Summary of Contents for Denon ASD-1RWT
- Page 1 Control Dock for iPod ® ASD-1R OPERATING INSTRUCTIONS BEDIENUNGSANLEITUNG MODE D’EMPLOI ISTRUZIONI PER L’USO INSTRUCCIONES DE FUNCIONAMIENTO GEBRUIKSAANWIJZING BRUKSANVISNING 操作說明書 操作说明书 iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
- Page 2 This product, when installed as indicated in the instructions contained in this verwendete Netzsteckdose leicht zugänglich ist. manual, meets FCC requirements. Modification not expressly approved by DENON may void your authority, granted by the FCC, to use the product. PRECAUTION: Pour déconnecter complètement ce produit du courant secteur, débranchez 3.
- Page 3 SVENSKA NEDERLANDS ESPAÑOL ITALIANO FRANCAIS DEUTSCH ENGLISH NOTE ON USE: NOTE SULL’USO: OBSERVERA: • Avoid high temperatures. • Evitate di esporre l’unità a temperature alte. • Undvik höga temperaturer. Allow for sufficient heat dispersion when installed in a rack. Assicuratevi che ci sia un’adeguata dispersione del calore Se till att det finns möjlighet till god värmeavledning vid •...
- Page 4 ENGLISH DEUTSCH FRANCAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA PRECAUZIONI: • DECLARACIÓN DE CONFORMIDAD • DECLARATION OF CONFORMITY • Le aperture di ventilazione non devono essere ostruite Declaramos bajo nuestra exclusiva We declare under our sole responsibility that coprendole con oggetti, quali giornali, tovaglie, tende e this product, to which this declaration relates, così...
- Page 5 SVENSKA NEDERLANDS ESPAÑOL ITALIANO FRANCAIS DEUTSCH ENGLISH A NOTE ABOUT RECYCLING: ACERCA DEL RECICLAJE: This product’s packaging materials are recyclable and can be Los materiales de embalaje de este producto son reciclables y se pueden volver reused. Please dispose of any materials in accordance with the a utilizar.
-
Page 6: Table Of Contents
ENGLISH Getting Started Contents Accessories Check that the following parts are attached in addition to the main Getting Started unit: Accessories ·······················································································1 Before using······················································································2 Operating Instruction ..............1 Part names and functions ·······························································2 Service Station List ..............1 Top panel/Rear panel ·······································································2 AC Adapter (KSAFD1200120W1UV) .........1 Bottom panel ···················································································2 Universal Adapter (5 types) ..........1 each... -
Page 7: Before Using
ENGLISH Getting Started Getting Started Dock connector Before using Universal adapter slot Pay attention to the following before using this unit: CONTROL terminal (stereo mini plug) • Moving the unit AUDIO OUT terminals To prevent short-circuits or damaged wires in the connection cables, always unplug the power supply cord and disconnect the connection S-VIDEO OUT terminal cables between all other audio components when moving the unit. -
Page 8: Connecting Other Sources
ENGLISH Connecting Other Sources Mounting the universal adapter on the control dock Mount the included universal adapter suited for your iPod ® to the Adapter control dock’s universal adapter slot. iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries. Main unit Bottom surface of universal adapter Stamped indication... -
Page 9: Connection To Devices Equipped With
ENGLISH Connecting Other Sources Connecting Other Sources Connection to devices equipped with DOCK CONTROL terminals MODE SELECT Set the switch on the ASD-1R’s bottom panel to “DOCK The iPod can be operated from an amplifier or system device equipped with a DOCK CONTROL CONTROL”. -
Page 10: Connecting The Asd-1R And A Device Equipped With A System Control (System Connector) Terminal
ENGLISH Connecting Other Sources Connecting Other Sources Connecting the ASD-1R and a device equipped with a system control MODE SELECT Switch the switch on the (SYSTEM CONNECTOR) terminal ASD-1R’s bottom panel. The iPod can be operated using the system remote control unit equipped with system control TAPE, CD-R: (SYSTEM CONNECTOR) terminal connected to the ASD-1R. -
Page 11: Functions And Operation
• When the ASD-1R and a system device equipped with a system control (SYSTEM CONNECTOR) terminal are connected, the iPod can be operated with the cassette deck or • By connecting the ASD-1R and a DENON CD recorder remote control buttons. -
Page 12: Remote Control Buttons And Operations
ENGLISH Functions and operation Functions and operation Remote control buttons and operations Name of remote control button iPod function Operation TAPE CD-R Starts playback. Play PLAY PLAY PLAY or Pauses playback. Pause PLAY Stops playback. Stop STOP STOP Skips playback to next track. Cue to next track Skips playback to previous track. -
Page 13: Troubleshooting
ENGLISH Troubleshooting If a problem should arise, first check the following. 1. Are the connections correct? 2. Have you operated the receiver according to the Operating Instructions? If this unit is not operating properly, check the items listed in the table below. Should the problem persist, there may be a malfunction. Disconnect the power immediately and contact your store of purchase. -
Page 14: Specifications
ENGLISH Specifications 2 iPod control dock (ASD-1R) Power supply: DC IN 12V (Dedicated AC adapter) Power consumption: 1.5 W (When iPod is disconnected) Maximum external dimensions: 104 (W) x 28.5 (H) x 76.5 (D) mm Mass: 220 g Terminal: Analog audio output terminals x 1, S-Video output terminal x 1, Control terminal x 1 2 AC Adapter (KSAFD1200120W1UV) - Page 15 TOKYO, JAPAN www.denon.com Denon Brand Company, D&M Holdings Inc. Printed in China 00D 511 4514 306...
