Model GXT67
INTRODUCTION
Thank you for choosing the GXT67 Series GMRS radio from Midland Radio Corporation. Please
read through this manual thoroughly to ensure you get peak performance from your radio. You
can also find additional information about the GXT67 on our website at Midlandusa.com or may
contact our Customer Service team at (816) 241-8500 from 8 AM to 4:30 PM (CT) Monday
through Friday for assistance.
FEATURES
Up to 30 GMRS Channels
o 30 Standard GMRS Channels
8 Standard GMRS Repeater Channels
285 Privacy Codes
o 38CTCSS
o 104DCS
o 143 Group
NOAA Weather Radio with Alert and Auto Scan
Waterproof and Dust-proof to IP67
4 VOX Levels
Group and Direct Call
10 Selectable Call Alert Tones
Vibrate Alert
Whisper Talk
Microphone Active Noise Cancellation (ANC)
SOS Siren
HI/MED/LO TX Power Settings
Selected Channel Scan and Dual Watch Pro
Backlight Off or 5 Brightness Levels
7 Backlight Colors
Battery Level Meter with Low battery Indicator
Narrow and Wide band operation
Silent Operation
Keypad Lock
Monitor
Roger Beep
Accessory Jack

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GXT67 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Midland Radio Corporation GXT67 Series

Summary of Contents for Midland Radio Corporation GXT67 Series

  • Page 1 Model GXT67 INTRODUCTION Thank you for choosing the GXT67 Series GMRS radio from Midland Radio Corporation. Please read through this manual thoroughly to ensure you get peak performance from your radio. You can also find additional information about the GXT67 on our website at Midlandusa.com or may contact our Customer Service team at (816) 241-8500 from 8 AM to 4:30 PM (CT) Monday through Friday for assistance.
  • Page 2 IMPORTANT NOTICE, FCC LICENSE REQUIRED FOR GMRS OPERATION (Only Applicable for GMRS Radio Use in the United States) The radios operate on GMRS (General Mobile Radio Service) frequencies which require an FCC (Federal Communications Commission) license. You must be licensed prior to operating the radio.

  • Page 3: Lcd Display

    LCD DISPLAY 1. NOAA Weather (WX) ICON – indicates when the radio is in Weather Band mode and Alert readiness status. 2. CHANNEL NUMBER – Indicates GMRS or Repeater channel number (1-99). In weather modes, indicates NOAA WX channel number (1-10). 3.
  • Page 4 CONTROLS AND INTERFACES 1. POWER/VOLUME KNOB – Turn clockwise to turn the power on and increase the volume level. Turn counter-clockwise to decrease the volume level and turn the power 2. ANTENNA 3. SPEAKER – Build-in speaker 4. PTT BUTTON – Press and hold to transmit voice communications. Within menus, acts as a “Back”...

  • Page 5: Installing The Belt Clip

    CHARGING THE BATTERY PACK Your GXT67 series radio comes with a rechargeable internal battery that can be charged using the desktop charger or the vehicle power adapter. The desktop charger and USB-C cable are compatible with industry-standard PD (Power Delivery) and quick-charging USB-C AC Wall adapters.

  • Page 6: Channel Selection

    OPERATING YOUR RADIO ABOUT RANGE Your GXT67 radio is designed to give you a maximum range under optimum conditions. [insert Midland range meter diagram] Optimum Conditions are: Over water Open rural areas without obstructions Flat areas where you can see the other person. To ensure you get maximum range: Be sure to use fresh or fully charged batteries –...

  • Page 7: Keypad Lock

    The GXT67 can send a “Call Tone” (direct call) to other radios to alert them you are about to transmit. Make sure Call Alert is turned on and a call tone is selected using the MENU function. 1. Briefly press the CALL/Lock button to transmit a CALL Alert. 2.
  • Page 8 Weather Modes Navigation [insert drawing of WX modes entry, navigation, & exit] From GMRS mode, p ress and hold the Menu/WX [ button g ra p hic ] button for 3 seconds to enter Weather Scan mode. Press Menu/WX again for Manual WX Channel Selection to set and listen to a selected Weather Channel.

  • Page 9: Channel Scan

    CHANNEL SCAN 1. Briefly press the Scan/Monitor button to turn Scan on or off. 2. The radio will rapidly scan through the selected channels stopping briefly on a channel in use to hear the conversation. NOTE: Each Channel can be configured to include in Channel Scan or to skip when scanning. 1.

  • Page 10: Group Mode

    1. The Menu [button graphic] button performs Forward / Next operations. Pressing Menu accepts and saves any changes and proceeds to the next menu level or the next selection item. If already at the lowest menu level or the last selected item, pressing Menu accepts any changes and returns to the prior menu level.

  • Page 11: Making A Group Call

    SET A GROUP CODE After selecting Group Mode On, press Menu to set the Group Code. Use the Up/Down arrow button to select one of the 143 group codes (0 – 142). Press MENU again to advance to the next setting, GROUP ID. SET GROUP ID 1.
  • Page 12 For each Repeater Channel (RPTR 15 through RPTR 22), separate Receive (RX) and Transmit (TX) Privacy Codes may be selected. Select the Repeater Channel you want to configure and press MENU, then select Privacy Codes as described in the SETTING PRIVACY CODES section - first for the RX Privacy Code, then for the TX Privacy Code.

  • Page 13: Roger Beep

    Select Channel Options (CHAN OPTIONS) from the Top Menu and press the MENU button. Select TX POWER in the CHAN OPTIONS menu, and press the MENU button. 3. Use the UP/Down Arrow to select between LOW, MEDIUM, or HIGH transmission power. 4.

  • Page 14: Whisper Mode

    Select RADIO OPTIONS from the Top Menu and press the MENU button. Select VIBRATE in the RADIO OPTIONS menu and press the MENU button. 3. Use the UP/Down Arrow to turn Vibrate Alert ON or Off.  The Vibrate Alert Icon will remain on when the function is activated. 4.
  • Page 15 1. Press the MENU button twice and increment to “DUAL WATCH PRO” then press the MENU button. 2. Use the UP/Down Arrow to turn Dual Watch ON and select the second channel to be scanned. 3. Once you have selected the primary channel, press the Menu button again to select the secondary channel.

  • Page 16: Troubleshooting Guide

    TROUBLESHOOTING GUIDE If you have a problem that you believe requires service, please call first and speak with a service technician at 816-241-8500. Many problems can be remedied over the phone without returning the unit for service. IMPORTANT: Changes or modifications to this unit not expressly approved by MIDLAND RADIO CORP.

  • Page 17: Specifications

    SPECIFICATIONS Channels: 30 GMRS Channels 10 NOAA Weather (WX) Band Channels Operating Frequency: 462.5500-462.7250MHz 462.5625-462.7125MHz 467.5500-467.7250MHz 467.5625-467.7125MHz Power Source: 7.4V 2400mAh Li-ion Battery...
  • Page 19 ACCESSORIES Accessories can be purchased at midlandusa.com AVP1 – Over the Ear Headsets AVPH2 – Closed Face Helmet Headset AVPH3 – Surveillance Headsets AVPH4 – Wrap Around the Ear Headsets AVPH5 – Behind the Head Headsets AVPH7 – Camo Headsets with Boom Mic AVP-H8 –...
  • Page 20 FCC Statement: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause...
