Summary of Contents for iglooworks Keybox 3E
- Page 1 Installers & User guide Keybox 3E. Version 0.1 06/22...
- Page 2 In this guide, you’ll find everything you need to get started with your Keybox. If you do not find what you’re looking for, reach out to us at support@iglooworks.co. We’re here to help. Support & Help Portal: go.iglooworks.co/support Let’s stay connected:...
-
Page 3: Table Of Contents
Table of Contents What’s Included Specifications Lock Anatomy Lock Features Managing the Battery Emergency Jumpstart Pairing the Box Keybox Installation Modes of Access Managing Access Managing Lock Features Manage Lock Settings Audio and LED Indications Car Sharing Kit Car Sharing Kit Set-Up Connect with Airbnb Other Services Troubleshoot... -
Page 4: What's Included
What’s Included Keybox 3E Slim Shackle Mounting Seal Rings x2 Screwdriver Screws Anchors x2 AAA Alkaline Batteries x4 Mounting Screws x2 Chain... -
Page 5: Specifications
Specifications SK3E Body Zinc Alloy, Al Alloy Shackle Hardened Steel, Rubber Gross (with packaging) 1.3 kg / 2.7 lbs 1.5 kg / 3.3 lbs Modes of access (Entry) PIN Codes, Bluetooth keys Power type 4 X AAA Alkaline Batteries Battery life Up to 12 months Emergency power type USB-C jumpstart... -
Page 6: Lock Anatomy
Lock Anatomy Shackle Slim Shackle Unlock Clear Touch Screen Keypad USB-C Port... -
Page 7: Lock Features
Lock Features PIN Code/Bluetooth Key Master PIN Code Master Bluetooth Key The Keybox 3E unlocks with a The Keybox 3E unlocks with Bluetooth permanent Master PIN Code. via the app. Guest PIN Code Guest Bluetooth Key The Keybox 3E supports multiple The Keybox 3E supports User types of User PIN codes, e.g. - Page 8 Lock Features Others Security Lockout Decoy PIN Code Keypad is disabled after several Heighten security and throw off incorrect access attempts. onlookers by entering random digits before your actual PIN code. Auto Lock Manual Relock Automatically locks once the Manually lock the device by holding Keybox is shut to give you greater the ‘Unlock’...
-
Page 9: Managing The Battery
Managing the Battery Loosen the 4 screws and Insert AAA Batteries remove battery cover Battery Cover Secure battery cover tightly with 4 screws Please screw the battery cover tightly after inserting batteries to ensure optimal water resistance. * DO NOT USE: Heavy Duty, Eveready, GP, or rechargeable batteries. Duracell &... -
Page 10: Emergency Jumpstart
Emergency Jumpstart USB-C Jumpstart 1. Connect the USB-A to USB-C cable to a power bank then plug it onto the USB-C jumpstart port on the keybox. 2. While the USB-A to USB-C cable is connected to the power bank, key in PIN code on the keypad followed by to unlock. -
Page 11: Pairing The Box
The LED indicator on the lock will flash green when it is successfully unlocked. You will also hear four ascending tones. Once you have tested it, you can now begin to pair the lock to your iglooworks account. Select [Locks] from the menu. -
Page 12: Keybox Installation
Keybox Installation Secure Keybox 3E on a handle or knob 1. Unlock the keybox 2. Push the shackle release to the right 3. Pull out the shackle 4. Secure on a handle or knob 5. Insert back the shackle Shackle... - Page 13 Mount on a surface 1. Unlock the Keybox 3E 2. Drill holes on a wall 3. Hammer the screw anchors into the holes 4. Mount the keybox on the wall with the mounting seal rings and 2 screws Mounting Seal Rings...
-
Page 14: Modes Of Access
Modes of Access PIN Code As the owner of the lock, you can use the Master PIN code, issue Guest PIN codes, and test the lock during set-up with the Factory PIN code. Permanent PIN code that works every time. Master PIN Code Can be customized via Bluetooth by lock owner. - Page 15 3. The LED indicator on the lock will flash blue to establish the Bluetooth connection, then green when it is successfully unlocked. You will also hear four ascending tones. Home Keybox 3E Note: You need to be within Bluetooth range of the lock, and have your Bluetooth services switched on.
-
Page 16: Managing Access
Managing Access Creating Guest PIN codes There are 2 ways to create PIN codes for your guests and family members. Choose from several PIN code validity durations to manage access for different users. a) If you are away from your property, generate PIN codes on the go with our unique algoPIN™... - Page 17 Create Guest Bluetooth Keys Allow guests and family members to use their smartphones to unlock the door. When you issue a Bluetooth key, you get real-time updates on who has accessed your property. 1. On the igloohome mobile app, tap on the 2.
-
Page 18: Managing Lock Features
Managing Lock Features You can configure the duration before Auto Lock is triggered: *Please ensure you are within Bluetooth range of the lock and your Bluetooth function is turned on. 1. On your app, tap [Lock Settings]. 2.Select [Auto Lock Timer] Auto Lock 3. - Page 19 1. Connect the USB-A to USB-C cable to a power bank. 2. Plug the USB-C port into the jumpstart port on the lock. Emergency Jumpstart 3. Once the lock powers up, enter a valid PIN code within 20 seconds, followed by to unlock.
-
Page 20: Manage Lock Settings
Manage Lock Settings To delete a lock from your account, you will need to unpair the device: *Please ensure you are within Bluetooth range of the lock and your Bluetooth function is turned on. Delete Lock 1. On your igloohome app, tap on 2. -
Page 21: Audio And Led Indications
Audio and LED Indications Actions Indications Bluetooth Connection LED Indicator flashes Blue Ascending 4 fast tones after unlocked Successfully Unlocked and flash Green LED 2 times 1 long beep after product is locked and Successfully Locked Green LED for 2 seconds Incorrect PIN 4 short beeps and flash Red 2 times Deleted PIN... -
Page 22: Car Sharing Kit
Car Sharing Kit The Keybox 3E is also compatible with the igloohome Car Sharing Kit. Designed to offer a seamless car-sharing experience for everyone, the kit lets you transform any vehicle into one that’s ready for safe sharing. * NOTE: The Car Sharing Kit is sold separately. -
Page 23: Car Sharing Kit Set-Up
Car Sharing Kit Set-Up Preparing the Keybox for installation 1. Unlock Keybox and unscrew the guard plate 2. Remove rubber bumper from the back of Keybox 3. Release shackle from the Keybox and mount onto the Car Mount Side View Unlock with Factory PIN Code 1 2 3 4 5 6 7 8 9 0 Shackle... - Page 24 Installing the Keybox on the Car Mount for use 4. Secure Keybox to Car Mount with the provided nuts and bolts 5. Place the car key fob into the Faraday Pouch 6. Place the pouch into the Keybox and close it 7.
-
Page 25: Connect With Airbnb
Connect with Airbnb Connect with Airbnb Airbnb Connect automates the generation of PIN codes for your Airbnb guests based on their approved reservations. Here are the steps to activate Airbnb Connect Step 1: Connect to your Airbnb Under [Account Settings], select [Connect with Airbnb], then click [OK]. Step 2: Connect to Airbnb listings Under [Reservations], click the [Add] icon to select a home to connect to. -
Page 26: Other Services
Other Services This lock supports iglooconnect and igloodeveloper services. iglooconnect iglooconnect is a platform for you to integrate your locks with a myriad of third-party services. Whether it’s managing facility booking, property management or vacation rental hosting, iglooconnect lets you simplify workflows. If you’re a lock owner that’s looking to get more out of your device, connect to our network of service providers’... - Page 27 1. On the igloohome app, go to Account Settings. 2. Tap [iglooconnect]. Removing locks 3. Select the service provider you want to unlink the lock from. from integration 4. Select the lock you want to unlink. slots 5. Tap the icon.
- Page 28 Speak with your owner or admin to get your accounts set up before you proceed. Once you receive an invite, you can register for an iglooworks account to start operating the lock on the ground.
-
Page 29: Troubleshoot
Troubleshoot I am unable to close the Keybox 3E. I closed the Keybox 3E but it did not relock automatically. • Do an unlock via PIN code or Bluetooth and try • Make sure Auto Lock is ON via the to close the keybox again. - Page 30 FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 31 IC Caution RSS-Gen Issue 5 “&” RSS-Gen numéro 5 English : This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 32 EU Declaration of Conformity (EN) igloocompany Pte. Ltd hereby declares that it is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The EU Declaration of Conformity can be found in the link below. (DE) Hiermit erklärt igloocompany Pte. Ltd, dass sich diese in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 2014/53/EU befindet.
- Page 33 (SK) igloocompany Pte. Ltd týmto vyhlasuje, že splňuje základné požiadavky a ostatné príslušné ustanovenia Smernice 2014/53/EÚ. EÚ vyhlásenie o zhode je k dispozícii na nižšie uvedenom odkaze. Frequency Maximum Power 2.4 Ghz (Bluetooth) < 20 dBm https:/ /go.iglooworks.co/SK3Esupport...
- Page 34 For more support articles, go to: iglooworks.co/support...
