Page 2: Version History
Version History Version Author modify Release Date Remark V1.0...
Page 3: Table Of Contents
List 1 Document Introduction ............................5th 1.1 Document Purpose ............................5th 1.2 Document range ............................5th 1.3 Target audience ..............................5th 1.4 Instructions for Use ............................5th 2 Product Introduction ..............................6th 3 Product Application ...............................6th 4 Product Display ................................ 6th 4.1 Packaging ..............................6th 4.2 Accessories display ............................
Page 4 8.4.1 .................................33rd 8.4.2 Debug Mode .............................33rd 8.5 Language ..............................33rd 8.6 Native Information ..........................34th 9. Driver installation instructions ........................35th...
Page 5: Document Introduction
1 Document Introduction This document describes the product specifications and corresponding supporting instructions. 1.1 Document Purpose A narrative used to standardize the product itself and its supporting facilities, providing guidance for product packaging, promotion, and sales. 1.2 Document range This document is applicable to the product department, marketing department, pre-sales and after-sales support, testing department, and business department.
Page 6: Product Introduction
2 Product Introduction Product Name : Industrial Barcode Printer Product Model : XP-G480B / XP-G480E Product Features :  8 inch / s ( 203 dpi ) / 8 inch / s ( 300 dpi ) high-speed printing ( speed has a certain influence on the printing ...
Page 7: Accessories Display
4.2 Accessories display...
Page 8: Physical Appearance Display
4.3 Physical appearance display 4.4 Internal component display...
Page 9: Product Technical Parameters
5 Product Technical Parameters Printer Model XP-G480B XP-G480E Items 203 DPI 300 DPI Resolution ratio Thermal transfer printing and Thermal transfer printing and Printing style direct thermal sensitivity direct thermal sensitivity Print speed 200 mm (8") / s 200mm (8") / s Max print width 108mm (4.25”)
Page 10 Motor Single motor Default USB \Serial port \ network port Interface Option Parallel port \ WiFi \ Bluetooth built-in power supply INPUT: AC 100-240V 2.5A, 50-60Hz POWER Standard model Operating switches, 3 status lights, 6 buttons, 1 3.5-inch color display buttons, LED Gap sensor, cover opening sensor, black label sensor, paper output sensor Sensor...
Page 11 vertical: 1 mm max. Deviation of printed output level: 1 mm max. Eight bitmap fonts / Windows fonts can be downloaded through Built-in font software Codepage 437 (English - US) Codepage 737 (Greek) Codepage 850 (Latin-1) Codepage 855 (Cyrillic) Codepage 857 (Turkish) Codepage 860 (Portuguese) Codepage 861 (Icelandic) Codepage 862 (Hebrew) Codepage 863 (French Canadian) Codepage 864 (Arabic) Codepage 865 (Nordic) Codepage 866 (Russian) Codepage 869...
Page 12: Product Installation
②User manual； ③USB data line； ④Power line； ⑤Random paper ⑥Carbon belt Printer one year Reliability Printing head 30 kilometers or one year first ①Cutting knife； ②Peel off； Factory ③Bluetooth module； selection ④WiFi ⑤parallel Distributor None selection User selection None Large angle open cover design can be easily installed consumables The carbon belt capacity is 600 m.
Page 13: Install Paper
Note: * Please turn off the power switch of the printer and insert the power cord into the printer's power slot; * The interface of printer in the picture may vary depending on the type of model you purchased. Please refer to the product catalog specifications for the actual transmission interface。...
Page 14: Install Carbon Belt
6.2 Install carbon belt ( 1 ). Open the printer housing as shown in the picture. ( 2 ). Install the ribbon into the ribbon supply shaft. ( 3 ). Raise the print head and stick the ribbon around the ribbon recycling spokes according to the picture. ( 4 ).
Page 15 ( 5 ). Close the print head and close the lid. 15th...
Page 16: Product Interaction
7 Product Interaction This printer has six buttons and three indicator lights. Pressing buttons or turning on the power switch can activate multiple functions of the printer， For example: feeding paper, pausing printer operation, printing self check pages, etc., please refer to the following introduction.
Page 17: Function Of Push Buttom
7.2 Function of push buttom 7.2.1 Form feed When the printer is ready ( standby state ), click the feed button, will advance to the front of the next label paper. 7.2.2 Printing job suspended When the printer is printing, clicking the paper button will make the printing pause.
Page 18 8.2 Setup 18th...
Page 19: Tspl2 Setup
TSPL2 Setup 8.2.1 19th...
Page 20: Zpl2 Setup
8.2.2 ZPL2 Setup 20th...
Page 21 8.2.1- 1.1 Printing speed setting Use this option to set the printing speed of the printer 。 Adjustment range 2 ~ 8 ips ， The spacing between each increase and decrease is 1 ips。 Press up button，increase numerical value； Press down button，decrease numerical value; Press feed button，Determinable settings；...
Page 22 8.2.1 - 1.3 Printing direction Use this option to set printing direction of the printer。 Set printing direction to 1 or 0。 Press up button to adjust value to 1； Press down button to adjust value to 0； Press feed button，Determinable settings； Press menu button，To cancel setting and range to the upper menu;...
Page 23 Press feed button，Determinable settings； Press menu button，To cancel setting and range to the upper menu; 8.2.1 - 1.5 Offset adjustment This option can be used to adjust stop position of label paper after printing。 When using paper stripping or cutting function, it can be used to adjust position where the label stops，When printing next label, the part that was originally pushed out too much or too little will be compensated in a pulling manner；...
Page 24 Press up/down buttons to set+- or 0-9 values; Press feed button，Determinable settings； Press menu button，To cancel setting and range to the upper menu; 8.2.1 - 1.7 Reference point Use this option to adjust reference coordinates on the label paper relative to the origin； Press left and right buttons to move cursor left and right;...
Page 25: Sensor Settings
8.2.1 - 1.9 Country code Use this option to set printer's country code。When entering this option，Here”>”figure refers to currently country code； Press up and down buttons to select desired country code; Press feed button，Determinable settings； Press menu button，To cancel setting and range to the upper menu; 8.2.3 Sensor settings 8.2.3.1 Sensor status This option allows you to view sensor status of printer.
Page 26 the following information; 8.2.3.2 Sensor Corrections This option allows you to set detection mode of sensor and calibrate the required sensors based on the label paper used。It is recommended to redo the sensor calibration once label paper is replaced; A、Gap mode Press up and down buttons to select sensor type;...
Page 27 B. Black Label Mode Automatic black label correction When entering this option, the above information will appear on the LCD ，And printer will input 2-3 sheets of label paper for sensor calibration action. C.Continuous paper mode Press up and down buttons to select sensor type, and press feed button to complete the setting。...
Page 28: Serial Port Settings
Automatic continuous paper correction When entering this option, you will see above information. Printer will automatically perform sensor calibration on the paper. After completing the correction, it will return to the previous menu level. 8.2.4 Serial port settings 8.2.4.1 BAUD This option can set the transmission speed of printer RS-232;...
Page 29 When entering this option, the ">" image refers to currently set mode; Press up and down buttons to select desired mode up or down; Press feed button to complete the setting; Press menu button to cancel the setting and return to the previous menu level; 8.2.4.2 Parity test This option can set inspection bit for RS-232。...
Page 30 Press up and down buttons to select desired mode up or down; Press feed button to complete the setting; Press menu button to cancel the setting and return to the previous menu level; 8.2.4.4Stop bit This option can set stop bit for RS-232; When entering this option, the ">"...
Page 31: File Management
8.3 File management This option function allows you to view usage of printer memory, Flash TF card, and file management. 31st...
Page 32: File List
8.3.1 File list This option can display, delete, and execute(.BAS)documents stored in memory 8.3.2 Memory space 8.3.3 Delete file This option can delete files; 32nd...
Page 33: Print Debugging
8.4 Print debugging 8.4.1 Print self test page After selecting to print self-test page, printer will automatically print out the internal settings of printer. 8.4.2 Debug Mode After selecting this function, the printer will enter debugging mode. 8.5 Language 33rd...
Page 34: Native Information
This option can set language displayed on the display screen. When entering this option, the ">" image refers to currently set mode; Press up and down buttons to select desired mode up or down; Press feed button to complete the setting; Press menu button to cancel the setting and return to the previous menu level;...
Page 35: Driver Installation Instructions
This option can initialize the printer or view the serial number and printed mileage; Press up and down buttons to select desired mode up or down; Press feed button to complete the setting; Press menu button to cancel the setting and return to the previous menu level; 9.
Page 36 Please confirm that the printer is turned on, please use the special USB to select Run Driver Wizard after unpacking drivers, select complete (note that the 64-bit system above window7 requires permission authorization); 36th...
Page 37 Select to install the printer driver, select next; Please confirm that the printer has been started, please use a special USB data cable to connect the printer and the computer terminal, will automatically enter the Figure 6 interface; Select the driver to install the plug and play printer, select the printer model (the actual port 37th...
Page 38 may be different from the instruction manual), and click Next; Set the printer name selection next step; 38th...
Page 39 Determine that the correct setting and the selection is complete; In the equipment and the printer to generate the corresponding model of printer equipment is installed; Note: The model of the installation driver varies according to the machine model. 39th...
Page 40 FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
