- Page 1 Operating Instructions Included Installation Instructions Wireless Antenna Unit For professional use only WX-AU202P Model No. WX -AU 202 PO WE R RE G MI C1 MI C2 Before operating this product, please read this instructions carefully and save this manual for future use.
-
Page 2: Safety Precautions
Trade Name: Panasonic 1.92 GHz to 1.93 GHz, and the power Model No.: WX-AU202P output level is 115 mW (max.).) Responsible Party: Do not use the unit in health care Panasonic Corporation of North... - Page 3 NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 4: Before Use
● It is easy to install and can be mounted on the ceiling or wall. Disclaimer of warranty IN NO EVENT SHALL Panasonic Connect Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE... -
Page 5: Open Source Software
Copyright, etc. Excluding the parts mentioned above, the rights to this software and other pieces of intellectual property belong to the Panasonic Connect Co., Ltd. or to third parties, and are not transferred to the customer. Panasonic Connect Co., Ltd. does not take any responsibility for damages, losses, etc. -
Page 6: Copyright
Before use Copyright Except for open source software licensed under GPL/LGPL and so on, distributing, copying, disassembling, reverse compiling and reverse engineering of the software provided with this product are all expressly prohibited. In addition, exporting any software provided with this product violating export laws is prohibited. Regarding radio waves ●... -
Page 7: Table Of Contents
Contents Safety precautions …………………………………………………………… 2 Before use …………………………………………………………………… 4 Preface ……………………………………………………………………………………… 4 Disclaimer of warranty ……………………………………………………………………… 4 Open source software ……………………………………………………………………… 5 Copyright ……………………………………………………………………………………… 6 Regarding radio waves ……………………………………………………………………… 6 Contents ……………………………………………………………………… 7 Precautions …………………………………………………………………… 8 Operating precautions …………………………………………………… 11 Major operating controls and their functions…………………………... -
Page 8: Precautions
Precautions Panasonic Connect Co., Ltd. assumes no responsibility for injuries or property damage resulting from failures arising out of improper installation, operation inconsistent with this documentation or through use of parts other than this product, such as locally procured parts. - Page 9 ● Do not bring the product near medical equipment (do not bring it into operation rooms, ICUs, CCUs, etc.) The radio waves emitted from the product may interfere with the medical equipment causing it to malfunction and lead to accidents. ●...
- Page 10 Precautions ● Install at a height where people will not run into the product. It may lead to injury. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body.
-
Page 11: Operating Precautions
Operating precautions This product is a Professional equipment. This product is designed to be used indoors. ● This product is not operable outdoors. ● Do not expose this product to direct sunlight for hours and do not install the product near a heater or an air conditioner. -
Page 12: Major Operating Controls And Their Functions
Major operating controls and their functions Front panel Side panel Rear panel WX-AU202 POWER MIC1 MIC2 Power indicator [POWER] Displays the power status of the unit. Lit (green) :Power is on Blinking (green) : Cannot perform wireless synchronization on startup when power is on, or wireless synchronization is lost during operation (when sub-antenna is set) Note:... - Page 13 Registration button [REG] This button performs operations related to ID registration between the target channel and microphone. ● ID registration : Press for at least 2 seconds to enter ID registration mode and activate MIC1 registration mode. If you then press again briefly, it will enter MIC2 registration mode. ●...
-
Page 14: About Operation Settings
About operation settings The operation settings of this unit are set from the Microphone System Configuration Center (Mic CC) connected to the Ceiling Array Microphone to which this unit is connected. The available options are shown in the table below. For details about the settings, please refer to the Operating Instructions for the Ceiling Array Microphone and Mic CC. -
Page 15: How To Install
How to install ■ Notes on installation WARNING: ● Ask your dealer to carry out the installation work. Before starting the installation work, power off the units to be connected. In addition, read the “Safety precautions” section carefully and follow its instructions. Be sure to also read the instructions that came with the unit to be connected. - Page 16 How to install Parts required for installation • For information on screws and other parts required for installation, refer to the relevant sections in this manual. Avoid installing in the following locations. • Locations in direct sunlight or near warm-air vents •...
- Page 17 Equipment classification and power source indication label Refer to the indication label on the rear panel of this unit for the equipment classification, power source, and other information. Regarding tightening the screws ● Make sure the screws remain straight as you tighten them. After tightening the screws, inspect them visually to make sure they are securely in place with no rattling.
-
Page 18: Ceiling-Mounted Installation
How to install ■ Ceiling-mounted installation Disconnect the cable from the unit and install in accordance with the following instructions. Drill a hole in the ceiling panel. Drill a Ø65 mm (2-9/16 inches) hole in the ceiling panel. Drill at a position shifted 30 mm (1-3/16 inches) to the right from the targeted center of this unit installation. - Page 19 Secure the fixing bracket (accessory). Slide the ceiling mounting screws installed in step through the fixing bracket holes and temporarily hold it. Secure the fixing bracket. At this time, note the orientation indicated by on the fixing bracket. The indicates the up direction for the product. ●...
- Page 20 How to install ● As shown in the figure below, pass the supplied cable tie through the cable tie fixing part to secure the connection cable, and then pass it halfway through the cable fixing groove at the rear panel of the unit to avoid pinching the cable when installing the unit.
-
Page 21: Wall-Mounted Installation (Using The Fixing Bracket)
■ Wall-mounted installation (using the fixing bracket) To install this product, disconnect the cable from the unit, and then install it in accordance with the following instructions. Screw the fixing bracket to the wall. Use the 4 supplied wood screws (4.1 mm × 25 mm) to mount the fixing bracket (accessory). - Page 22 How to install Connect the cable to the unit. Connect the CAT 5e or CAT 6 straight-through cable to the unit. For the cable connection, refer to “How to connect” (page 24). ● When pulling out the connection cable through the top of the unit, pass the supplied cable tie through the cable tie fixing part to secure the connection cable as shown in the figure below, pass it through the cable fixing groove at the rear panel of the unit, and pull the cable out through the top of the unit.
- Page 23 Mount the unit. Mount the unit by catching the notches on the hooks on the fixing bracket. (4 places) Notches Screwdriver Hooks WX-A U202 POW ER MIC1 MIC2 Open the screw cover on the side of the unit, and secure the unit to the fixing bracket using the supplied unit mounting screw (M3 ×...
-
Page 24: How To Connect
How to connect Power can be received by connecting this unit to the Ceiling Array Microphone. In addition, you can output the audio from the microphones to the Ceiling Array Microphone, output the audio from the amplifier and speakers connected to the Ceiling Array Microphone, and output the audio sent to a remote destination for teleconference. -
Page 25: Id Registration
ID registration In order to establish communication between this unit and a microphone, it is necessary to register a pairing (hereinafter referred to as “registration”) between them. Registration is done when you want to use a microphone that has not been registered with this unit, or when a registration error occurs. - Page 26 ID registration Register the microphone. If you press the registration button of the microphone for at least 2 seconds while the power of the microphone to be registered is “on”, the power indicator of the microphone blinks orange and registration starts. When registration completes successfully, the power indicator on the microphone will change to the normal lighting state (green/orange/red) according to the remaining battery level, and the registration indicator for the registered channel on the unit will...
-
Page 27: About Microphone System Configuration Center
About Microphone System Configuration Center The settings and status of this unit can be managed from the Microphone System Configuration Center (Mic CC) connected to the Ceiling Array Microphone to which this unit is connected. The unit settings and status management functions in Mic CC are as follows. For details, please refer to the Operating Instructions of Mic CC. -
Page 28: Dimensions
Dimensions Unit: mm/inch (1-1/4 inches) 212 (8-11/32 inches) WX-AU202 POWER MIC1 MIC2... -
Page 29: Troubleshooting
Troubleshooting Check the following before requesting repair. Consult your sales shop if these measures do not resolve a problem, if symptoms not listed here occur. Reference Symptom Cause/solution pages Power indicator ● Is power being supplied? 12, 24 ¨ Check the connection between the unit and the does not light Ceiling Array Microphone. -
Page 30: Specifications
Specifications Wireless Operating 1921.536 MHz to 1928.448 MHz frequency Antenna Internal antenna Reception 3 Diversity reception Power Power source DC24 V Power source Ceiling Array Microphone WX-AM800P Connector RJ-45 Compatible CAT 5e/CAT 6 straight-through cable* cables Field selection Three step selection Microphone Number of 2 channels... -
Page 31: Standard Accessories
Standard accessories Operating Instructions (this manual)..................1 Ceiling mounting plate ......................1 Fixing bracket ........................1 Ceiling mounting screws (M4 × 35 mm) ................2 Unit mounting screw (M3 × 8 mm) ..................1 Wood screws (4.1 mm × 25 mm)...................4 Cable tie ..........................1... - Page 32 Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 https://na.panasonic.com/us/ © Panasonic Connect Co., Ltd. 2023 Cv1023-0 PUQX1066ZA Printed in Vietnam...
