TD – 78607 A
HURF-300
Datum / Date: 22.12.2020
Hurricane Flip
Technical Data
Pressure
4000psi (27.5Mpa)
Temperature
250°F
RPM
max. 2000 rpm
Housing
ø12"
Water connection
3/8"NPTF
Nozzle connection
2x 1/8"NPTF
Throughput medium
water (pH 3-12)
|
Änderungen vorbehalten
|
Subjects to change without notice
S. 1/4
Advertisement
Related Manuals for Mosmatic Hurricane Flip
Summary of Contents for Mosmatic Hurricane Flip
- Page 1 TD – 78607 A HURF-300 Hurricane Flip Technical Data Pressure 4000psi (27.5Mpa) Temperature 250°F max. 2000 rpm Housing ø12" Water connection 3/8"NPTF Nozzle connection 2x 1/8“NPTF Throughput medium water (pH 3-12) Datum / Date: 22.12.2020 Änderungen vorbehalten Subjects to change without notice...
- Page 2 TD – 78607 A HURF-300 Hurricane Flip Indication: (original language German) • Read all instructions, check overall conditions and safety requirements before initial operation of the product. • Our products should only be installed by experienced users of high pressure equipment.
- Page 3 TD – 78607 A HURF-300 Hurricane Flip 180° Caster flip (original language German) 1. Pull up the ring (a) of the locking bolt, till the caster (b) is loose. 2. Turn the caster (b) by 180° upside down. 3. Release the ring (a) so the locking bolt clicks back in.
- Page 4 TD – 78607 A HURF-300 Hurricane Flip Pos. Art. Nr. Description 70.021 Quick connect plug (ø0.47") 42.906 Toggle joint 905.359 Guide plate 905.350 Cover 78.9005 Brush ring replacement-kit 58.913 Swivel unit (DYFk-90°-TKE) 1503 HP-nozzle (1503) 905.378 Protective plate (ø12") 80.9030 Caster flip (ø2.4") replacement-kit...
