- Page 1 USERS MANUAL RF DATA LINK RADIOS 70-101BD 70-201BD idland Radio Corporation Important Information__________________________________________________________...
- Page 2 © Midland Radio Corporation This manual is designed to facilitate the set-up of the Midland 70-101BD and 70-201BD RF Data Link Radio series. As necessary, user manual supplements will be published and distributed on the following forms: Manual Addition (MA)……………For supplemental information...
- Page 3 Comments or suggestions concerning areas of manual improvement are welcome. CAUTIONS Exposure To Radio Frequency Energy Your Midland radio is designed to comply with the following national and international standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy: •...
- Page 4 TCXO ---------------------- Temperature Controlled Crystal Oscillator PLL ------------------------- Phase Locked Loop Installation and Setup Information for 70-101BD and 70-201BD Data Link Radios. Transmit/Receive channels are chosen from the frequencies programmed by switches inside the cover. Refer to the channel data list provided by your dealer or servicer and set the DIP switches for the desired frequency.
- Page 5 All connections to the unit are made through the DB9 connector. Connect wiring according to the diagram below. Connections to DB-9 connector: 1. Mod in (data). Audio sensitivity is 100mV RMS @ 60% Peak deviation. 2. AF out (data) (0.25 volt rms) 3.
