Summary of Contents for Energizer Arc Solar 120
- Page 1 Arc Solar 120 Quick Start Guide Quick Start Guide...
-
Page 2: Included In The Box
Fast Charge USB Type-A Output up to 5V/2.1A, 9V/2A, DC 3.5mm DC 8mm “H” Barrel “K” Barrel 12V/1.5A. Adapter Tip Adapter Tip USB Type-A Output up to 5V/2.4A. USB Type-A Output up to 5V/2.4A. Arc Solar 120 www.energizerarc.com support@energizerarc.com | 1-877-528-3772... - Page 3 Quick Start Guide Remove the 10- MC4 cable and desired adaptor from the pocket. Unfold solar panel and release both kickstands. Place under direct sun in an unshaded area outside. See ‘Best Practice’ for more factors a ecting panel output. 2A) Output to USB: plug the USB cable into the junction box.
- Page 4 FAQs How do conditions affect the charge? phone to consistently draw the power it Sun angle, panel angle, distance from the needs. equator, clouds, shadows, temperature, Can I charge a lead acid battery? dirt, dust, and snow on the glass all a ect Yes, using a solar charge controller and the output of your panel.
-
Page 5: Best Practice
Some factors are more obvious such as optimize your panel setup to get the most cloud cover and shade, while other factors power out of your Arc Solar 120. are less obvious like the angle of the panel, geographical latitude, season, windows or dust. -
Page 6: Parallel Setup
Parallel Setup Connecting Two Solar Panels Solar panel branch connectors are used to connect two solar panels together for double the power output. This will speed up recharge times. 1) Connect the positive from both solar panels to the positive branch connector. 2) Connect the negative from both solar panels to the negative branch connector. -
Page 7: Specifications
Specifications Model Arc Solar 120 Maximum Power at STC (P 120W Tolerance Cell Type Monocrystalline Solar Cells Operating Temperature -15°C to 85°C Voltage at Pmax (V Current at Pmax (I 6.66A Open Circuit Voltage (V 21.6V Short Circuit Current (I 7.30A... -
Page 8: Warranty
DO NOT dispose in regular household trash. Inspect the unit prior to every use. The Arc Solar 120 produces 18V power. Check the Carefully read the instructions for the electric devices you recommended input voltage of the device to ensure the Arc intend to connect.
