 220u/10 R1612 V-6_J JA1601 4:4F,4G,7F,8F/ R1620 Q1601 GND_FP1 INC2002AC1 GND_AI R1606 GND_AI GND_AH GND_FHP GND_FHP2 R1617 GND_FP1 GND_FMIC...
  • Page 34: Pnl2 Assy (1/2)

    PNL2 ASSY (DWX3741) F X 2 - 3 F X 2 - 2 F X 2 - 1 2:2B 2:2B 2:2B 2:2B 2 : 2 B V + 5 _ L E D V + 5 _ L E D V + 5 _ L E D V + 5 _ L E D V + 3 R 3 _ U C O M...
  • Page 35: Pnl2 Assy (2/2)

    PNL2 ASSY ( DWX3741 1:2G,5G/ V+3R3_AD 2:2B 1:1E,4C,4D,4B/2:7E,8B,6E/ JOG TOUCH @PxrefLocat V+3R3_UCOM V+3R3_UCOM V+3R3_D2 1:10B,7B,8B,9B/ V+5_LED R 2 2 0 8 TO JOG Plate K N 2 2 0 1 1/4W A K F 7 0 0 2 - A D C N 1 1 8 7 - A V K N 2 0 9 7 - A R 2 2 0 3...
  • Page 36: Waveforms

    TP/Q1202 - B (KEY_IN_0) TP/VR2601 - pin 2 (AD_CRSFD) TP (JOG_TCH1) V: 2.0 V/div. H: 200 μS/div. V: 1.0 V/div. H: 100 mS/div. V: 1.0 V/div. H: 50 mS/div. TP/Q1202 - C (KEY_0) V: 2.0 V/div. H: 200 μS/div. DDJ-SB2...
  • Page 37 TP/IC1002 pin 51 (GRID_0) V: 5.0 V/div. H: 200 μS/div. Q1402 - C (V+5LED_GRID0) V: 5.0 V/div. H: 200 μS/div. Q1412 - C (GND_LED4) V: 2.0 V/div. H: 200 μS/div. Q1412 - B (LED_4) V: 2.0 V/div. H: 200 μS/div. DDJ-SB2...
  • Page 38: Pcb Connection Diagram

    11. PCB CONNECTION DIAGRAM SIDE A SIDE A CN101 CN102 PNL1 ASSY CN1003 CN1601 NOTE FOR PCB DIAGRAMS 1.The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic dia- IC1501 gram.
  • Page 39 SIDE B SIDE B PNL1 ASSY CN1003 CN1601 Q1404 Q1408 Q1409 Q1407 IC1551 Q1402 Q1406 Q1551 Q1401 Q1405 Q1552 Q1206 Q1421 Q1207 Q1202 Q1418 Q1417 IC1002 IC1702 Q1413 IC1001 IC1701 Q1422 Q1414 Q1203 Q1410 Q1411 Q1412 Q1601 Q1602 (DNP2788-A) (DNP2789-A) CRFD ASSY...
  • Page 40: Pnl2 Assy

    SIDE A SIDE B PNL2 ASSY PNL2 ASSY (DNP2789-A) (DNP2789-A) PC2251 IC2201 Q2002 Q2007 Q2062 Q2003 Q2054 IC2251 Q2252 PC2252 Q2051 Q2053 Q2052 Q2056 Q2251 Q2059 Q2001 Q2057 Q2060 Q2061...
  • Page 41: E 12. Pcb Parts List

    2..PNL1 ASSY DWX3740 2..HOLD1 ASSY DWX3743 2..HOLD2-1 ASSY DWX3787 2..HOLD2-2 ASSY DWX3788 1..IFPW ASSY DWX3569 DDJ-SB/SXJ5, DDJ-SB2/SXJ and DDJ-SB2/XJCN are constructed the same except for the following: Mark Symbol and Description DDJ-SB/SXJ5 DDJ-SB2/SXJ DDJ-SB2/XJCN Remarks 1..PNL1 ASSY DWX3570 Not used Not used 1..PNL1 ASSY...
  • Page 42 SLI-343YYW C 1009-1021,1024-1029 CKSRYB103K50 D 2072,2075-2077 LTL17KRH5D C 1033,1035-1037 CKSRYB103K50 D 2202 RB501VM-40 C 1038,1601,1602 CEJQ101M16 C 1039-1042 CCSRCH101J50 MISCELLANEOUS C 1044-1056,1205,1215 CKSRYB103K50 L 2001-2004 INDUCTOR CTF1629 C 1207-1210 CKSRYB105K10 L 2201,2202,2205 INDUCTOR CTF1379 KN 2201 EARTH TERMINAL AKF7002 DDJ-SB2...
  • Page 43: Ifpw Assy (Refer To Service Manual For Ddj-Sb)

    C 2203 CCSRCH221J50 C 2205 DCH1201 HOLD1 ASSY There is no service parts. HOLD2-1 ASSY There is no service parts. HOLD2-2 ASSY There is no service parts. IFPW ASSY The supply parts are, refer to Service Manual for DDJ-SB. DDJ-SB2...
