Sofirn H35R User Manual

H35R
User Manual
Thank you for purchasing! Contact sofirnlight@gmail.com if you need any help!
H35R is a rechargeable multi-functional headlamp that has 5 emitters, providing both
white light and red light.
Technical Parameters
Modes Moonlight Low Medium High Turbo
White led 1LM 60LM 450LM 800LM 1500LM
Water-Resistant IPX6
Recharge 5V, 1A input via Hidden USB Port
Emitter 3 LEDs for white light+ 2 LEDs for red light
Dimension 84mm (length)× 23mm (head diameter)
Weight 80 ± 2 grams(excluding battery)
Battery 1*18650
* Note:
It's hard to test the output of red light. The wavelength of red light is 660 nanometers.
Battery Installation:
Unscrew the tail cap (the side opposite the button) and insert the 18650 battery with
the positive (+) terminal facing the switch. Then, screw the tail cap back on.
Operation Instruction:
1. Click(from off) to turn white light on. Long pressing (from off) to turn red light on.
2. Long pressing (from on) to cycle through Moonlight/Low/Medium/High/Turbo.
Recharging:
Please unscrew the cap(same side with the button) and plug in USB cable;
Charging Indicator:
Red = charging;
Green = fully charged
Tips:
1. Recharge or replace the battery when the battery indicator starts flashing.
2. Ensure the USB cable is connected to the USB port in the correct direction, and
disconnect the cable promptly once charging is complete.
