- Page 1 DVD KARAOKE SYSTEM SERVICE MANUAL REVISE (PCB) DKS-6000/DKS-6001 DKS-6100/DKS-6101 MODEL: DKS-6000/6001 DKS-6100/6101...
-
Page 2: Mpeg Schematic Diagram
❏ SCHEMATIC DIAGRAMS 1. MPEG SCHEMATIC DIAGRAM Video signal not oppeared System not working or scream is abnormal 27MHz Signal not oppeared 2-13 2-14... -
Page 3: Rf & Servo Schematic Diagram
2. RF & SERVO SCHEMATIC DIAGRAM TE, FE, RF Signal isn’t appear or bad Loading not move CD/DVD LD will not on Spindle not move Focus, Tacking, SLED will not move 2-15 2-16... - Page 4 3. AV JACK SCHEMATIC DIAGRAM 2CH Aduio out bad Video Signal CVBS Video Signal Y 2CH Aduio out bad Video Signal color 2cn Audio 2-17 2-18...
- Page 5 4. 5.1 CH & SCART SCHEMATIC DIAGRAM 5.1 CH Audio bad 2-19 2-20...
- Page 6 5. MIC SCHEMATIC DIAGRAM 2-21 2-22...
- Page 7 6. FRONT TIMER SCHEMATIC DIAGRAM (6000) LED abnormal Remocon not operate Digital abnormal System not operate or Digitron abnornd or key not operate. System not aperate. 2-23 2-24...
- Page 8 7. FRONT TIMER SCHEMATIC DIAGRAM (6100) LED abnormal Remocon not operate Digital abnormal System not operate or Digitron abnornd or key not operate. System not aperate. 2-25 2-26...
-
Page 9: Smps Schematic Diagram
7. SMPS SCHEMATIC DIAGRAM VF(+) Power Dead F102 is defective VF(-) Power Dead ZD101 is defective 12V Power dead IC103 is defectuve 8V Power Dead IC105 is defective 3.3V Power Dead IC106 is defective Power Dead IC101 is defective 5V Power Dead Q107 is defective 2-27 2-28... - Page 10 • MPEG P.C BOARD DIAGRAM 2-33 2-34...
- Page 11 • MPEG P.C BOARD DIAGRAM 2-35 2-36...
- Page 12 • MIC P.C BOARD DIAGRAM • I/O P.C BOARD DIAGRAM 2-37 2-38...
-
Page 13: Smps P.c Board Diagram
• SMPS P.C BOARD DIAGRAM 2-39 2-40...
